Specifications — MAV Series Matrix Switchers

Video — composite video and S-video models

Routing

MAV 44 Series .................. 4 x 4 matrix

MAV 48 Series .................. 4 x 8 matrix

MAV 62 Series .................. 6 x 2 matrix

MAV 84 Series .................. 8 x 4 matrix

MAV 88 Series .................. 8 x 8 matrix

Gain ............................................... Unity

Bandwidth .................................... 150 MHz (-3 dB), fully loaded

Differential phase error .............. <0.1º at 3.58 MHz and 4.43 MHz

Differential gain error ................. <0.1% at 3.58 MHz and 4.43 MHz

Crosstalk ....................................... <-50 dB @ 5 MHz

Switching speed ........................... 20 ms (max.)

Video input — composite video and S-video models

Number/signal type

MAV 44 AV, MAV 44 AV RCA, MAV 48 AV, MAV 48 AV RCA

4 composite video

MAV 44 SVA, MAV 44 SVA RCA, MAV 48 SVA, MAV 48 SVA RCA

4 S-video

MAV 62 Composite Video 6 composite video

MAV 62 S-video ............... 6 S-video

MAV 84 AV, MAV 84 AV RCA, MAV 88 AV, MAV 88 AV RCA, MAV 88 V

8 composite video

MAV 84 SVA, MAV 84 SVA RCA, MAV 88 SVA, MAV 88 SVA RCA

8 S-video

Connectors

MAV 44/48 composite video models

4 female BNC

MAV 44/48 S-video models

4 female 4-pin mini DIN

MAV 62 Composite Video 6 BNC female

MAV 62 S-video ............... 6 female 4-pin mini DIN

MAV 84/88 composite video models

8 female BNC

MAV 84/88 S-video models

8 female 4-pin mini DIN

Nominal level ............................... 1 Vp-p for Y of S-video, and for composite video

0.3 Vp-p for C of S-video

Minimum/maximum levels ...... Analog: 0.4 V to 2.0 Vp-p with no offset at unity gain

Impedance .................................... 75 ohms

Return loss

MAV 62 Series ................... <-30 dB @ 5 MHz

All other models .............. Composite video: <-38 dB @ 0 to 10 MHz

S-video: <-25 dB @ 0 to 10 MHz

DC offset (max. allowable)

MAV 62 Series ................... 1.5 V

All other models .............. 5 V

External sync (genlock)............... 0.2 V to 0.4 Vp-p

Input coupling.............................. AC coupling only (for models other than the MAV 62 Series)

1-2 MAV 44, MAV 48, MAV 62, MAV 84, and MAV 88 Series Matrix Switchers • Specifications

Video output — composite video and S-video models

MAV 44 AV, MAV 44 AV RCA, MAV 84 AV, MAV 84 AV RCA

4 composite video

MAV 44 SVA, MAV 44 SVA RCA, MAV 84 SVA, MAV 84 SVA RCA

4 S-video

MAV 62 Composite Video 2 composite video

MAV 62 S-video ............... 2 S-video

MAV 88 AV, MAV 88 AV RCA, MAV 88 V, MAV 48 AV, MAV 48 AV RCA

8 composite video

MAV 88 SVA, MAV 88 SVA RCA, MAV 48 SVA, MAV 48 SVA RCA

8 S-video

Connectors

MAV 62 Composite Video 2 female BNC

MAV 62 S-video ............... 2 female 4-pin mini DIN

MAV 44/84 composite video models

4 female BNC

MAV 44/84 S-video models

4 female 4-pin mini DIN

MAV 48/88 composite video models

8 female BNC

MAV 48/88 S-video models

8 female 4-pin mini DIN

Nominal level ............................... 1 Vp-p for Y of S-video, and for composite video

0.3 Vp-p for C of S-video

Minimum/maximum levels ...... 0.4 V to 2.0 Vp-p (follows input)

