Ez One Shot BAR CODE SCANNER Manuale utente
Default
CHECK VERSION
Version: MAR20041021
DEFAULT
BAR CODE
SCANNER
USER'S
MANUAL
Ez One Shot
CONTENTS
GENERAL
Table of contents
-------
1
Introduction, Ez Troubleshooting
-------
2-3
Cloning Mode
-------
4-5
Getting Started
How to fix the scanner to the terminal
-------
6-9
How to change a cable
-------
9
How to set up the parameter
-------
10
SETTING GROUP
1 Interfaces selection, Computer type, Default
-------
11
2 Reading Mode
-------
12
3Check Version, Beep tone, Caplock Mode
-------
13
4Preamble and postamble
-------
14
5Accuracy adjustment
-------
15
6Enable and Disable Code ID
-------
16
7 Symbologies Code Identifier,
-------
17
8~9 Set Code ID, Customer Configuration
-------
18-
19
10 Delay between block and character
-------
20
11 Terminator & keyboard layout
-------
21
12 RS232: Baud rate, Data bits & parity
-------
22
13 RS232: Stop bit, handshaking, ACK/NAK,
Flow Control
-------
23
14 Wand Emulation parameter setting
-------
24
SYMBOLOGY
FORMATTING
( GROUP 15~31)
15 Enable Barcode Symbology
-------
26
16 Disable Barcode Symbology
-------
27
17 China post code ( Toshiba code), Code 32
-------
28
18 UK Plessy code, MSI code
-------
30
19 Code IATA, Code93, Telepen
-------
32
20 Interleaved 2 of 5, Code 11
-------
34
21 Codabar
-------
36
22 ABC Codabar, CX Codabar,
-------
38
23 Codabar Coupling
-------
39
24 Code 128, Standard Code 39, Full ASCII code
39
-------
40
25 Industrial 2 of 5, Matrix 2 of 5
-------
42
26 UPC-E
-------
44
27 UPC-E(0) &(1), UPC-E&UPC-A Expand
-------
45
28 UPC-A
-------
46
29 EAN-8
-------
47
30 EAN-13
-------
48
31 EAN/UCC 128, ISSN, ISBN
-------
49
FULL ASCII (CODE 39 ) TABLE,
FUNCTION CODE TABLE
32~39Full ASCII table ( Code 39)
-------
50-57
40 Numeric table
-------
58
41~42Function code table (Code 39) for PC- AT
-------
59-60
43~46Trouble Shooting
-------
61-63
APPENDIX- A
Default
-------
64
-
66
Cable pinout
-------
67-68
2
GENERAL
INTRODUCTION
This scanner apply with Ez one shot easy programming decoder, It is
specially designed to deliver high-end bar code reading performance
at the lowest possible price. The scanner utilizes exceptional decoding
technology. One-time settings are easily made by scanning set-up bar
codes in this handy user's manual. This bar code scanner uses CCD or
optical diode technology which does not have moving part, provide
ragged reliable quality, enables it suit for any harsh environment
conditions. Furthermore, the LED illumination light source of scanner
provides less harmful beam to human eyes, and more longer product
lifetime.
Notes: ( Please contact your distributor for the detail model number.)
The Ez One shot decoder are mainly apply to the following
categories bar code scanner for your reference:
1. Short Range- The reading distance is about from contact to 100mm,
2. Mid Range- The reading distance is about from contact to180mm,
3. Long Range - The reading distance is about from 5mm to 300mm,
4. Wand or Pen bar code scanner.
5. Scan Engine and Fixed Mount scanner .
This scanner has many settings that can be used to conform the
unit to the requirements of a particular application. For most usages,
however,the default settings programmed into the unit at the factory
are appropriate.It is not recommended that the default settings be
changed unless thereis a specific need to alter the characteristics of
the scanner's performance.
The scanner is easy to install and use. Many problems encountered
can be attributed to a wrong setting that has been programmed into
the scanner. Before troubleshooting the problem, try this:
1. Unplug the cable from the host computer.
2. Plug the cable back into the host computer.
3. Reset the scanner settings to DEFAULT (Group 1).
If these steps do not resolve the problem, please refer to the
troubleshooting table on the next page. If this fails to correct the
problem, please consult the troubleshooting section beginning on
page 61~63 for further assistance.
EZ TROUBLESHOOTING
. A001$
CLONING MODE
.A018$( Cloning Mode on PC/AT) - you can clone the settings to a PC/AT
regardless what kind of device has been chosen on the scanner
. A016$
CLONING MODE
. A018$
CLONING MODE ON- PC/AT
Figure 1
* Format of Cloning :
1st rows >>> ".A017$" ( never edit any data of the first row )
2nd rows >>> "....XXXX" you can adjust the String's Length starting
from the dots"...." forward. The length of the string should
be in 4, 8,12,16 or 20 ( MAX )digits.
3rd rows~ so on >>> XXXX
End rows- A dot "." Is an ending of cloning.
XXXX Stand for any String
FORMAT OF CLONINGFORMAT OF CLONING
NOTES:
4
WHAT IS CLONING MODE?
HOW SHOULD CLONING WORK?
CLONING duplicates a wand's settings in other wands. It can save time
when a number of wands must be programmed to the same settings.
1. Using this guide, make all the necessary settings for one wand.
2. Scan the CLONING MODE bar code shown below.
3. When CLONING MODE is scanned, all setup parameters will be
converted to alphanumeric characters and shown on the monitor.
4. Using a bar code printer, print out all the setup parameters as
Code 39 bar code labels.
5. Scan the printed labels sequentially with each wand to be
programmed.
1. All cloning strings are upper case.
2. All cloning strings printed on labels should be the same as those on
the monitor sequentially from first to last.
3. Cloning mode works in Word Note Pad only.
4. Never edit the data on the first row (.A017$). It is an entry gate for
cloning.
5. The cloning string's length can be adjusted by combining multiple
strings into one, or by breaking one string to multiple strings starting
from the second row after "....". Length must be in sequences of four,
such as 4,8,12,16,20 (MAX).
6. Be sure to print the dots exactly where they are shown on the monitor.
