VersaTools™ MSW 4V SDI

VersaTools™ MSW 4V SDI Mini Switcher • Installation 3VersaTools™ MSW 4V SDI Mini Switcher • Installation

Installation

Introduction

The Extron MSW 4V SDI is a four-input, two-parallel-output, mini SDI

(serial digital interface) switcher (MSW). The MSW is a member of the

Extron VersaTools™ line of basic distribution amplifiers, switchers, and

associated video accessories.

The MSW switches among up to four SMPTE-259M serial video SDI

inputs on female BNC connectors and outputs two identical equalized

and re-clocked SDI outputs on female BNC connectors. The MSW 4V

SDI automatically recognizes 4fsc PAL, 4fsc NTSC, component 4:2:2, and

Widescreen 4:2:2 standards.

The switcher can be operated from the front panel or via a contact

closure device connected to the rear panel such as an Extron KP 6

Keypad Remote Control or an IR 102 infrared remote control kit. The

MSW also features a front panel selectable autoswitching mode that

automatically switches to the highest numbered input with active SDI

signals.

The MSW ships with an external 12VDC power supply.

Installation

The 1U high, quarter rack width, MSW 4V SDI can be mounted on a

rack shelf, mounted under a desk or tabletop, or mounted on a projector

bracket.

Rack mounting

For optional rack mounting, mount the MSW on a VersaTools 19" 1U

Rack Shelf (Extron part #60-190-20) (figure 1) or a standard Universal 1U

Rack Shelf (Extron part #60-190-01) (figure 2). On the standard rack

shelf, the MSW mounts in one of four locations to the rear of the rack or

in one of four locations to the front of the rack.

1. If feet were previously installed on the bottom of the MSW, remove

them.

2. Mount the MSW on the rack shelf, using two 4-40 x 3/16 screws in

opposite (diagonal) corners to secure the MSW to the shelf.

3. Install blank panel(s) or other unit(s) to the rack shelf.

Only products in the VersaTools line can be mounted to a

VersaTools shelf. Most 1U rack-mountable Extron products can

be mounted on the standard shelf.

Furniture or projector mounting

Furniture mount or projector mount the MSW using the optional

mounting kit (Part #70-212-01, furniture, or 70-217-01, projector) as

follows:

1. Attach the mounting brackets to the MSW with the machine

screws provided (figure 3).

(2) 4-40 x 3/16" screws

Use 2 mounting holes on

opposite corners

1U Rack Shelf

1/4 Rack Width False Front

Face Plate

A/VSWITCHER

AUTOSWICH

MODENORMALAUTO

1234

A/VSWITCHER

AUTOSWICH

MODENORMALAUTO

1234

A/VSWITCHER

AUTOSWICH

MODENORMALAUTO

1234

Figure 1 — Mounting the MSW on a VersaTools rack

shelf

A/V SWITCHER

AUTOSWITCH

MODENORMALAUTO

1234

A/V SWITCHER

AUTOSWITCH

MODENORMALAUTO

1234

Figure 2 — MSW mounted on a standard rack shelf

2. If feet were previously installed on the bottom of the MSW, remove

them.

3.For furniture mounting, hold the MSW with the attached brackets

against the underside of the table or other furniture. Mark the

location of the screw holes of the bracket on the mounting surface.

VersaTools™ MSW 4V SDI Mini Switcher • Connections 5VersaTools™ MSW 4V SDI Mini Switcher • Connections

Installation

4.For furniture mounting, drill 3/32” (2 mm) diameter pilot holes,

1/4” (6.3 mm) deep in the mounting surface at the marked screw

locations.

5.For furniture mounting, insert #8 wood screws into the four pilot

holes. Tighten each screw into the mounting surface until just less

than 1/4” of the screw protrudes.

6.For furniture mounting, align the mounting screws with the slots

in the brackets and place the MSW against the surface, with the

screws through the bracket slots.

7.For furniture mounting, slide the switcher slightly forward or

back, then tighten all four screws to secure the MSW in place.

Ceiling

Digital Projector

Projector

Mounting

Bracket

MDA4VSDI

POWER

15V

.5AMAX

SDIINPUT

SDIOUTPUTS

Mounting

Bolt

Projector Mounting Under Desk Mounting

A/VSWITCHER

MODENORMALAUTO

AUTO

SWITCH

1234

Figure 3 — Desk and projector mounting the MSW

8.For projector mounting, secure the MSW to a projector mount by

inserting the mounting bolt through the bracket’s slotted hole.

