Extron electronics DTP CrossPoint 84 Manuale utente

68-2349-50 Rev. F

06 22

DTP CrossPoint 84

Scaling Presentation Matrix Switchers with DTP Extension

Matrix Switchers

IMPORTANT:

Refer to www.extron.com for the complete

user guide, installation instructions, and

specifications before connecting the

product to the power source.

IMPORTANT:

Refer to www.extron.com for the complete

user guide, installation instructions, and

specifications before connecting the

product to the power source.

Setup Guide

Safety Instructions

Safety Instructions • English

WARNING: This symbol, , when used on the product, is intended to

alert the user of the presence of uninsulated dangerous voltage within

the product’s enclosure that may present a risk of electric shock.

ATTENTION: This symbol, , when used on the product, is intended

to alert the user of important operating and maintenance (servicing)

instructions in the literature provided with the equipment.

For information on safety guidelines, regulatory compliances, EMI/EMF

compatibility, accessibility, and related topics, see the Extron Safety and

Regulatory Compliance Guide, part number 68-290-01, on the Extron website,

www.extron.com.

www.extron.com



Trademarks

All trademarks mentioned in this guide are the properties of their respective owners.

The following registered trademarks (®), registered service marks (SM), and trademarks (TM) are the property of RGBSystems, Inc. or Extron (see the

current list of trademarks on the Terms of Use page at www.extron.com):

Registered Trademarks (®)

Extron, Cable Cubby, ControlScript, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, eLink, Flat Field, FlexOS, Glitch Free, GlobalConfigurator,

GlobalScripter, GlobalViewer, Hideaway, HyperLane, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink, MediaPort, NAV,

NetPA, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, ShareLink, Show Me, SoundField, SpeedMount, SpeedSwitch, StudioStation,

SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VN-Matrix, VoiceLift, WallVault, WindoWall, XPA, XTP, XTPSystems, and ZipClip

Registered Service Mark(SM) : S3 Service Support Solutions

Trademarks (™)

AAP, AFL (Accu-RATEFrameLock), ADSP(Advanced Digital Sync Processing), AVEdge, CableCover, CDRS(ClassD Ripple Suppression),

CodecConnect, DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator, DSPConfigurator, DSVP(Digital

Sync Validation Processing), EQIP, Everlast, FastBite, Flex55, FOX, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, Opti-Torque,

PendantConnect, ProDSP, QS-FPC(QuickSwitch Front Panel Controller), RoomAgent, Scope-Trigger, SIS, SimpleInstructionSet, Skew-Free,

SpeedNav, Triple-Action Switching, True4K, True8K, Vector™ 4K, WebShare, XTRA, and ZipCaddy

FCC Class A Notice

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause interference. This interference must be corrected at the expense of the user.

ATTENTION:

• The Twisted Pair Extension technology works with unshielded twisted pair (UTP)

or shielded twisted pair (STP) cables; but to ensure FCC Class A and CE

compliance, STP cables and STP Connectors are required.

• La technologie extension paires torsadées fonctionne avec les câbles paires

torsadées blindées(UTP) ou non blindées(STP). Afin de s’assurer de la

compatibilité entre FCC ClasseA et CE, les câbles STP et les connecteurs STP

sont nécessaires.

NOTES:

• This unit was tested with shielded I/O cables on the peripheral devices. Shielded

cables must be used to ensure compliance with FCC emissions limits.

• For more information on safety guidelines, regulatory compliances, EMI/EMF

compatibility, accessibility, and related topics, see the Extron Safety and

Regulatory Compliance Guide on the Extron website.

Conventions Used in this Guide

Notifications

The following notifications are used in this guide:

ATTENTION:

• Risk of property damage.

• Risque de dommages matériels.

NOTE: A note draws attention to important information.

TIP: A tip provides a suggestion to make working with the application easier.

