Fein WBP10 Series Guida all'installazione

WBP10

Repair instructions

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 1of 39

WBP10

Contents

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 2of 39

1. Models described

2. Technical data

3. Notes and requirements

4. Tools required

5. Lubricants and auxiliary substances required

6. Removal

7. Fitting

8. Connection diagram

WBP10

1. Models described

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 3of 39

These repair instructions describe how to repair the following models:

Model Order number

WBP10 7 205 51 …

WBP10

2. Technical data

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 4of 39

Technical data

All the technical data can be found in the operating instructions for the model.

Test data

Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service →Repair Guides).

Lubricants

The lubricants and container sizes available from FEIN can be found on the FEIN Extranet (Customer Service →Repair Guides).

Lists of spare parts

Lists of spare parts and exploded views are available online at www.fein.com

WBP10

3. Notes and requirements

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 5of 39

Please note

These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and

electrical training.

Only use original FEIN spare parts.

Provisions

Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in

serious risks to the user.

The provisions set out in DIN VDE 0701-0702 should be observed after repairs.

The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when

commissioning.

The German Equipment and Product Safety Act [ProdSG] applies for correct use.

Outside Germany, the regulations applicable in the relevant country must be observed.

WBP10

4. Tools required

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 6of 39

Standard tools

Special tools

Torx T20 Assembly aid 6 41 22 121 01 0

Cross-tip screwdriver PH1, PH2 Expansion wedge, 12 mm 6 33 05 009 01 3

Slotted screwdriver (small) Drawing-off socket cap 6 41 04 150 00 8

Circlip pliers Chuck cone, dia. 16 mm 6 41 07 016 00 1

Plastic hammer Chuck cone, dia. 17 mm 6 41 07 017 00 0

Arbor press Chuck cone, dia. 19 mm 6 41 07 019 00 7

Punch Chuck cone, dia. 22 mm 6 41 07 022 00 1

Long-nosed pliers Chuck cone, dia. 26 mm 6 41 07 026 00 0

Drill chuck key

Cylinder head screw M8x60

Sleeve Inner dia. 11 mm

Outer dia. 26 mm

Inner dia. 16 mm

Outer dia. 20 mm

Inner dia. 12 mm

Outer dia. ~16 mm

Inner dia. 10 mm

Outer dia. 26 mm

WBP10

4. Tools required

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 7of 39

Standard tools

Sleeve Inner dia. 9 mm

Outer dia. 22 mm

Inner dia. 12 mm

Outer dia. ~15 mm

Inner dia. 16 mm

Outer dia. ~25 mm

Inner dia. 5 mm

Outer dia. 15 mm

Inner dia. 13 mm

Outer dia. 25 mm

Inner dia. 8 mm

Outer dia. ~17 mm

Inner dia. 8 mm

Outer dia. ~19 mm

WBP10

5. Lubricants and auxiliary substances required

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 8of 39

Lubricants

Grease 0 40 101 0100 4 25 g Housing

WBP10

6. Removal

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 9of 39

Removing the handle half shell

1. Remove the key-type drill chuck (1).

2. Unscrew the three screws (2).

3. Unscrew the countersunk screw (3).

4. Remove the switch pushbutton (4).

5. Remove the handle half shell (5).

Tools:

- M8x60 cylinder head

screw

- 6 mm hex key

- Drill chuck key

- PH2 cross-tip

screwdriver

WBP10

6. Removal

C-SC_CSSM

Version 1.0

2015-05-22

FEIN retains all rights of disposal, such as copying and circulation.

Page 10 of 39

Removing the cable with plug

1. Unscrew the screw (1).

2. Remove the cable clamping piece (2).

3. Remove the speed setting switch (3).

4. Undo the two screws (4) and remove the cable with plug.

Tools:

- PH2 cross-tip

screwdriver
