Flexitron WebdynEasy W M-Bus Manuale utente

WebdynEasy W M-Bus 868MHz

User Manual

www.webdyn.com

contact@webdyn.com | webdyn.com

V2.0 subject to changes | Webdyn © by Flexitron Group

Index

1. Glossary................................................................................................................................................. 5

2. About this Document............................................................................................................................ 7

2.1 Scope ........................................................................................................................................ 7

2.2 Target Audience........................................................................................................................ 7

2.3 Product Versions ...................................................................................................................... 7

User Manual ..................................................................................................................... 9

1. Presentation.......................................................................................................................................... 9

1.1 General Description ................................................................................................................. 9

1.2 Operating Principle................................................................................................................... 9

1.3 Interfaces (old and new).......................................................................................................... 10

1.4 Supported Equipment.............................................................................................................. 12

1.5 Product and Accessory References ........................................................................................ 12

1.6 Technical Specications .......................................................................................................... 12

1.6.1 General Specications ............................................................................................... 12

1.6.2 Technical Specications............................................................................................. 13

1.6.3 Software Specications ............................................................................................. 16

1.6.4 Battery Life.................................................................................................................. 16

1.7 Safety Instructions ................................................................................................................... 18

1.8 Regulations............................................................................................................................... 19

2. Installation ............................................................................................................................................ 20

2.1 Prerequisite ............................................................................................................................. 20

2.2 Unpacking................................................................................................................................. 20

2.2.1 Contents...................................................................................................................... 20

2.2.2 Identication ............................................................................................................... 20

2.3 Assembly................................................................................................................................... 22

2.3.1 Opening/Closing the Box ........................................................................................... 22

2.3.2 Wall Mounting............................................................................................................. 22

2.4 Interface Description ............................................................................................................... 23

2.4.1 Product Power Supply................................................................................................. 23

2.4.2 Radio ........................................................................................................................... 25

contact@webdyn.com | webdyn.com

V2.0 subject to changes | Webdyn © by Flexitron Group

2.4.3 Cellular Network ........................................................................................................ 26

2.4.4 Indicators & Buttons .................................................................................................. 28

2.4.5 USB Interface.............................................................................................................. 29

2.4.6 Bluetooth Interface (BLE)........................................................................................... 30

3. Product Operation................................................................................................................................. 31

3.1 Starting the Product................................................................................................................. 31

3.1.1 Operating Mode .......................................................................................................... 31

3.1.2 Application Operation................................................................................................. 35

4. Conguration......................................................................................................................................... 37

4.1 Local Conguration .................................................................................................................. 37

4.1.1 USB .............................................................................................................................. 37

4.1.2 Bluetooth (BLE)........................................................................................................... 37

4.2 Conguration File ..................................................................................................................... 39

4.2.1 System......................................................................................................................... 39

4.2.2 W M-Bus radio ............................................................................................................ 43

4.2.3 Hub Connectivity......................................................................................................... 48

4.2.4 Alarms ......................................................................................................................... 54

4.2.5 Schedule and Monitoring........................................................................................... 55

5. Operation............................................................................................................................................... 61

5.1 The Remote Server................................................................................................................... 61

5.1.1 The FTP Server............................................................................................................ 61

5.2 The Conguration..................................................................................................................... 64

5.3 The Data ................................................................................................................................... 66

5.4 Alarms....................................................................................................................................... 68

5.5 ACK Acknowledgements.......................................................................................................... 69

5.6 Commands ............................................................................................................................... 71

5.6.1 “Request” Command.................................................................................................. 73

5.6.2 “Factory” Command................................................................................................... 74

5.6.3 “Firmware” Command................................................................................................ 74

5.6.4 “Diag” Command........................................................................................................ 74

5.6.5 “CongGet” Command............................................................................................... 75

5.6.6 “whiteListErase” Command....................................................................................... 75

contact@webdyn.com | webdyn.com

V2.0 subject to changes | Webdyn © by Flexitron Group

5.6.7 “operatorInit” Command............................................................................................ 76

5.6.8 “logGet” Command .................................................................................................... 76

5.6.9 “logClean” Command................................................................................................. 77

5.6.10 “supervisionClean” Command ................................................................................ 77

5.6.11 “supervisionGet” Command.................................................................................... 78

5.6.12 “certicate” Command ............................................................................................ 78

5.6.13 “certClean” Command............................................................................................. 79