Software Commands

Commands are written in the fonts shown here:

^AR Merge Scene,,0p1 scene 1,1 ^B 51 ^W^C.0

[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]

E X! *X1&*X2)*X2#*X2! CE}

NOTE: For commands and examples of computer or device responses used in this

guide, the character “0” is the number zero and “O” is the capital letter “o.”

Computer responses and directory paths that do not have variables are written in the font

shown here:

Reply from 208.132.180.48: bytes=32 times=2ms TTL=32

C:\Program Files\Extron

Variables are written in slanted form as shown here:

ping xxx.xxx.xxx.xxx —t

SOH R Data STX Command ETB ETX

Selectable items, such as menu names, menu options, buttons, tabs, and field names are

written in the font shown here:

From the File menu, select New.

Click the OK button.

Specifications Availability

Product specifications are available on the Extron website, www.extron.com.

Extron Glossary of Terms

A glossary of terms is available at https://www.extron.com/technology/glossary.aspx.

Contents Contents

Introduction ............................................... 1

About this Guide.................................................. 1

About the DTP CrossPoint Matrix Switchers........ 1

DTP Input and Output Signals ......................... 3

Installation................................................. 4

Rear Panel........................................................... 4

Video Inputs and Outputs ................................ 5

Audio Inputs and Outputs................................ 6

Serial and IR Insertion Connections ................. 7

Control Connections........................................ 7

Switcher Reset ................................................ 7

Power.............................................................. 7

Additional Connector Information..................... 8

Front Panel........................................................ 12

Front Panel Operations............................ 13

Creating a Tie .................................................... 13

Recalling a Preset.............................................. 14

Viewing Ties (and Muting Outputs)..................... 14

Viewing and Adjusting Volume and Mic

Volume ............................................................. 14

Setting the Front Panel Locks (Executive

Modes)............................................................. 14

Selecting Lock Mode 2 or Toggling

Between Mode 2 and Mode 0 ...................... 15

Selecting Lock Mode 2 or Toggling

Between Mode 2 and Mode 1 ...................... 15

Remote Control........................................ 16

Selected SIS Commands................................... 16

Establishing a Network (Ethernet)

Connection................................................... 16

Number of Connections................................. 17

Establishing a USB Port Connection.............. 17

Host-to-Switcher Instructions ........................ 17

Common SIS Command Symbols ................. 17

SIS Command and Response Table for

Matrix Switcher Commands ............................. 18

Installing and Starting the Control Programs ...... 20

Installing the Programs .................................. 20

Starting the Product Conﬁguration

Software....................................................... 21

Starting the DSP Conﬁgurator Program ......... 22

Accessing the HTML Pages............................... 24

viiTechnical Publications Standards and Styles • Contents

Technical Publications Standards and Styles • Contents viii

DTP CrossPoint 84 • Introduction 1

Introduction

This section gives an overview of the Extron DTP CrossPoint 84 Series matrix switchers and

describes their features. Topics that are covered include:

• About this Guide

• About the DTP CrossPoint Matrix Switchers

About this Guide

NOTE: For more information on subjects in this guide, see the DTP CrossPoint 84

Series User Guide and the IPCP Pro Series User Guide available at www.extron.

com.

This guide provides instructions for an experienced installer to set up

and operate the Extron DTP CrossPoint 84 Scaling Presentation Matrix

Switchers with DTP Extension. Step by step instructions show you how to:

• Connect the hardware (see Installation on page4)

• Perform basic operations (see Front Panel Operations on page13)

• Use both the front panel controls and selected Simple Instruction Set (SIS) commands

(see Front Panel Operations on page13 and SIS Command and Response

Table for Matrix Switcher Commands on page18)

• Load and start up the Microsoft®Windows®-based Product Configuration Software (see

page21) and DSP Configurator Program (see page22).

• Connect to the built-in HTML pages (see page24),which you can use to view the switcher status

and make changes to the communications protocol and set the system clock.

About the DTP CrossPoint Matrix Switchers

The DTP CrossPoint matrix switchers distribute HDCP-compliant HDMI and Extron

proprietary DTP video and audio signal types. A matrix switcher routes any input signal

to any combination of outputs. It can route multiple input and output configurations

simultaneously.