Impedance .................................... 75 ohms

Return loss

MAV 62 Series .................. <-30 dB @ 5 MHz

All other models .............. S-video: <-25 dB @ 5 MHz

Composite video: <-40 dB @ 5 MHz

DC offset

MAV 62 Series .................. ±5 mV maximum with input at 0 offset

All other models .............. 15 mV typical (per output enabled with 70 ohm termination) with input at 0 offset

Switching type ............................. Vertical interval

Sync — composite video and S-video models

Genlock connectors ..................... 2 BNC female

Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM

Audio — audio models

Routing

MAV 44 Series .................. 4 x 4 stereo matrix

MAV 48 Series .................. 4 x 8 stereo matrix

MAV 62 Series .................. 6 x 2 stereo matrix

MAV 84 Series .................. 8 x 4 stereo matrix

MAV 88 Series .................. 8 x 8 stereo matrix

Gain ............................................... Adjustable; the default is unity. Unity gain occurs for all RCA connector models

and in MAV 62 Series models configured for unbalanced output. In all other

models with captive screw connectors, unity gain occurs when the switcher is

configured for balanced output.

Frequency response ..................... 20 Hz to 20 kHz, ±0.5 dB

THD + Noise ................................ 1% @ 1 kHz, 0.3% @ 20 kHz at nominal level

S/N ............................................... 90 dB at maximum output (unweighted)

Crosstalk ....................................... <-65 dB @ 20 kHz, <-80 dB @ 1 kHz or below 60 Hz, fully loaded

MAV 44, MAV 48, MAV 62, MAV 84, and MAV 88 Series Matrix Switchers • Specifications 1-3

Specifications — MAV Series Matrix Switchers (continued)

Stereo channel separation

MAV 62 Series .................. >80 dB @ 1 kHz

All other models .............. >80 dB @ 20 Hz to 20 kHz

CMRR ............................................ >75 dB @ 20 Hz to 20 kHz

Audio input — audio models

Number/signal type

MAV 44 AV, MAV 44 SVA, MAV 48 AV, MAV 48 SVA

4 stereo, balanced/unbalanced

MAV 44 AV RCA, MAV 44 SVA RCA, MAV 48 AV RCA, MAV 48 SVA RCA

4 stereo, unbalanced

MAV 62 ............................. 6 stereo, balanced/unbalanced

MAV 84 AV, MAV 84 SVA, MAV 88 AV, MAV 88 SVA

8 stereo, balanced/unbalanced

MAV 84 AV RCA, MAV 84 SVA RCA, MAV 88 AV RCA, MAV 88 SVA RCA

8 stereo, unbalanced

Connectors

MAV 44 AV, MAV 44 SVA, MAV 48 AV, MAV 48 SVA

(4) 3.5 mm captive screw connectors, 5 pole

MAV 44 AV RCA, MAV 44 SVA RCA, MAV 48 AV RCA, MAV 48 SVA RCA

4 pairs of RCA female connectors

MAV 62 ............................. (6) 3.5 mm captive screw connectors, 5 pole

MAV 84 AV, MAV 84 SVA, MAV 88 AV, MAV 88 SVA

(8) 3.5 mm captive screw connectors, 5 pole

MAV 84 AV RCA, MAV 84 SVA RCA, MAV 88 AV RCA, MAV 88 SVA RCA

8 pairs of RCA female connectors

Impedance

MAV 62 Series .................. >10k ohms unbalanced/balanced, DC coupled

All other models .............. >18k ohms unbalanced, 24k ohms balanced, DC coupled

Nominal level

MAV 62 Series .................. -10 dBV (316 mV, consumer level)

All other models .............. Configurable: +4 dBu (1.23 V, professional level) or -10 dBV (316 mV, consumer

level)

Maximum level

MAV 62 Series .................. +19.5 dBu (balanced or unbalanced) at 1% THD+N

All other models .............. >+20 dBu (captive screw models) at 1% THD+N

>+14 dBu (RCA models) at 1% THD+N

Input gain adjustment................. –18 dB to +10 dB, adjustable per input; default = 0 dB. (This is referenced to the

internal bus signal level. It can be verified by measuring the unbalanced output

level when the output level is set to “Consumer”.)

