Fein BSS 1.6 E Guida all'installazione
BSS 1.6E, BSS 1.6CE
Repair instructions
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 1of 33
BSS 1.6E BSS 1.6CE
BSS 1.6E, BSS 1.6CE
Contents
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 2of 33
1. Models described
2. Technical data
3. Notes and requirements
4. Tools required
5. Lubricants and auxiliary substances required
6. Disassembly
7. Assembly
8. Troubleshooting
9. Connection diagram
Es wurden keine Einträge für das Inhaltsverzeichnis gefunden.
BSS 1.6E, BSS 1.6CE
1. Models described
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 3of 33
These instructions describe how to repair the following models:
Model Order number
BSS 1.6E 7 230 31 00 23 0
BSS1.6CE 7 230 32 00 23 0
BSS 1.6E, BSS 1.6CE
2. Technical data
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 4of 33
Technical data
The complete technical data can be found in the operating instructions for the model.
Test data
Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lubricants
The lubricants and container sizes available from FEIN can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com
BSS 1.6E, BSS 1.6CE
3. Notes and requirements
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 5of 33
Note
These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and
electrical training.
Only use original FEIN spare parts!
Provisions
Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in
serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employers' liability insurance associations are to be observed when
commissioning.
The German Equipment and Product Safety Act applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed!
BSS 1.6E, BSS 1.6CE
4. Tools required
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 6of 33
Standard tools
Special tool
Hex key 2.5mm; 4mm Drawing-off socket cap 6 41 04 150 00 8
Plastic mallet 16mm chuck cone 6 41 07 016 00 1
Torx screwdriver T15 19mm chuck cone 6 41 07 019 00 1
Slotted screwdriver 26mm chuck cone 6 41 07 026 00 0
Slotted screwdriver (small) Press-in fixture 6 41 22 108 00 0
Phillips head screwdriver Hook 6 41 22 108 00 0
Circlip pliers
Punch
Arbor press
Sleeves 6mm internal Ø
7mm internal Ø
Ball bearing support 19mm; 26mm
BSS 1.6E, BSS 1.6CE
5. Lubricants and auxiliary substances required
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 7of 33
Lubricants
Grease 0 40 101 0100 4 12 g Gearbox
BSS 1.6E, BSS 1.6CE
6. Disassembly
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 8of 33
Disassembling the motor
1. Pull the plug.
2. Remove the three screws (1) and take off the cover (2).
3. Unscrew the brush holder (3).
4. Unscrew the cable clamping piece (4).
5. Unplug the screw connections between the motor and electronics.
6. Remove the electronics (5).
7. Disconnect the supply cable (6).
Tool:
- Phillips head
screwdriver
- Torx T15
5
4
3
6
1
2
BSS 1.6E, BSS 1.6CE
6. Disassembly
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 9of 33
Separating the motor and gearbox
1. Unscrew the two cylinder head screws (1).
2. Remove the shear head (2).
3. Unscrew the four screws (3).
4. Remove the intermediate flange with armature (4).
5. Remove the air guide ring (5).
Tool:
- 4mm hex key
- Torx T15
1
3
2
4
5
BSS 1.6E, BSS 1.6CE
6. Disassembly
C-SC_CSSM
Version 1.0
2013-07-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 10 of 33
Disassembling the stator
1. Lift up the slide switch (1) with a slotted screwdriver.
2. Unscrew the two screws (2).
3. Drive the field coil out of the motor housing by tapping it gently with the mallet.
Tool:
- Slotted screwdriver
- Torx T15
- Plastic mallet
1
2