The fixed matrix size switchers support a total of eight inputs: six HDMI and two inputs from

Extron DTP transmitting devices. The matrix switchers provide four outputs: two HDMI and

two scaled DTP outputs.

The DTP CrossPoint Matrix Series consists of three 8-input by 4-output models,

differentiated by their audio and control capabilities:

• DTP CrossPoint 84

• DTP CrossPoint 84 IPCP SA — Includes a stereo audio amplifier and a built-in Extron

IPCP Pro 350 control processor

• DTP CrossPoint 84 IPCP MA 70 — Includes a 70 V mono audio amplifier and a built-

in Extron IPCP Pro 350 control processor

DTP CrossPoint 84 • Introduction 2

POWER

12V

--AMAX

Rx GTx RxTxG

RS-232 IR

RxTx

RGB, Y, R-Y, B-YHDMIHDMI

SIG LINK

DTP OUT

AUDIO

CONTACTRS-232TALLY

123G123+V

RESET

INPUTS

OVER DTPREMOTE

100-240V ~ --A MAX

50/60 Hz LAN

EXP

RS-232

Tx Rx G

RESET

MIC +48V

5678

1234 8

4 1

12345G 678910 G

11 12 13 14 15 G1617181920G

234

56 78

910

11 127

MIC/LINE INPUTS

OUTPUTS

DIGITAL I/O

REMOTE

DMP 128 C

LAN

321

50-60 Hz

100-240V ~ 2.0 A MAX

SIG LINK

OUT

SIG LINK

OUT

1344

XTPRS-232 IR

Tx Rx Tx RxG

Tx Rx

RTSCTS

GTx Rx GTxRxG

RS-232 IR

Tx Rx Tx RxG

Tx Rx G

Tx Rx Tx Rx

XTP

RESET

S/PDIF

OUT

DTP

XTP

DTP

XTP

DTPEXP

+48V

MIC/LINE

113

LINK

LAN 2

LAN 1

LAN 3

HDBT

DTP

HDBT

1234 578

DTP CROSSPOINT 84

CLASS 2 WIRING

RS-232 IR

Tx Rx Tx RxG

OVER TP

REMOTE

SIG LINK

AUDIO INPUTS

INPUTS

AUDIO OUTPUTS

AMP OUTPUT

COM1

CONTROL

1234G

COM2 DIGITAL I/O

COM3

DMP EXPANSION

SGG

2C34C D-SG+S+V

IR/SERIAL

PWR OUT = 6W

eBUS

RELAYS

OUTPUTS

LR 1

LR 3

LR 4

LR 2

LR4

Extron Extron

OUTPUTS

AUDIO

TxRx GTxRx

RS-232 IR

OVERDTP

OUTPUTS

AUDIO

TxRx GTxRx

RS-232 IR

OVERDTP

OUTPUTS

AUDIO

TxRx GTxRx

RS-232 IR

OVERDTP

OUTPUTS

AUDIO

TxRx GTxRx

RS-232 IR

OVERDTP

DTPHDMI 230 Tx

Flat Panel DisplayFlat Panel Display

CATx Cable

up to 330' (100 m)

CATx Cable up to 230' (70 m)

CATx Cable

up to 230' (70 m) CATx Cable

up to 330' (100 m)

RS-232HDMI

HDMI

Extron

DTP HDMI

330 D Rx

Receiver

Extron

DTP HDMI

230 D Rx

Receiver

RS-232

Ethernet

Audio

AudioAudio

HDMI

Extron

DTP T USW 333

DTP Transmitter

Extron

DTP HDMI 230 Tx

Transmitter

Inputs

Outputs

Extron

TLP 1020T

10" Tabletop

TouchLink Pro

Touchpanel

Control

Network

Microphones

Extron

SM 26

Surface Mount

Speakers

Extron

DMP 128 C

Digital Matrix

Processor

Camera

Video Conference

Codec

Table Microphones

Wireless

Microphones

Extron

DTP CrossPoint 84 SA

Scaling Presentation

Matrix Switcher with

DTP Extension

Figure 1. Typical DTP CrossPoint Application

The switchers provide four mono microphone (mic)/line level inputs that can be mixed with

or across one or all audio outputs.

