Fluke 64 max Manuale utente

PN 4861406

January 2017

All product names are trademarks of their respective companies.

64 Max

IR Thermometer

Instructions

Introduction

The Fluke 64 Max IR Thermometer (the Product) can determine the surface temperature by

measuring the amount of infrared energy radiated by the target’s surface.

Warning

Read all safety information before you use the Product.

3-Year Limited Warranty. See the Users Manual for the full warranty.

Go to www.fluke.com to read the Users Manual and find more information about

the Product. To register your product, visit http://register.fluke.com.To see, print,

or download the latest manual supplement, visit http://us.fluke.com/usen/support/manuals.

Safety Information

A Warning identifies conditions and procedures that are dangerous to the user. A Caution

identifies conditions and procedures that can cause damage to the Product or the equipment

under test.

Warning

To prevent eye damage and personal injury:

•Read all safety Information before you use the Product.

•Do not use the Product if it operates incorrectly.

•Use the Product only as specified, or the protection supplied by the

Product can be compromised.

IR Thermometer

Safety Information

•Before you use the Product, inspect the case. Do not use the Product if it

appears damaged. Look for cracks or missing plastic.

•See emissivity information for actual temperatures. Reflective objects

result in lower than actual temperature measurements. These objects

pose a burn hazard.

•Do not look directly into the laser with optical tools (for example,

binoculars, telescopes, microscopes). Optical tools can focus the laser

and be dangerous to the eye.

•Do not look into the laser. Do not point laser directly at persons or

animals or indirectly off reflective surfaces.

•Replace the batteries when the low battery indicator shows to prevent

incorrect measurements.

•Do not use the Product around explosive gas, vapor, or in damp or wet

environments.

•Use the Product only as specified or hazardous laser radiation exposure

can occur.

Caution

•To avoid damage to the Product, do not leave the thermometer on or

near objects of high temperature.

64 Max

Instructions

Table 1 lists the symbols used on the Product and in this manual.

Table 1. Symbols

Symbol Meaning Symbol Meaning

WARNING. RISK OF DANGER. Warning. Laser.

Consult user documentation. Conforms to European Union

directives.

Conforms to relevant Australian EMC standards.

Indicates a Class 2 laser. DO NOT STARE INTO BEAM. The following text

may appear with the symbol on the product label: “IEC/EN 60825-1

Complies with 21 CFR 1040.10 and 1040.11 except for deviations

pursuant to Laser Notice 50, dated June 24, 2007.” In addition, the

following pattern on the label will indicate wavelength and optical power:

λ= xxxnm, x.xxmW



This product complies with the WEEE Directive marking requirements. The

affixed label indicates that you must not discard this electrical/electronic

product in domestic household waste. Product Category: With reference to

the equipment types in the WEEE Directive Annex I, this product is classed

as category 9 "Monitoring and Control Instrumentation" product. Do not

dispose of this product as unsorted municipal waste.

IR Thermometer

Safety Information

Table 2. Nominal Surface Emissivity

Material Value Material Value

Default**** 0.95 Glass 0.85

Aluminum* 0.30 Iron* 0.70

Asbestos 0.95 Lead* 0.50

Asphalt 0.95 Oil 0.94

Brass* 0.50 Paint 0.93

Ceramic 0.95 Plastic** 0.95

Concrete 0.95 Rubber 0.95

Copper* 0.60 Sand 0.90

Food-Frozen 0.90 Steel* 0.80

Food-Hot 0.93 Water 0.93

Wood 0.94

* Oxidized

** Opaque, over 20 mils

*** Natural

**** Factory Setting

64 Max

Instructions

Specifications

Temperature Range -30 °C to +600 °C

Accuracy

(Calibration geometry with ambient

temperature 23 °C ±2 °C)

≥0 °C: ±1 °C or ±1 % of reading, whichever is

greater

≥-10 °C to <0 °C: ±2 °C

< -10 °C: ±3 °C

Response Time (95 %) <500 ms (95 % of reading)

Spectral Response 8 microns to 14 microns

Emissivity 0.10 to 1.00

Temperature Coefficient ±0.1 °C/°C or ±0.1 %/°C of reading (whichever is

greater)

Optical Resolution 20:1

(calculated at 90 % energy)

Display Resolution 0.1 °C

Repeatability (% of reading) ±0.5 % of reading or ±0.5 °C, whichever is greater

Power 1 AA IEC LR06 Battery

Battery Life 30 hours with laser and backlight on

IR Thermometer

Specifications

Weight 255 g

Size 175 x 85 x 75 mm

Operating Temperature 0 °C to 50 °C

Storage Temperature -20 °C to +60 °C, (without battery)

Operating Humidity

Non Condensing (≤10 °C)

≤90 % RH (at 10 °C to 30 °C)

≤75 % RH (at 30 °C to 40 °C)

≤45 % RH (at 40 °C to 50 °C)

Operating Altitude 2000 meters above mean sea level

Storage Altitude 12 000 meters above mean sea level

Safety

General IEC 61010-1: Pollution Degree 2

Laser IEC 60825-1: Class 2, 650 nm, <1 mW

Ingress Protection IEC 60529: IP54

64 Max

Instructions

Electromagnetic Compatibility

International ........... IEC 61326-1: Portable; IEC 61326-2-2; CISPR 11: Group 1, Class A

Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio

frequency energy that is necessary for the internal function of the equipment itself.

Class A: Equipment is suitable for use in all establishments other than domestic and those

directly connected to a low-voltage power supply network that supplies buildings used for

domestic purposes. There may be potential difficulties in ensuring electromagnetic

compatibility in other environments due to conducted and radiated disturbances.

Caution: This equipment is not intended for use in residential environments and may not

provide adequate protection to radio reception in such environments.

Korea (KCC) .......................................Class A Equipment (Industrial Broadcasting &

Communication Equipment)

Class A: Equipment meets requirements for industrial electromagnetic wave equipment and

the seller or user should take notice of it. This equipment is intended for use in business

environments and not to be used in homes.

USA (FCC) .........................................47 CFR 15 subpart B. This product is considered an

exempt device per clause 15.103.

IR Thermometer

Overview

To turn on the Product, pull the trigger.

iba02.eps

64 Max

Instructions

iba01.eps
