Fantec QB-X8US3R Manuale utente
8-BAY RAID ENCLOSURE
English
CONTENTS
RAID mode setup / LED display status
SETUP
INITIALIZATION 16 - 20
OVERVIEW
LED indication
Model: QB-X8US3R
REFERENCES 21 - 24
Windows Vista (32 / 64 bit) / Windows 7 (32 / 64 bit)
Macintosh O.S. 10.5
Trouble shooting
1 - 4
5 - 10
16 - 18
19 - 20
11 - 15
LED DISPLAY STATUS
http://www.fantec.de
For questions or needs regarding this device,
please visit our Fantec Support Forum:
http://www.fantec-forum.com/
Please visit our website for more information:
DIAGRAM of QB-X8US3R
FRONT PANEL LED INDICATION
OVERVIEW
1 2
32 56 74 8 9 10
14 15 16 17 18
21 22 23 24 25 26 27 28
19 20
1
11 12 13
1. Power button
It needs to be pressed and held for 3 seconds to power off.
This design prevents accidental power off.
2. eSATA in use / access
3. Rebuild
4. Blue Power on
Orange Sleep mode
5. HDD error When any of HDD1~HDD8 has error,
HDD error is on.
6. USB in use / access
7. 2 X Spanning Mode / BIG (JBOD)
8. Spanning Mode / BIG (JBOD)
9. 2 X RAID 0 Striping Mode
10. RAID 0 Striping Mode
11. 2 X RAID 5
12. RAID 50
13. 2 X RAID 10
14. Smart Fan automatic mode
15. Smart Fan manual mode
16. Fan speed level 1
17. Fan speed level 2
18. Fan speed level 3
19. Mode RAID mode button needs to be pressed and held
for 3 seconds to switch the device's raid mode.
This design will prevent accidental execution of this function.
20. Fan button Controls auto & manual modes
and fan speed from level 1 to level 3.
21.-28. HDD1 / HDD2 / HDD3 / HDD4 / HDD5 / HDD6 / HDD7 / HDD8
Blue active
Purple access
Red rebuild
29. Key slot
29
Descriptions
Descriptions
1. Fan
2. RAID Mode confirmation button
3. eSATA port
4. USB 3.0 / USB 2.0 port
5. AC Input port
6. Lock
HDD HANDLE
3 4
REAR
1
1
2
3
4
KEYS
5
1
2
3
4
5
6
7
8
INSIDE
Descriptions
1. HDD1 error
2. HDD2 error
3. HDD3 error
4. HDD4 error
5. HDD5 error
6. HDD6 error
7. HDD7 error
8. HDD8 error
6
5 65 6
HDD 1
HDD 2
HDD 3
HDD 4
HDD 5
HDD 6
HDD 7
HDD 8
Layer 1
Layer 2
Spanning concatenates multiple hard drives
as a single large volume; resulting in a seamless
expansion of virtual volumes beyond
the physical limitations of separately connected
hard drives. The data are written from HDD1 to HDD8.
Note: The computer will detect 1 drive.
HDD 1 3TB
HDD 2 3TB
HDD 3 3TB
HDD 4 3TB
HDD 5 3TB
HDD 6 3TB
HDD 7 3TB
HDD 8 3TB
12TB
12TB
HDD 1
HDD 2
HDD 3
HDD 4
HDD 5
HDD 6
HDD 7
HDD 8
24TB
HDD 1 3TB
HDD 2 3TB
HDD 3 3TB
HDD 4 3TB
HDD 5 3TB
HDD 6 3TB
HDD 7 3TB
HDD 8 3TB
RAID mode setup, users need to press and HOLD the "RAID" button for
3 seconds till the LED flashes, press again to change the mode.
After selecting the RAID you want, press and HOLD the confirmation
button in the rear panel till the device shuts down.
Mode button
RAID Mode Confirmation button
SETUP
RAID mode setup
Defaut Setting at ”RAID 5” mode.
2x Raid 0 Spanning, is the same like Raid 0 Spanning.
Note: The computer will detect 2 drives.
7 8
HDD 1
HDD 2
HDD 3
HDD 4
HDD 5
HDD 6
HDD 7
HDD 8
Layer 1
Layer 2
HDD1
HDD2
HDD3
HDD4
HDD5
HDD6
HDD7
HDD8
3TB
3TB
3TB
3TB
3TB
3TB
3TB
3TB
Layer 1
9TB
Layer 2
9TB
Distributed parity requires all drives but one to be present to operate;
drive failure requires replacement, but the array is not destroyed
by a single drive failure.
Upon drive failure, any subsequent reads can be calculated
from the distributed parity such that the drive failure is masked
from the end user.0 The array will have data loss in the event
of a second drive failure and is vulnerable until
the data that was on the failed drive is rebuilt onto a replacement drive.
Note: The computer will detect 2 drives.
HDD 1
HDD 2
HDD 3
HDD 4
HDD 5
HDD 6
HDD 7
HDD 8
Layer 1
Layer 2
HDD 1
HDD 2
HDD 3
HDD 4
HDD 5
HDD 6
HDD 7
HDD 8
24TB
HDD 1 3TB
HDD 2 3TB
HDD 3 3TB
HDD 4 3TB
HDD 5 3TB
HDD 6 3TB
HDD 7 3TB
HDD 8 3TB
Striping is a method of concatenating multiple hard drives
into one logical storage unit.
