Flymo GT500 WHEELS Manuale utente

IMPORTANT INFORMATION

Read before use and retain for future

reference

WICHTIGE INFORMATION

Bitte vor dem Benutzen des Gerätes

durchlesen und gut aufbewahren

RENSEIGNEMENTS IMPORTANTS

A lire avant usage et à conserver pour

référence ultérieure

BELANGRIJKE INFORMATIE

Leest u deze informatie voor het

gebruik en bewaar ze voor

toekomstige raadpleging

VIKTIG INFORMASJON

Les bruksanvisningen før bruk og

oppbevar denne for senere bruk.

VIKTIG INFORMATION

Läs anvisningarna före användningen

och spara dem för framtida behov

VIGTIGE OPLYSNINGER

De bør læse dette før brug og gemme

til senere henvisning

INFORMACIÓN IMPORTANTE

Léase antes de utilizar y consérvela

como referencia en el futuro

INFORMAÇÕES IMPORTANTES

Leia antes de utilizar e guarde para

consulta futura

INFORMAZIONI IMPORTANTI

Leggere prima dell’uso e conservare

per consultazione futura

TÄRKEÄÄ TIETOA

Lue tämä ennen käyttöä ja säilytä

myöhempää tarvetta varten

(GB) INSTRUCTION MANUAL

(D) BEDIENUNGSANWEISUNG

(F) MANUEL D’UTILISATION

(NL) GEBRUIKSAANWIJZING

(N) BRUKSANVISNING

(SF) KÄYTTÖHJE

(S) BRUKSANVISNING

(DK) BRUGSANVISNING

(E) MANUAL DE INSTRUCCIONES

(P) INSTRUÇNÕES PARA O USO

(I) ISTRUZIONI PER L’USO

GT500

WHEELS

900

C D

532

Fitting the Lower Handle to the Lawnmower

1. Feed the hook (A2) attached to the lower handle (A1) halfway

through the centre slot of the guide (A3), in the direction indicated by

the arrow (A4).

2. Maintaining the hook (A2) in the centre slot of the guide (A3) turn

the lower handle (A1) clockwise through 900 to place both legs of

the lower handle in position between the hood brackets (A5). as

illustrated in Fig A.

3. Fit the lower handle (B1) to the deck with the lower handle pin (B2) as

illustrated in Fig B.

Fitting the Wheel frame to the lawnmower

1. Attach the wheels (C1) to the wheel frame (C2) with the wheel

retaining clips (C3) as illustrated in Fig C.

2. Fit the wheel frame (D1) to the deck with the lower handle bolt (D2),

small washer (D3), large washer (D4) and locknut (D5) as illustrated in

Fig D.

3. Locate the lower telescopic tubes (E1) inside the upper telescopic

tubes (E2) and secure with the pin (E3) and retaining clip (E4) as

illustrated in Fig E.

For further information, refer to the full Instruction Booklet supplied

with your product.

5119123-01

Electrolux Outdoor Products

Aycliffe Industrial Park

NEWTON AYCLIFFE

Co.Durham DL5 6UP

ENGLAND

Telephone - (00) 44 1325 300303 Fax - (00) 44 1325 310339

UK Telephone - 01325 300303 Fax - 01325 310339

Our policy of continuous improvement means that the specification of products may be altered from time to time

without prior notice. Electrolux Outdoor Products manufacture products for a number of well known brands under

various registered patents, designs and trademarks in several countries.

Registered number 974979 England

From the Electrolux Group. The world’s No.1 choice.

The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use.

More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum

cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more than 150

countries around the world.
