Foscam E1 Manuale utente

Customer Care

If you have any questions regarding your product,

please contact Foscam Customer Care.

Email: support@foscam.com

www.foscam.com

QUICK START

GUIDE

EQE10003

E1 Base Station

Power Adapter

Ethernet Cable

E1 Camera

Camera USB

Power Cable

Rechargeable

Battery

Magnetic

Wall Mount

Mounting

Screws & Anchors

WHAT'S

IN THE BOX

Single-sided

Adhesive Tape

Note: Please fully charge the battery before ﬁrst use.

E1 Base Station

E1 Camera

Power Adapter

USB . LAN . Sync . Power

E1 Base Station

Press the button to sync camera with Base Station.

Press the button to turn oﬀ the siren manually.

PHYSICAL DESCRIPTION

Green: The Base Station is connected to an external

USB Storage Device.

Blinking Green: The system is recording.

Amber: The external USB Storage Device is full or

disabled.

Oﬀ: No USB Storage Device is inserted.

Green: The Base Station is connected to the

Internet.

Amber: The Base Station is connected to the router

but no Internet connection has been established.

Oﬀ: The Base Station is not connected to a router.

Green: Camera(s) are connected to the Base Station.

Blinking Green: The Base Station is attempting to

sync with the camera.

Oﬀ: No cameras are currently connected to the Base

Station.

Green: The Base Station is powered On.

Oﬀ: The Base Station is powered Oﬀ.

Green Slow Blinking: Sync in process.

Solid Green Then Oﬀ: Sync process completed.

Blinking Amber Rapidly: Failed to sync.

Blinking Amber Slowly Then Oﬀ: The camera's battery level

is low.

Oﬀ: Camera is on standby or the battery is depleted.

Sync/Siren Oﬀ

Sync Button: Press this button to sync the E1 with the Base

Station.

Sync / Siren Oﬀ Button

E1 Camera

PHYSICAL DESCRIPTION

DC 12V . On/Oﬀ . USB . Reset . LAN

DC 12V

WIRELESS CONNECTIVITY

Ethernet Cable

Router

Power Cable

DC 12V

2. Connect Your Base Station to the Internet

1. Connect the Base Station to your router with an Ethernet Cable.

2. Plug the Base Station Power Adapter into an electrical outlet.

Note: Make sure your smartphone is on the same network as

the router. It will need to be connected to the 2.4GHz WiFi channel.

SETTING UP YOUR E1 SYSTEM

1. Insert the Rechargeable Battery Into Your Camera

a. Unlock the Rechargeable Battery compartment by

pressing and holding the latch.

b. The battery door will open automatically.

e. Close the battery door.

3. Press the On/Oﬀ button, and wait until the power and Internet

lights turn green. With a minute, the camera will connect to the

Base Station automatically.

A green LED on the camera will blink rapidly while syncing. The

camera LED will then turn oﬀ, and the Sync Status LED of the

Base Station will turn solid green, indicating that sync is

successful and the camera will announce "Base Station connection

succeeded".

a~b

c~d

Ethernet Cable

Router

LAN

DC 12V

Note: Please fully charge the battery before ﬁrst use.

c. Align the battery contacts.

d. Insert the Rechargeable Battery.

When the in-package camera is powered on, its LED light will

blink green repeatedly, indicating that it in the process of

syncing with the Base Station.

DC 12V

On/Oﬀ

3. Download Foscam App

4. Get a Free Foscam Account

b. Follow the onscreen instructions.

5. Add the Base Station to an Existing

Foscam Account

4. Follow the onscreen instructions.

6. View Your Video Footage

Add the Base Station to an existing Foscam Account.

To download the free Foscam App, simply scan the QR Code below.

You can also search for "Foscam" in the App Store or

Google Play store to download and install Foscam App as well.

With the Foscam App, you can turn your iOS or Android

smartphone into a monitoring center for your security system.

a. If you already have a Foscam Account, log in and tap .

When you launch the Foscam App, the devices page will display. To view

and listen in on a live feed, tap or click Live on the camera feed image.

View your camera's alert video recordings in the Foscam Cloud by

tapping the timebar in the live page. Your system is now set up and

ready to go!

Foscam

Camera

Add Camera

Base Station

Battery Camera

1. Tap the Foscam icon on your smartphone, then login to your

Foscam Account.

2. Tap .

Foscam

To create a new Foscam Account, launch the Foscam App from your

smartphone, tap the Sign Up button, and follow the onscreen

instructions.

3. Select Base Station, tap Next to scan the QR code of the Base Station,

or tap Alternate Setup to add the Base Station.

Mount Your Camera to the Wall

1. Fasten the mounting screw into the wall.

2. Hang the Magnetic Wall Mount from the screw.

CHARGE YOUR

BATTERY

2. Connect the power adapter and cable as shown below:

Note: Before mounting the Magnetic Wall Mount, please ensure that the

camera is positioned towards the precise area you would like to monitor.

Note: If you are using the camera outside, bring it inside while

charging the battery.

3. The camera LED light will stay solid green when the battery is fully

charged.

PLACE / MOUNT

YOUR CAMERA

1. Apply the single-sided adhesive tape provided in the package to the

bottom of the camera.

2. Place your camera on a ﬂat surface and position the camera to

monitor the area that you would like to.

Place Your Camera on a Flat Surface

You can place your camera on a ﬂat surface (desk, shelf, table, etc.)

1. Place the camera indoors. If the camera is currently mounted to a wall,

remove it from the Magnetic Wall Mount.

SYNC YOUR CAMERA WITH

THE BASE STATION

Within 1 to 3 feet

Repeat steps 1 through 4 for each camera.

When adding additional E1 cameras to your system, you will need to

individually sync them to the Base Station.

4. When Sync Status LED blinks green, press the Sync button on

top of the camera for about two seconds, and then release it.

A green LED on the camera will blink rapidly while syncing. The

camera LED will then turn oﬀ, and the Sync Status LED of the Base

Station will turn solid green, indicating that sync is successful and

the camera is ready for viewing!

Note: If the camera LED blinks an Amber color, then sync has failed.

Please repeat the sync process again and ensure that the camera is

within 1-3 ft. of the Base Station.

3. Press and hold the Sync button on the top of the Base Station for

about two seconds and then release it.

1. Please insert the Rechargeable Battery into the camera.

2. Place the camera within 1 to 3 feet (30 to 100 centimeters) of

the Base Station.

Syncing more than one camera?

USB . LAN . Sync . Power

Sync Status LED