It is the automated process of writing data across
multiple drives simultaneously.
Striping is used to increase the performance of disk reads.
The multiple hard drives will write data in “column” effect.
If one drive in a striped set fails, all of the data
in the stripe set is lost.
Note: The computer will detect 1 drive.
HDD 1 3TB
HDD 2 3TB
HDD 3 3TB
HDD 4 3TB
HDD 5 3TB
HDD 6 3TB
HDD 7 3TB
HDD 8 3TB
12TB
12TB
Layer 1
Layer 2
2x Raid 0 Striping, is the same like Raid 0 striping.
Note: The computer will detect 2 drives.
2x RAID 10 is mirrored (RAID 1) set in a striped (RAID 0) set.
Note: The computer will detect 2 drives.
3TB
3TB
3TB
3TB
3TB
3TB
3TB
3TB
18TB
HDD1
HDD2
HDD3
HDD4
HDD5
HDD6
HDD7
HDD8
Layer 1
Layer 2
9TB
9TB
STRIPING
HDD 1
HDD 2
HDD 3
HDD 4
HDD 5
HDD 6
HDD 7
HDD 8
Layer 1
Layer 2
RAID 50 combines multiple RAID 5 arrays with RAID 0 Striping
RAID 50 offers highest level of redundancy and performance
RAID 50 can sustain one to four drive failures while maintaining data
integrity if each failed disk is in a different RAID 5 array.
In RAID 50, the total addressable volume is 2 times the smallest layer
of RAID 5 array RAID 50 requires at least 6 Hard drives.
Note: The computer will detect 1 drive.
9 10
HDD 1 3TB
HDD 2 3TB
HDD 3 3TB
HDD 4 3TB
HDD 5 3TB
HDD 6 3TB
HDD 7 3TB
HDD 8 3TB
STRIPING
Mirroring
Mirroring
Mirroring
Mirroring
STRIPING
6TB
6TB
HDD 1
HDD 2
HDD 3
HDD 4
HDD 5
HDD 6
HDD 7
HDD 8
Layer 1
Layer 2
Purple / Transferring Data Purple / Transferring Data
LED Display Status
When any of HDD1 ~ HDD8 is recognized by the PC,
HDD1 ~ HDD8 blue / active is on.
Blue / Active
MODE LED Display
Spanning
(BIG)
RAID 0
LED Display Status
Blue / Active
MODE LED Display
When any of HDD1 ~ HDD8 is recognized by the PC,
HDD1 ~ HDD8 blue / active is on.
RAID 0
Striping
11 12
Purple / Transferring Data
Red / Rebuild
When the data is being rebuilt, LED
of rebuild, HDD error and HDD
(1-8, depends on which HDD
is being rebuilt) error will be on.
RAID 50
Striped set
with dedistributed parity
LED Display Status
MODE LED Display
When any of HDD1 ~ HDD8 is recognized by the PC,
HDD1 ~ HDD8 blue / active is on.
Blue / Active
213 14
Purple / Transferring Data
Red / Rebuild
When the data is being rebuilt, LED
of rebuild, HDD error and HDD
(1-8, depends on which HDD
is being rebuilt) error will be on.
LED Display Status
MODE LED Display
When any of HDD1 ~ HDD8 is recognized by the PC,
HDD1 ~ HDD8 blue / active is on.
Blue / Active
Striped set
with distributed parity
RAID 5
Purple / Transferring Data
Red / Rebuild
When the data is being rebuilt, LED
of rebuild, HDD error and HDD
(1-8, depends on which HDD
is being rebuilt) error will be on.
RAID 10
Mirroring + Striping
LED Display Status
MODE LED Display
When any of HDD1 ~ HDD8 is recognized by the PC,
HDD1 ~ HDD8 blue / active is on.
Blue / Active
INITIALIZATION
15 16
Windows Vista (32 / 64 bit) / Windows 7 (32 / 64 bit)
If the HDD is uninitialized, you may have to initialize
it by doing steps as followed:
At first click “Start”, “Execute” at your PC
and key in “diskmgmt.msc”.
After that please press “Enter” key.
Windows Vista (32 / 64 bit) / Windows 7 (32 / 64 bit)
Activate MBR if total volume is less than 2TB
Note: Please enable GPT if the total capacity is more than 2TB and enable MBR if the
total capacity is less than 2TB.
Start disk initialization.
Windows Vista (32 / 64 bit) / Windows 7 (32 / 64 bit)
17 18
Windows Vista (32 / 64 bit) / Windows 7 (32 / 64 bit)
Disk format completed.
Under Windows Vista (32/64-bit), if the total capacity is more than 16TB,
it's strongly recommend to choose “Allocation unit size” at 8192
when formatting the HDD.
Users could find more information about cluster allocation
at：http://support.microsoft.com/kb/302873
Cluster size Maximum NTFS Volume size (bytes RAW)
512 2,199,023,255,040 (2TB)
1.024 4,398,046,510,080 (4TB)
2.048 8,796,093,020,160 (8TB)
4.096 17,592,186,040,320 (16TB)
8.192 35,184,372,080,640 (32TB)
16.384 70,368,744,161,280 (64TB)
32.768 140,737,488,322,560 (128TB)
65.536 281,474,976,645,120 (256TB)
Create new partition and format disk.
Activate GPT if total volume is more than 2TB
