Eufy Security T8221 Manuale utente

QUICK

START GUIDE

eufy Security Video Doorbell 2E (Battery)

TABLE OF

CONTENTS

What’s Included

01 08

Finding a Mounting Spot

Product Overview

03 10

Mounting the Bracket

How the System Works

04 13

Mounting the Doorbell

Connecting the Homebase

05 14

Detaching the Doorbell

Setting up the System

06 15

Recharging the Doorbell

Charging Your Doorbell

07 16

Notice

01 English

WHAT’S INCLUDED

For Video Doorbell Installation

QSG

Video Doorbell 2E

(Battery)

Model: T8221

Screw Packs (Spare

screws and anchors are

included)

Quick Start

Guide

Screw Hole

Positioning Card

Doorbell

Detaching Pin

15° Mounting

Wedge

(Optional)

Mounting Bracket

FCC ID: 2AOKB-T8220

IC: 23451-T8220

USB Charging

Cable

English 02

For HomeBase 2 Installation

Homebase 2

Model:T8010X

Power Adapter for

HomeBase 2

Ethernet Cable for

HomeBase 2

FCC ID:2AOKB-T8010X

IC: 23451-T8010X

Note: Power plug may vary in different regions.

03 English

PRODUCT OVERVIEW

Video Doorbell (Battery Powered)

Front view:

1. Motion Sensor

2. Microphone

3. Camera Lens

4. Ambient Light Sensor

5. Status LED

6. Doorbell Button

7. Speaker

Rear View:

1. Micro USB Charging Port

2. SYNC/RESET button

3. Detaching Mechanism

Operation How-to

Power on Press and release the SYNC button.

Add doorbell to Wi-Fi

Doorbell Chime

Press and hold the SYNC button until you hear a beep.

Power off the doorbell Quick-press the SYNC 5 times in 3 seconds.

Reset the doorbell Press and hold the SYNC button for 10 seconds.

English 04

HOW THE SYSTEM WORKS

How the System Works

The video doorbell system includes 2 parts. One is the video doorbell at your door.

The other is the HomeBase in your house.

The video doorbell detects motion at your porch and allows you to answer the door

anytime and anywhere.HomeBase 2 stores video clips on its built-in storage. When

someone rings the doorbell, people in the house will be notified.

HomeBase 2

Video Doorbell

05 English

STEP 1 CONNECTING THE HOMEBASE

Connect the HomeBase 2 to the Internet

1. Power on the HomeBase 2, then use the ethernet cable provided to connect the

HomeBase 2 to your home router.

2. The LED indicator turns blue (this may take up to 1min) when HomeBase 2 is

ready for setup.

English 06

STEP 2 SETTING UP THE SYSTEM

Download the App and Set up the System

Download the eufy Security app from the App Store (iOS devices) or Google Play

(Android devices).

setup.

Tap Add Device to add the following devices:

1. Add the HomeBase 2.

2. Add the doorbell.

07 English

STEP 3 CHARGING YOUR

DOORBELL

The doorbell comes with an 80% battery level for safe transportation. Fully charge it

before mounting the doorbell at your front door.

Note: The battery life varies depending on usage. In most common cases, a

doorbell may have up to 15 events per day and each recording lasts 20 seconds on

average. Under this scenario, the doorbell battery life can last up to 4 months.

English 08

STEP 4 FINDING A MOUNTING SPOT

Find a Mounting Spot

Take the Video Doorbell to your front door and check the live view on the eufy

Security app at the same time. Find a position where you can get the desired field of

view.

Consider the below factors:

1. Check if you can reuse the existing holes and anchors on the wall or door frame.

2. If you want to place the doorbell close to a side wall, make sure the wall doesn’t

show up in the field of view. Otherwise IR light will be reflected and night vision

will become blurry.

3. If you are drilling the mounting holes for the first time the recommended

mounting height is 48" / 1.2m from the ground.

4. Use the 15° mounting wedge as a supplementary mounting bracket if you wish to

see more on a specific side.

1.76m(5’9”)

1.2m (48")

0.3m

(12")

(40")

Video Doorbell

Without 15° Mounting wedge

Door Video Doorbell

With 15° Mounting wedge

Door

15°