Rear Panel Connections

SDI Inputs (1 through 4) connectors — Connect SDI video inputs

to these BNC connectors.

SDI Outputs (A and B) connectors — Connect one or two SDI

devices to these BNC connectors. The MSW outputs re-clocked

SDI outputs.

Contact connector — Connect a remote contact closure device to

the switcher for remote control of the switcher, or daisy chain the

switcher to other MSWs for remote control of the other switchers,

via this 5-pin captive screw connector

MSW 4V SDI

POWER

12V

.5A MAX

CONTACT

1234

24 3

Figure 4 — MSW 4V SDI rear panel

The switcher must be in normal (manual) mode for contact

closure to work.

To select an input using a contact closure device, momentarily

short the pin for the desired input number to logic

ground (pin 5). To force one of the inputs to be

always selected, leave the short in place. The short

overrides any front panel input selections.

You can also daisy chain multiple MSWs via the

Contact connector for front panel control of all switchers; touch

the input button on one MSW to switch all MSWs. Wire pin 1 to

pin 1, pin 2 to pin 2, and so on.

CAUTION

Power supply voltage polarity is extremely important.

Applying power with incorrect voltage polarity could

damage the power supply and the MSW. Identify the power

cord negative lead by the ridges on the side of the cord.

Power connector — Plug the external 12V power supply into this

2-pole captive screw connector. The power supply is included

with the unit. Figure 5 shows how to wire the connector.

Do not tin the stripped power supply leads before installing the

captive screw connector. Tinned wires are not as secure in the

captive screw connectors and could be pulled out.

The two power cord wires must be kept separate while the

power supply is plugged in. Remove power before wiring.

Return

+12V

End Captive Screw

Connector

view of

power supply

output cord.

Figure 5 — Power connector wiring

CONTACT

1234

VersaTools™ MSW 4V SDI Mini Switcher • Specifications 7VersaTools™ MSW 4V SDI Mini Switcher • Controls and Indicators

Connections

To verify the polarity before connection, check the no load power

supply output with a voltmeter.

Alternatively, an Extron P/S 100 Universal 12VDC Power Supply

can power up to ten MSWs or other Extron 12V DC devices using

only one AC power connector.

Front Panel Controls and Indicators

A/V SWITCHER

MODE NORMAL AUTO

AUTO

SWITCH

1234

7 8 9

Figure 6 — MSW 4V SDI front panel

Input selection

Input 1 through 4 buttons — Each Input button selects the

associated input for output.

The Input 1, Input 2, and Input 3 buttons are also used to toggle

auto-switch mode on and off. See Autoswitch mode controls and

indicators and items

, and

Input 1 through 4 LEDs — The Input LEDs identify the selected

input.

Autoswitch mode controls and indicators

Mode button — The Mode button is used with the Normal

button or the Auto button to select the switching mode. Mode is a

secondary function of the Input 1 button.

Normal button — The Norm button is used with the Mode

button to select normal mode. Normal is a secondary function of

the Input 2 button.

Auto(switch) button — The Auto button is used with the Mode

button to select autoswitching mode. Auto is a secondary

function of the Input 3 button.

Auto Switch LED — When lit, the Auto Switch LED indicates

that the switcher is in autoswitch mode. The MSW automatically

switches to the highest numbered input with active SDI signals.

When unlit, the switch is in normal (manual switch) mode.

Mode selection

Turn autoswitch mode on or off as follows:

1. Press and hold the Mode (Input 1) button.

2a.To select autoswitch mode — Press and release the Auto (Input 3)

button. The Auto Switch Mode Active LED lights.

2b.To select normal mode — Press and release the Normal (Input 2)

button. The Auto Switch Mode Active LED goes off.