The IPCP models also feature the built-in Extron IPCP Pro 350 control processor, which has

local area network (LAN) Ethernet ports, RS-232 and IR-based control, relays, and digital

I/O controls that can control and monitor a variety of external devices, such as projectors

and lights. The non-IPCP model has one Ethernet port.

The matrix switcher can be remotely controlled via an Ethernet LAN port, a serial port,

or a USB port connection using either the Extron Product Configuration Software, DSP

Configurator software, or the Simple Instruction Set (SIS).

Altri manuali per DTP CrossPoint 84

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Extron electronics Commutatore a matrice

Extron electronics

Extron electronics CrossPoint 450 Plus 84 HV Manuale utente

Extron electronics

Extron electronics FOX3 Matrix Series Manuale utente

Extron electronics

Extron electronics MVX 128 Manuale utente

Extron electronics

Extron electronics XTP II CrossPoint Series Manuale utente

Extron electronics

Extron electronics XTP II CrossPoint Series Manuale utente

Extron electronics

Extron electronics MAV Plus Series Manuale utente

Extron electronics

Extron electronics DMS 1600 Manuale utente

Extron electronics

Extron electronics DXP DVI Pro Manuale utente

Extron electronics

Extron electronics MSG0804 Manuale utente

Extron electronics

Extron electronics DTP CrossPoint 4K Series Manuale utente

Extron electronics

Extron electronics SW HD 4K PLUS Series Manuale utente

Extron electronics

Extron electronics MMX 42 Series Manuale utente

Extron electronics

Extron electronics MultiMatrix SMX System Manuale utente

Extron electronics

Extron electronics MPX Plus 866 A Manuale utente

Extron electronics

Extron electronics DTP CrossPoint 84 Manuale utente

Extron electronics

Extron electronics DXP HD 4K Series Manuale utente

Extron electronics

Extron electronics DTP CrossPoint 4K Series Manuale utente

Extron electronics

Extron electronics HDXP Plus Series Manuale utente

Extron electronics

Extron electronics Matrix 50 Series Manuale utente

Extron electronics

Extron electronics DTP CrossPoint 84 IPCP Manuale del proprietario

Extron electronics

Extron electronics XTP II CrossPoint 1600 Manuale utente

Extron electronics

Extron electronics DMS 1600 Manuale utente

Extron electronics

Extron electronics CrossPoint 82 DTP2 Manuale utente

Extron electronics

Extron electronics DMS 1600 Manuale utente

Manuali Commutatore a matrice popolari di altre marche

Broadcast Tools

Broadcast Tools SS 8.2 Manuale utente

Altimium

Altimium MATF32 Manuale utente

ALFAtron

ALFAtron ALF-MUK44N Manuale utente

Monoprice

Monoprice Blackbird 15377 Manuale utente

Kramer

Kramer XL 3216VS Manuale utente

PTN

PTN FMX12 Manuale utente

CYP

CYP nT15GX01 Manuale utente

Kramer

Kramer VP-2x2 Manuale utente

Kramer

Kramer Sierra Video 6432V5xl Manuale utente

TESmart

TESmart HMA0402A40 Manuale utente

Octava

Octava HD4XSTPMX Manuale utente

Intelix

Intelix FLX-88 Istruzioni operative

Kramer

Kramer LASSEN XL 3232S Manuale utente

Roland

Roland XS-1HD Manuale utente

Kramer

Kramer VS-66HDCPxl Manuale utente

Atlona

Atlona AT-HDMI-22M Manuale utente

Link

Link HD8X8 Manuale utente

AMX

AMX AVS-OP-2020-117 Istruzioni e ricette
