EverFocus ECD230 Manuale utente

EVERFOCUS

Color Dome Camera

Operation Instructions

Model: ECD230

Please read this manual first for correct installation and operation. This manual should be retained

for future reference. The information in this manual was current when published. The

manufacturer reserves the right to revise and improve its products. All specifications are therefore

subject to change without notice.

PRECAUTIONS

1. Do not have camera immersed in water.

2. Do not disassemble it or place it on an unstable base.

3. Do not touch the surface of CCD sensor by hand directly.

4. Never face the camera toward the sun.

5. Use proper power source otherwise the camera will not function correctly.

6. Use the camera at temperatures within 0℃~ 50℃/32℉~122℉and humidity between 20%~

80%. The input power sources is 12VDC only.

PREFACE

These cameras are compact, full functioned CCD cameras. Their stylish appearance can be

applied as per installer's ideal locations. These dome cameras can be mounted either on the

ceiling or on the wall easily. The camera uses high sensitive 1/3" color interline transfer CCD

sensor with DSP. The camera is featured withAuto Electronic Shutter, Automatic Gain Control,

and Auto White Balance functions.

FEATURES

zThe high sensitivity is achieved by using 1/3” SONY Super HAD interline transfer color

CCD

zThe electronic shutter and AGC functions allow the camera to be used in environment with

varying light levels.

zBuilt-in anti-aliasing and IR-cut optical filter

zCompact size: 87 mm (D). x 58 mm (H) / 3.48” (D) x 2.31” (H)

zSystem available for NTSC or PAL

STANDARD ACCESSORIES

zCamera Unit

zOperation Instructions (this document)

LENS AVAILABLE

* Standard board lens f=3.6 mm, F=2.0 mm.

* Other available lens : 4 Lens f=4.3 mm, F=2.0 mm

6 Lens f=6.0 mm, F=2.0 mm

8 Lens f=8.0 mm, F=2.0 mm

INSTALLATION

1. Remove the plastic dome cover.

2. Loosen the two screws of the supporting bracket to remove the camera body.

3. Using four screws to fix the camera base on the ceiling.

4. Put the camera body back to the supporting bracket, the connector of the back panel

should always be placed to camera’s left lower corner, in order to obtain the image of best

quality. Tighten the 2 screws to fix the camera. Please refer to the back panel diagram

shows as below:

a. Floor Mount b. Ceiling Mount

c. Wall mount, aim to the right d. Wall mount, aim to the left

Main

Board Bottom Connector

5. Connect the BNC connector of the camera to a color monitor, or other video device

through a 75 ohm type coaxial cable with BNC female connector at cable extension.

6. Connect the DC +12V regulated power source of the camera (DC Jack) to the DC 12V

Power-in jack with 2 mm, center+, outer- plug.

7. Once the image appears on the monitor, loosen the fixing screw located at the lens mount

then adjust the focus and diaphragm of the lens to obtain the best picture. When the ideal

picture is obtained, secure the lens mount by fixing screw firmly again.

8. Put the plastic cover back on the Dome Camera.

SPECIFICATIONS

Model Standard Resolution High Resolution

Pickup Device 1/3'' SONY Super HAD CCD

Video Format NTSC or PAL

Scanning System NTSC: 525 TV lines, 60 fields/sec

PAL: 625 TV lines, 50 fields/sec.

Picture Elements NTSC: 510(H) x 492(V)

PAL: 500(H) x 582(V)

NTSC: 768(H) x 494(V)

PAL: 752(H) x 582 (V)

Horizontal Resolution 380 TV Lines 480 TV Lines

Sensitivity 0.3 Lux/F=1.2 0.4 Lux/F=1.2

S/N Ratio Over 48dB (AGC Off)

Electronic Shutter 1/50(1/60)~1/100,000

Lens Type f=3.6mm; f=4.3mm; f=6.0mm; f=8.0mm

*Lens vary in different regions

Back Light Comp. Yes

Auto Gain Control Yes

Auto White Balance Yes

Gamma Correction 0.45

Video Output BNC 1.0Vp-p, 75ohm

Sync. Mode Internal sync

Power Source 12VDC

Power Consumption 12VDC: 1.5W max

Dimensions 87 mm (O.D.) x 58 mm (H) ; 3.48” (O.D.) x 2.31” (H)

Weight 0.1kg ; 0.22 lbs

Operating Temperature 0°C~50°C ; 32°F~122°F (20%~80% Humidity)

Certifications FCC/CE

EverFocus Electronics Corp.

Head Office:

12F, No.79 Sec. 1 Shin-Tai Wu Road,

Hsi-Chih, Taipei, Taiwan

TEL: +886-2-26982334

FAX: +886-2-26982380

www.everfocus.com.tw

USA L.A. Office:

1801 Highland Ave. Unit A

Duarte, CA 91010, U.S.A.

TEL: +1-626-844-8888

FAX: +1-626-844-8838

www.everfocus.com

USA N.Y. Office:

415 Oser Avenue Unit S

Hauppauge, NY 11788

TEL: 631-436-5070

FAX: 631-436-5027

www.everfocus.com

Europe Office:

Albert-Einstein-Strasse 1

D-46446 Emmerich, Germany

TEL: 49-2822-9394-0

www.everfocus.de

China Office:

Room B-05D-1, KESHI PLAZA , Shangdi

Information Industry Base,

Haidian District, Beijing China

100085

TEL: +86-10-62973336/37/38/39

FAX: +86-10-62971423

www.everfocus.com.cn

Japan Office:

1809 WBG MARIBU East 18F,

2-6 Nakase.Mihama-ku.

Chiba city 261-7118, Japan

TEL: +81-43-212-8188

FAX: +81-43-297-0081

www.everfocus.com

our EverFocus product is desi

ned and

manufactured with high quality materials and

components which can be recycled and

reused.

This symbol means that electrical and

electronic equipment, at their end-of-life,

should be disposed of separately from your

household waste.

Please, dispose of this equipment at your

local community waste collection/recycling

centre.

In the European Union there are separate

collection systems for used electrical and

electronic product.

Please, help us to conserve the environment

we live in!

Ihr EverFocus Produkt wurde entwickelt und

hergestellt mit qualitativ hochwertigen

Materialien und Komponenten, die recycelt

und wieder verwendet werden können.

Dieses Symbol bedeutet, dass elektrische und

elektronische Geräte am Ende ihrer

Nutzungsdauer vom Hausmüll getrennt

entsorgt werden sollen.

Bitte entsorgen Sie dieses Gerät bei Ihrer

örtlichen kommunalen Sammelstelle oder im

Recycling Centre.

Helfen Sie uns bitte, die Umwelt zu erhalten, in

der wir leben!

P/N: MCD2G00910