0 dBu = 0.775 V(rms), 0 dBV = 1 V(rms), 0 dBV 2 dBu

Audio output — audio models

Number/signal type

MAV 44 AV, MAV 44 SVA, MAV 84 AV, MAV 84 SVA

4 stereo, balanced/unbalanced

MAV 44 AV RCA, MAV 44 SVA RCA, MAV 84 AV RCA, MAV 84 SVA RCA

4 stereo, unbalanced

MAV 62 Series .................. 2 stereo, balanced/unbalanced

MAV 88 AV, MAV 88 SVA, MAV 48 AV, MAV 48 SVA

8 stereo, balanced/unbalanced

MAV 88 AV RCA, MAV 88 SVA RCA, MAV 48 AV RCA, MAV 48 SVA RCA

8 stereo, unbalanced

1-4 MAV 44, MAV 48, MAV 62, MAV 84, and MAV 88 Series Matrix Switchers • Specifications

Connectors

MAV 44 AV, MAV 44 SVA, MAV 84 AV, MAV 84 SVA

(2) 3.5 mm captive screw connectors, 10 pole

MAV 44 AV RCA, MAV 44 SVA RCA, MAV 84 AV RCA, MAV 84 SVA RCA

4 pairs of RCA female

MAV 62 Series .................. (2) 3.5 mm captive screw connectors, 5 pole

MAV 88 AV, MAV 88 SVA, MAV 48 AV, MAV 48 SVA

(4) 3.5 mm captive screw connectors, 10 pole

MAV 88 AV RCA, MAV 88 SVA RCA, MAV 48 AV RCA, MAV 48 SVA RCA

8 pairs of RCA female

Impedance .................................... 50 ohms unbalanced, 100 ohms balanced

Gain error ...................................... <±0.1 dB channel to channel

Nominal level ............................... Configurable: +4 dBu (1.23 V, professional level) or -10 dBV (316 mV, consumer

level)

Maximum level (Hi-Z)

MAV 62 Series .................. >+18 dBu, balanced; >+12 dBu, unbalanced at 1% THD+N

All other models .............. >+24 dBu, balanced; >+18 dBu, unbalanced at 1%THD+N

Maximum level (600 ohm)

MAV 62 Series .................. >+16 dBm, balanced; >+10 dBm, unbalanced at 1% THD+N

All other models .............. >+19 dBm, balanced; >+13 dBm, unbalanced at 1%THD+N

Control/remote — switcher

Serial control port ........................ RS-232, 9-pin female D connector

Baud rate and protocol ............... 9600, 8 data bits, 1 stop bit, no parity

Serial control pin configurations

MAV 62 Series .................. 2 = TX, 3 = RX, 5 = GND

All other models .............. 2 = TX, 3 = RX, 5 = GND, 9 = hardwired IR

IR controller module (all models except MAV 62 Series)

IR 501 remote control (optional)

Program control ........................... Extron’s control/configuration program for Windows®

Extron’s Simple Instruction Set (SIS™)

General

Power............................................. 100 VAC to 240 VAC, 50/60 Hz, 15 watts, internal, autoswitchable

Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Rack mount

MAV 62 Series .................. Yes, with optional 1U rack shelf, part #60-190-01 or 60-604-01

All other models .............. Yes, with included brackets, part #70-077-03

Also furniture mountable with an optional under-desk mounting kit, part

#70-222-01

Enclosure type .............................. Metal

Enclosure dimensions

MAV 62 Series ................. 1.75" H x 8.75" W x 9.5" D (1U high, half rack wide)

4.4 cm H x 22.2 cm W x 24.1 cm D

All other models .............. 1.75" H x 17.4" W x 8.5" D (1U high, full rack wide)

4.4 cm H x 44.2 cm W x 21.6 cm D

(Depth excludes connectors. Width excludes rack ears.)

