Fein KBM 50 Q Guida all'installazione
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 1/79Version 1.0
Repair instructions
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 2/79Version 1.0
1. Models described
2. Technical data
3. Notes / requirements
4. Tools required
5. Lubricants and auxiliary substances required
6. Disassembly
7. Assembly
8. Troubleshooting
9. Connection diagram
Contents
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 3/79Version 1.0
These instructions describe how to repair the following models:
Model
Order no.
KBM 50 Q
7 27 04 100 23 0
JCM 200QX
7 27 04 512 36 0
1. Models described
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 4/79Version 1.0
2. Technical data
Technical data
The complete technical data can be found in the operating instructions for the model.
Test data
Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lubricants
The lubricants and container sizes available from FEIN can be found on the FEIN Extranet (Customer Service
→ Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 5/79Version 1.0
3. Notes / requirements
Note
These instructions are only intended for persons with suitable technical training. It is assumed
that the reader has mechanical and electrical training.
Only use original FEIN spare parts!
Requirements
Please note that power tools may only be repaired, maintained and checked by a trained
electrician, as improper repair can result in serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employers’ liability insurance associations are
to be observed when commissioning.
The German Equipment and Product SafetyAct applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed!
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 6/79Version 1.0
4. Tools required
Standard tool
Special tool
Order number
- Torx 15 and 20 screwdrivers
- 2 x cross screwdriver
- Slotted screwdriver
- Socket wrenches: sizes 2.5; 3; 4; 5
- Arbor press
- Plastic hammer
- Punch
- Rubber hammer
- Circlip pliers for
inner and outer rings
- Inner bearing puller, 6-10 mm
- Inner bearing puller, 12-16 mm
- Inner bearing puller, 18-22 mm
- Drift key
6 33 05 003 00 3
- Press-on fixture
6 41 01 019 00 8
- Drawing-off socket cap
6 41 04 150 00 8
- Chuck cone
19 mm
26 mm
6 41 07 019 00 7
6 41 07 026 00 0
- Hook
6 41 22 121 01 0
NOTE
You can only order special tools with an order number from FEIN.
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 7/79Version 1.0
4. Tools required
Standard tool
- Sleeve
Outer diameter
Inner diameter
~65 mm
55 mm
Outer diameter
Inner diameter
~55 mm
40 mm
Outer diameter
Inner diameter
~35 mm
25 mm
Outer diameter
Inner diameter
28 mm
~21 mm
Outer diameter
Inner diameter
21 mm
~10 mm
Outer diameter
Inner diameter
~25 mm
15 mm
Outer diameter
Inner diameter
30 mm
~15 mm
Outer diameter
Inner diameter
30 mm
~26 mm
NOTE
You can only order special tools with an order number from FEIN.
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 8/79Version 1.0
4. Tools required
Standard tool
- Sleeve
Outer diameter
Inner diameter
~53 mm
45 mm
- Ball bearing support
19 mm
26 mm
- Base
Height
Width
22 mm
~20 mm
NOTE
You can only order special tools with an order number from FEIN.
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 9/79Version 1.0
5. Lubricants and auxiliary substances required
Lubricants
Grease
0 40 106 0100 1
6 g
NILOS ring, sealing rings, shaft (spider), guide
Grease
0 40 118 0300 9
120 g
Gearbox
KBM 50Q; JCM 200QX
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
C-SC_CSSM 2013.02 10/79Version 1.0
1. Remove container (1).
6. Disassembly
Disassembling container
1
