Flex-a-Lite Black Magic 155 Manuale utente

Mounting Instructions-155 may be

installed horizontally or vertically to the

radiator

Assemble the brackets and threaded rods to the 155

fanaccordingtothespecificapplicaiton.Mountthe

155withbracketsusingeitherthebolt-onorclamp-on

method.

Clamp-on Method

Star Nut

Washer

Black Magic

Be sure to use star nuts to stabilize the threaded rods.

Do not over tighten to the radiator,damage may occur.

Bolt-on Method

Radiator(Front)

Nut



Threaded

Rod



Bracket

Radiator

Channel



Notes:

155

revised 01-02-06 99155

The Flex-a-lite Limited Warranty

Flex-a-lite Consolidated, 7213-45th St. Ct. E. Fife, WA 98424, Telephone No. 253-922-2700, warrants to the original purchasing user, that all Flex-a-lite products to be free of

defects in material and workmanship for a period of 365 days (1 year) from date of purchase. Flex-a-lite products failing within 365 days (1 year) from date of purchase may

be returned to the factory through the point of purchase, transportation charges prepaid. If, on inspection, cause of failure is determined to be defective material or workmanship

and not by misuse, accidental or improper installation, Flex-a-lite will replace the fan free of charge, transportation prepaid. Flex-a-lite will not be liable for incidental,

progressive or consequential damages. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may

not apply to you. This warranty gives you specific legal rights and you may have other rights, which vary from state to state.

The Flex-a-lite warranty is in compliance with the Magnuson-Moss Warranty Act of 1975.

This model does not include thermostatic control

Red motor wire should be positive +. Black motor wire should be negative -

Washer

This fan is designed to mount as a puller.
