Flycam GL-020-00 Manuale utente
Truecam Fluid Motion Head
(GL-020-00)
I N S T R U C T I O N M A N U A L
All rights reserved
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, except as may be expressly permitted
by the applicable copyright statutes or in writing by the Publisher.
FLYCAM TRUECAM FLUID MOTION HEAD 2
INTRODUCTION
Flycam Truecam is a gimbal which is masterfully designed for Handheld Stabilizers and to keeps
the camera horizontal no maer how you move the stabilizer. Truecam completely isolates roll
of the camera. Now you can move from high mode to low modeand back again, in one single
uid, cinemac shot while your camera automacally remains level and horizontal at all mes.
This CNC Aluminum constructed Flycam gimbal when combines with the Flycam stabilizers
provides stable videos. You can evenrotate the stabilizer a full 360°,and the camera will keep its
posion the enre me. Its custom sensors, powerful motors and advanced algorithms
put world-class precision in your hands.
IN THE BOX
lease inspect the contents of your shipped package to ensure you have received all that is
pictured and listed below.
Truecam Head with 1/4"-20
Camera Bolt
USB Cable
ASSEMBLING YOUR TRUECAM FLUID MOTION HEAD
Aach the truecam with your stabilizer camera plate (NOT INCLUDED) and ghten the
screw with the help of screw driver.
FLYCAM TRUECAM FLUID MOTION HEAD 3
Mount the truecam onto the Camera
Stabilizer as shown below.
Insert the camera onto the truecam camera plate and ghten the screw properly.
NOTE : You can adjust the height of camera plate with the help of provided knob.
knob
FLYCAM TRUECAM FLUID MOTION HEAD 4
Insert your 12v baery (NOT INCLUDED) onto the gimble as shown below.
FLYCAM TRUECAM MOTION HEAD
ALL DRESSED UP AND GOOD TO GO.
(SHOWN WITH OPTIONAL ACCESSORIES)
Precauons and safety measures
Check wether the camera is completely ght and completely balanced
Do not put weight on it more than its limit
Do not lose or ght bolts unnecessarily as it is completely checked by company(or properly
calibrated)
Do not charge the baery while it is in gimbal
Charge the baery enough as it is able to drive the product(inbuilt alarm is there)
Do not change the PID sengs. It will leads to poor working of product.
Do not use other power source or baery
FLYCAM TRUECAM FLUID MOTION HEAD 5
WARRANTY
We oer a one year warranty for our products from the date of purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
best to help you out.
For any other assistance you can reach us via email.