Product weight

MAV 62 Series .................. 3.3 lbs (1.5 kg)

All other models .............. 7.0 lbs (3.2 kg)

Shipping weight

MAV 62 Series .................. 6 lbs (3 kg)

All other models .............. 10 lbs (5 kg)

MAV 44, MAV 48, MAV 62, MAV 84, and MAV 88 Series Matrix Switchers • Specifications 1-5

Specifications — MAV Series Matrix Switchers (continued)

Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances

MAV 62 Series .................. CE

All other models .............. CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%.

Specifications are subject to change without notice.

(7.51-020405-D7)

1-6 MAV 44, MAV 48, MAV 62, MAV 84, and MAV 88 Series Matrix Switchers • Specifications

Altri manuali per MAV 44 Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Extron electronics Commutatore a matrice

Extron electronics

Extron electronics MPX 423 A Manuale utente

Extron electronics

Extron electronics Matrix 12800 wideband Manuale utente

Extron electronics

Extron electronics MVX 44 Series Manuale utente

Extron electronics

Extron electronics CLK 100 Manuale utente

Extron electronics

Extron electronics CrossPoint 42 HVA Manuale utente

Extron electronics

Extron electronics FOX3 Matrix 80x Manuale utente

Extron electronics

Extron electronics Matrix 3200 Series Manuale utente

Extron electronics

Extron electronics XTP CrossPoint1600 Manuale utente

Extron electronics

Extron electronics MVX 128 VGA A Manuale utente

Extron electronics

Extron electronics FOX3 Matrix Series Manuale utente

Extron electronics

Extron electronics CrossPoint 300 Series Manuale utente

Extron electronics

Extron electronics CrossPoint 450 Plus 64 Series Manuale utente

Extron electronics

Extron electronics CrossPoint 450 Plus 64 Series Manuale utente

Extron electronics

Extron electronics DTP CrossPoint 84 Manuale utente

Extron electronics

Extron electronics XTP II CrossPoint Series Manuale utente

Extron electronics

Extron electronics MVX 128 Manuale utente

Extron electronics

Extron electronics MPX 866 A Manuale utente

Extron electronics

Extron electronics DTP CrossPoint 84 IPCP Manuale del proprietario

Extron electronics

Extron electronics DTP CrossPoint 108 4K Manuale utente

Extron electronics

Extron electronics MMX 32 VGA A Manuale utente

Extron electronics

Extron electronics MVX VGA A Manuale utente

Extron electronics

Extron electronics Matrix 50 Series Manuale utente

Extron electronics

Extron electronics MultiMatrix SMX System Manuale utente

Extron electronics

Extron electronics CrossPoint 450 Plus 64 Series Manuale utente

Manuali Commutatore a matrice popolari di altre marche

Broadcast Tools

Broadcast Tools SS 8.2 Manuale utente

Altimium

Altimium MATF32 Manuale utente

ALFAtron

ALFAtron ALF-MUK44N Manuale utente

Monoprice

Monoprice Blackbird 15377 Manuale utente

Kramer

Kramer XL 3216VS Manuale utente

PTN

PTN FMX12 Manuale utente

CYP

CYP nT15GX01 Manuale utente

Kramer

Kramer VP-2x2 Manuale utente

Kramer

Kramer Sierra Video 6432V5xl Manuale utente

TESmart

TESmart HMA0402A40 Manuale utente

Octava

Octava HD4XSTPMX Manuale utente

Intelix

Intelix FLX-88 Istruzioni operative

Kramer

Kramer LASSEN XL 3232S Manuale utente

Roland

Roland XS-1HD Manuale utente

Kramer

Kramer VS-66HDCPxl Manuale utente

Atlona

Atlona AT-HDMI-22M Manuale utente

Link

Link HD8X8 Manuale utente

AMX

AMX AVS-OP-2020-117 Istruzioni e ricette