5.7 Supervision............................................................................................................................... 79

5.8 The Log ..................................................................................................................................... 86

6. Update ................................................................................................................................................... 88

6.1 Local.......................................................................................................................................... 89

6.2 Remote...................................................................................................................................... 89

7. Tools & Diagnostics............................................................................................................................... 90

8. FAQ......................................................................................................................................................... 91

9. Appendix................................................................................................................................................ 92

9.1 Conguration - Variable list...................................................................................................... 92

Ofces & Support Contact............................................................................................... 96

contact@webdyn.com | webdyn.com

V2.0 subject to changes | Webdyn © by Flexitron Group

1. Glossary

NAME DESCRIPTION

APN Access Point Name: the name of the access point the gateway uses to connect to

the Internet via a mobile connection.

AES Advanced Encryption Standard: synthetic encryption algorithm.

BLE Bluetooth Low Energy: wireless transmission technique in the form of a Bluetooth-

based open standard, characteristically having much lower power consumption.

Base64 Encoded data using an alphabet with 64 characters.

BSON Binary JSON: binary version of JSON: encoding used to reduce the size of

transmitted data to save stand-alone system batteries.

FTP File Transfer Protocol: communication protocol used to exchange les over a TCP/

IP network.

FTPS File Transfer Protocol Secure: communication protocol intended for the computer

exchange of les on a TCP / IP network, variant of FTP, secured with SSL or TLS

protocols. It allows visitors to verify the identity of the server they are accessing

using an authentication certicate. It also makes it possible to encrypt the

communication.

2G Second generation: second generation digital standard (2G) for mobile telephony

including GSM, GPRS and EDGE.

HTTP HyperText Transfer Protocol: client-server communication protocol developed for

the Web.

IP Internet Protocol: message protocol in charge of addressing and sending TCP

packets over the network.

JSON JavaScript Object Notation: JSON is an easily interpretable data exchange format.

LTE-M/

CAT-M1

Long Term Evolution – Machine: 4G mobile network specic to connected objects,

i.e. low consumption and long range.

NB-IoT NarrowBand - Internet of Things: 4G mobile network dedicated to connected

objects, i.e. low consumption and long range.

NTP Network Time Protocol: an NTP server makes it possible to time synchronise

equipment.

contact@webdyn.com | webdyn.com

V2.0 subject to changes | Webdyn © by Flexitron Group

IS Information System: server with which the hub exchanges (conguration, data,

alarms, etc.).

TCP Transmission Control Protocol: an Internet-based connection-oriented protocol

that provides data packet segmenting services that the IP protocol sends over the

network. This protocol provides a reliable data transfer service. See also IP.

TCP/IP Transmission Control Protocol/Internet Protocol: a set of network protocols

that provide interconnection services between computers of different

hardware architectures and operating systems. TCP/IP includes standards for

communication between computers and conventions for network interconnection

and routing.

W M-BUS Wireless M-Bus: evolution of the European Mbus standard in a radio frequency

adaptation. This connectivity is specic to metering applications such as: water,

gas and electricity meters.

contact@webdyn.com | webdyn.com

V2.0 subject to changes | Webdyn © by Flexitron Group

2. About this Document

This guide describes all features of the WebdynEasy W M-Bus product.

Its purpose is to help operators install and congure their WebdynEasy W M-Bus and to allow operating

entities to include the collected data in their IS.

This manual is split into six separate sections:

• Section 1: General presentation

• Section 2: Installation

• Section 3: Conguration

• Section 4: Operation

• Section 5: Tools & diagnostics

• Section 6: FAQ

2.1 Scope

This technical description is valid for WebdynEasy W M-Bus hubs from hardware version V1 and software

version V1.0 onwards.

2.2 Target Audience

This guide is for on-site installers who will cable and congure the installations, for those in charge of

local or remote maintenance of the installations, and for developers of portals to use the sent data.

2.3 Product Versions

VERSION CONTENT

V1.0 Creation.

V1.1 Modication of the functioning of the product regards the magnet and the

number of bips. Adding of a scheme concerning le management.

V1.2 Addition and Modication on the supervision part. Adding autonomy.

V1.3 Additions in the glossary, modication of the command le.

V1.4 Additions on Field L for B format frames.