3. Release the Mode button.

Specifications

Video

Resolution ..................................... 8 or 10 bits, automatic

Operations standards .................. 143 Mb/s (4fsc NTSC)

177 Mb/s (4fsc PAL)

270 Mb/s (4:2:2) component video

360 Mb/s (4:2:2) widescreen, autoselect

Equalization and re-clocking ..... Automatic for up to -30dB of cable loss

Video input

Number/signal type ................... 4 digital component video

Connectors .................................... 4 female BNC

Minimum/maximum levels ...... 0.4V to 2.0V p-p with no offset

Impedance .................................... 75 ohms

Return loss .................................... -40dB, DC @ 10 MHz

Maximum DC offset .................... 5.0V

Video output

Number/signal type ................... 2 re-clocked SMPTE-259 serial digital component

video

Connectors .................................... 2 BNC female

Impedance .................................... 75 ohms

Return loss .................................... <-30dB @ 5 MHz

DC offset ....................................... ±5mV maximum with input at 0 offset

Sync

Standards ...................................... SMPTE-259

Control/remote — switcher

Contact closure............................. 1 3.5 mm 5-pole captive screw connector

Extron Electronics, USA

1230 South Lewis Street

Anaheim, CA 92805

USA

714.491.1500

Fax 714.491.1517

Extron Electronics, Europe

Beeldschermweg 6C

3821 AH Amersfoort

The Netherlands

+31.33.453.4040

Fax +31.33.453.4050

Extron Electronics, Asia

135 Joo Seng Road, #04-01

PM Industrial Building

Singapore 368363

+65.6383.4400

Fax +65.6383.4664

Extron Electronics, Japan

Daisan DMJ Building 6F

3-9-1 Kudan Minami

Chiyoda-ku, Tokyo 102-0074 Japan

+81.3.3511.7655

Fax +81.3.3511.7656

www.extron.com

FCC Class A Notice

Note: This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference, in which case the user will be required

to correct the interference at his own expense.

Note: This unit was tested with shielded cables on the peripheral devices. Shielded cables

must be used with the unit to ensure compliance.

Contact closure pin configurations See switcher’s label.

General

Power ............................................. 100VAC to 240VAC, 50/60 Hz, 6 watts, external,

autoswitchable; to 12VDC power supply.

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to

90%, non-condensing

Operating +32° to +122°F (0° to +50°C) / 10% to

90%, non-condensing

Rack mount................................... Yes, with optional 1U rack shelf #60-190-01 or 60-

190-20;

also under-furniture mountable with optional

brackets #70-212-01,

or projector mountable with optional brackets

#70-217-01

Enclosure type .............................. Metal

Enclosure dimensions ................. 1.7" H x 4.3" W x 3.0" D (1U high, quarter rack

width)

4.3 cm H x 10.9 cm W x 6.5 cm D

(Depth excludes connectors.)

Product weight ............................. 0.6 lbs (0.3 kg)

Shipping weight .......................... 3 lbs (1.4 kg)

Vibration ....................................... ISTA/NSTA 1A in carton (International Safe

Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

Specifications are subject to change without notice.

Indice

Altri manuali Extron electronics Interruttore

Extron electronics

Extron electronics FOX T USW 203 Manuale utente

Extron electronics

Extron electronics MEDIALINK MLC 206 Manuale utente

Extron electronics

Extron electronics SVS 100 Manuale utente

Extron electronics

Extron electronics SW2 DP Manuale utente

Extron electronics

Extron electronics IR Broadcaster Manuale utente

Extron electronics

Extron electronics SW4 12G HD-SDI Manuale utente

Extron electronics

Extron electronics SW HD 4K PLUS Series Manuale utente

Extron electronics

Extron electronics SW HD 4K PLUS Series Manuale utente

Extron electronics

Extron electronics ISS 408 Manuale utente

Extron electronics

Extron electronics VSW 2VGA A Manuale utente

Extron electronics

Extron electronics MPS 602 Manuale utente

Extron electronics

Extron electronics SW2 VGA DA2 AF R Manuale utente

Extron electronics

Extron electronics SW2 VGA DA2 A Manuale utente

Extron electronics

Extron electronics IN1608 HDBT Series Manuale utente

Extron electronics

Extron electronics MediaLink VersaTools MLS 100 A Manuale utente

Extron electronics

Extron electronics System 8 Plus Manuale utente

Extron electronics

Extron electronics SW2 DP Manuale utente

Extron electronics

Extron electronics IN1804 Series Manuale utente

Extron electronics

Extron electronics MPS 601 Manuale utente

Extron electronics

Extron electronics ISS 408 Manuale utente

Extron electronics

Extron electronics SGS 408 Manuale utente

Extron electronics

Extron electronics VGA MATRIX SWITCHERS MVX PLUS 128 Manuale utente

Extron electronics

Extron electronics PVS 204SA Plus Istruzioni per l'installazione e il funzionamento

Extron electronics

Extron electronics USB HUB4 Series Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
