FARMSTREAM 4G Static Manuale
4G Static
5MP Camera
Setup Instructions
©Farmstream LTD 2023
Farmstream 4G Static
5MP Camera Setup
STEP 1
Check your box for:
©Farmstream LTD 2023
1 x 4G Static Camera
2 x Antennas
1 x 3-pin plug adapter
1 x Screw pack (not pictured)
1 x Giffgaff SIM (not pictured)
2
STEP 2
©Farmstream LTD 2023 3
SIM card activation:
A.
B.
C.
D.
E.
F.
G.
Using a mobile phone, download the giffgaff app.
Open the giffgaff app and select ‘Activate SIM’ (you will then be redirected to a
web browser page).
Enter the activation code which is the 6 digit code written on the plastic SIM
card holder.
Select to activate SIM and enter your personal details.
Select to register.
Either add credit or select a goodybag option. We recommend starting with
the £10 goodybag (you can adjust this at a later date).
Fill in the required payment details and select to add date to your SIM.
Note: Our cameras are unlocked and can be used with any SIM card provider. For
alternative providers, such as Vodafone, the camera cannot always automatically
retrieve the correct network settings. It may then require the APN settings to be
manually updated. This is a straightforward process, and we have specific instructions
on how to do this available on the setup page of our website.
STEP 3
Inserting SIM card & SD card (SD card optional):
A.
B.
C.
Use the Allen key provided to carefully remove the back access panel.
Insert the SIM card and SD card (if using) as shown below. When inserted
correctly, each of these will gently click into place.
Replace the back access panel.
SD Card
4G SIM
STEP 4
Antenna attachment:
A. Carefully screw the two antennas into place, making sure they
are tightly screwed into place.
©Farmstream LTD 2023 4
Power
Reset
button Audio
STEP 5
A.
Power on your new camera:
There are four cables coming out the
back of the camera (as below).
Connect the power cable to the
power lead coming out the back of
the camera. This will be the 3-pin plug
adapter if powering the camera via
mains or this will be a 12V battery
connection cable if powering the
camera via a 12V battery.
A.
B.
C.
STEP 6
Connecting your camera to the CamHiPro app:
Use your mobile phone to access the App / Google Play store and
download a free app called ‘CamHiPro’.
Once downloaded, open CamHipro and give it full permissions.
The following steps can be used to connect your 4G Static to the
CamHiPro app:
©Farmstream LTD 2023 5
1. Select
'Add Camera'
2. Select
'IP Camera'
3. Select
'Device in Use'
4. Select ‘Scan QR code’
and scan the QR code
on the side of the camera
5. Select
'Add to'
6. Name your camera
and select 'confirm'
7. Tap on your camera
to bring it online,
and tap again to view
8. Follow the
tutorial
Note: Ensure you scan the QR code on your camera displayed next to your UID
code (Your UID code will be a 15-digit code. Example: SSAA-534834-ACABA)
©Farmstream LTD 2023
Your 4G Static Camera is now
setup, and you’ll be able to view
footage wherever you are using
your mobile phone. Feel free to
unplug your camera and mount it
where you want to use it before
reconnecting to power.
Any questions regarding setup?
Drop us an email at
support@farmstream.co.uk,
including your order number and a
brief description of the problem so
we can get the best person to help
figure out what is going wrong.
We also have a troubleshooting
section on our website:
https://www.farmstream.co.uk/tro
ubleshooting