V1.5 Details on the data parameter F and on the diagnostic mode, adjustment of

the/scheduleRadio/data range.

contact@webdyn.com | webdyn.com

V2.0 subject to changes | Webdyn © by Flexitron Group

V1.5 Added multi listening mode. Changed example of “wlFilter”. Changed

example command “diag”. Added “cid” in all commands. Added

“supervisionGet” command. Changed the “update” command to “rmware”.

Modication of the “congGet” command.

V2.0 Added NB-IoT

Adding supervision variables

Addition and presentation of the new case

Added network unregistration by magnet

Added certicate management commands

Added radio conguration (longHeader, skipVersionField and

skipMediumField)

Addition of commercial reference without BLE

Added clarication on the use of the whiteList

contact@webdyn.com | webdyn.com

V2.0 subject to changes | Webdyn © by Flexitron Group

User Manual

1. Presentation

1.1 General Description

The purpose of the WebdynEasy W M-Bus hub is to collect data from Wireless M-Bus sensors such as

meters (water, gas and electricity) and sensors (temperature, humidity, etc...). This technology is energy-

efcient, the hub battery service life can exceed 10 years.

Data collection is by radio on the 868MHz frequency. This frequency is free of charge and its use is

harmonised in many EU countries.

The collected information (data, parameters, alarms, ...) is formatted to BSON format before being sent

to an information system (IS) by modem.

1.2 Operating Principle

WebdynEasy W M-Bus allows you to build your private network and is part of a package. WM-Bus

communication is point-to-point in a non-operated way. The meters or sensors regularly send data frames,

which are received and the raw data (encrypted or transparent) contained in these frames are stored by

the WM-Bus hub. WebdynEasy W M-Bus will regularly send a le in BSON format containing the whole raw

data of the different sensors to a server via FTP using its LTE-M/NB-IoT/2G or modem. It is possible to

secure the exchanged les between the WebdynEasy W M-Bus and the FTP server by activating the AES

encryption (see chapter 4.2.1.2 : “security”).

NB, LTE-M, 2G

cellular network

Other W M-Bus

equipment

WebdynEasy W M-Bus

868MHz

Water and

electricity meters

Server User

Wireless M-Bus

888888

It is possible to congure the WebdynEasy by connecting it by USB to a computer or by BLE using a

smartphone application.

contact@webdyn.com | webdyn.com

1.3 Interfaces (old and new)

Old Interfaces:

1. HALL effect sensor

2. Buzzer

3. Mini-USB connector

4. Indicators:

• LED 1: reserved

• LED 2: reserved

• LED 5: Modem status

5. 868MHz radio SMA antenna

6. Box output for the 868MHz radio external antenna (optional)

7. Battery Pack

8. Battery pack connector

9. Aerator

10. Box output for external power supply (optional)

11. Terminal block for external 12 V power supply

12. Box output for the LTE-M/NB-IoT/2G modem external antenna (optional)

13. LTE-M/NB-IoT/2G Modem SMA Antenna

14. Reset button

15. SIM card holder

Altri manuali per WebdynEasy W M-Bus

Indice

Altri manuali Flexitron Portale

Flexitron

Flexitron WebdynPulse WG0510-A01 Manuale utente

Flexitron

Flexitron Webdyn WebdynEasy LoRaWAN Manuale utente

Flexitron

Flexitron Webdyn WebdynEasy W M-Bus Manuale utente

Flexitron

Flexitron Webdyn ExpertLoRaWAN Manuale di installazione

Manuali Portale popolari di altre marche

LST

LST M500RFE-AS Manuale utente

Kinnex

Kinnex Media Gateway Manuale utente

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuale utente

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuale utente

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuale utente

Telsey

Telsey CPVA 500 - SIP Manuale utente

RTA

RTA 460A-NNA4 Scheda tecnica

Shaw

Shaw Gateway HDPVR Manuale utente

ABB

ABB VSN900 Guida rapida

Commander

Commander Pulse Manuale utente

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuale utente

NETGEAR

NETGEAR C6300BD Manuale utente

Amit

Amit CDW531AM Manuale utente

HMS

HMS Netbiter EasyConnect EC150 Manuale utente

Huawei

Huawei EchoLife HG620 Manuale utente

AT&T

AT&T U-verse 3801 Manuale per l'uso e la cura

Logic IO

Logic IO RTCU MX2 turbo Manuale utente

Suttle

Suttle MediaMAX MXM-521 Manuale utente
