Exmark FontRunner FR524 Manuale utente

Front-mount perFormance, exmark®qualit y an d proven

technology From the leader in proFessional mowing equipment.

•Hydraulic, push-button, power deck-fold system:

With one push of a button, the deck lifts to an

upright position, giving you access to the

underside for easy maintenance and cleaning.

•Full-floating UltraCut™deck: Floats over

uneven terrain to deliver a superior cut.

•Superior weight-transfer system: Keeps the

weight on drive tires to maintain traction

and reduce turf damage.

THE EXMARK

FRONTRUNNER™.

Best-selling Brand of mowing equipment for the landscape professional.

www.exmark.com

FRONTRUNNER™

MODEL ENGINE CUTTING WIDTH

FR23 KC 23 hp Kohler®Command™ SP

FR27 KC 27 hp Kohler Command SP

FR31 BV 31 hp Vanguard™

FR25 KD 25 hp Kubota®Diesel

FR524 52" (132 cm)

FR604 60" (152 cm)

FR724 72" (183 cm)

TRACTOR WEIGHT

23 hp Kohler®Command™SP 906 lbs

27 hp Kohler Command SP 925 lbs

31 hp Vanguard™960 lbs

25 hp Kubota®Diesel 1099 lbs

DECK WEIGHT

52" 360 lbs

60" 430 lbs

72” lbs

TRACTOR WIDTH

Turf Mate®tires, 49.2", AT101 tires, 53.1"

LENGTH

Single tail wheel, 112.5", Dual Tail Wheel, 109.5"

HEIGHT

68.8"

ROLL OVER PROTECTION

Standard

SEAT BELT

Standard

2-YEAR WARRANTY*

Standard

DECK CONSTRUCTION

5.5" deep UltraCut™Deck

7-gauge sides joined by a continuous bead weld to a 10-gauge top

4-point suspension, full-floating deck with six adjustable anti-scalp rollers

CUTTING WIDTH

52", 60" or 72”

CUTTING HEIGHTS

1.5" to 5.0" hydraulic cut height adjustment

PTO ENGAGEMENT

MagStop Electromagnetic 200 ft-lbs clutch with spot brake. 2 year warranty.

DECK LIFT AND FOLD

Standard hydraulic deck-fold, to approximately 70o(full-fold position)

FRONT CASTER TIRES

9 x 3.5-4, semi-pneumatic

FRONT CASTERS

3/8" thick double-yoke, smooth tread caster wheel assembly with

pre-installed needle roller bearings

REAR CASTER TIRE

13 x 6.50-6, semi-pneumatic

REAR CASTERS

23 hp model single tail wheel–standard

25 hp diesel, 27 and 31 hp models dual tail wheel–standard

1/2" thick double-yoke, smooth tread caster wheel assembly with

pre-installed bearing cups

DRIVE TIRES

23 hp model 23 x 10.50-12, 4-ply Turf Mate®turf tread

25 hp diesel, 27 and 31 hp models 24 x 12-12, 4-ply AT101 bar lug tread

OF COURSE, IT’S AN EXMARK®

Since opening our doors, we’ve been busy making high-quality, professional-grade mowers. And the FrontRunner

™

is no

exception. We take pride in the fact that anything bearing the Exmark

name is an exceptional piece of equipment. You can

feel conﬁdent knowing that it’s the brand landscape pros choose 2 to1 over any other. Visit exmark.com

EXMARK MANUFACTURING COMPANY INC. • 2101 ASHLAND AVENUE •P.O. BOX 808 •BEATRICE, NE 68310-0808 •CALL 402.223.6300 •FAX 402.223.6384

Products depicted in this literature are for demonstration purposes only. Actual products

offered for sale may vary in use, design, required attachments and safety features.

We reserve the right to improve our products and make changes in speciﬁcations,

designs and standard equipment without notice and without incurring obligations.

See your dealer for details on all of our warranties. Exmark®is a registered trademark,

Best-selling Brand of mowing equipment for the landscape professional.

www.exmark.com
