Foster 7236 000 Manuale utente

Live the Quality

MANUALE D’ISTRUZIONE PIANI COTTURA GRILL

NOTICE D’UTILISATION POUR TABLE DE CUISSON GRIL

USER’S MANUAL FOR GRILL COOKER HOBS

BEDIENUNGSANLEITUNG FUER KOCHPLATTE GRILL

GEBRUIKSAANWIJZING VOOR KOOKPLAAT GRILL

MANUAL DE INSTRUCCIONES PLACAS GRILL

cod. 7236 000

Foster spa

via M.S. Ottone, 18/20

42041 Brescello (RE) - Ital

tel. +39.0522.687425 - tel. Servizio Assistenza +39.0522.684450

fax +39.0522.686019 - fax Servizio Ricambi +39.0522.962166

e-mail: service@fosterspa.com

www.fosterspa.com

- 15 -

INDEX

PAGE

INSTALLATION INSTRUCTIONS

FITTING

ASSEMBLY

SOME SUGGESTIONS

MAINTENANCE

Disposal of old electrical appliances

The European Directive 2002/96/EC on Waste Electrical and Electronic

Equipment (WEEE), requires that old household electrical appliances

must not be disposed of in the normal unsorted municipal waste stream.

Old appliances must be collected separately in order to optimise the

recovery and recycling of the materials they contain and reduce the

impact on human health and the environment.

The crossed out “wheeled bin” symbol on the product reminds you of your

obligation, that when you dispose of the appliance it must be separately

collected.

Consumers should contact their local authority or retailer for information

concerning the correct disposal of their old appliance.

- 16 -

INSTALLATION

• This grill uses 2,500 watts at maximum position. Therefore, before

connection, ensure that your electricity supply is fitted with a minimum

16-ampere fuse. IT IS VITAL that your grill be connected to earth.

• It is likewise necessary to provide a bipolar cut-off device in your power

supply circuit, where the opening of the contacts is more than 3 mm.

• The plug must be accessible after installation.

• If the supply lead is damaged, it must be replaced by an equivalent

lead (H07RNF 3x1,5mm²) available from the after-sales department.

• Cooking with the grill necessarily involves the emission of fumes.

Sometimes, when cooking meats with a great deal of fat, small

flames will appear, identical to those on a barbecue. It is

necessary to take this feature into account when choosing a place

to build in your grill.

IT IS ABSOLUTELY IMPERATIVE TO LEAVE A SPACE OF AT LEAST

5 CM BETWEEN THE BOTTOM OF THE GRILL AND THE FIRST

SHELF OF THE KITCHEN UNIT.

THE DISTANCE BETWEEN THE WALL AND THE REAR OF THE

APPARATUS SHOULD BE 5.5 CM.

- 17 -

FITTING

This grill is built into a work surface or kitchen unit by simply cutting a hole

the corresponding shape.

Any support may be suitable: brickwork, timber, metal, granite, laminate,

etc.

Dimensions of apparatus: 520 x 380 mm

Dimensions of hole cut in work surface: 490 x 360 mm

- 18 -

ASSEMBLY

The fitting plate is fixed into the work surface.

When the grill is located in your work surface, you can fill the tray with

volcanic rocks, leaving the element raised. The bed of rock must be laid

with care, so that the distribution is regular and does not go beyond the

top of the tray.

You likewise have the opportunity to replace the volcanic rocks with water

(max.: 2 litres). This alternative is above all of interest in the cooking of

very fatty meats (sausages for example), since the juices disperse

immediately in the water. This avoids too severe fumes and facilitates

cleaning.

Fold down the element.

Then put the grill in place.

Your apparatus is ready to operate.

The appliance is not intended for use by young children or infirm

persons without supervision.

Young children should be supervised to ensure that they do not play

with the appliance.

- 19 -

SOME SUGGESTIONS

Before any utilization, preheat for 5 to 10 minutes in position maximum.

The position of the knob is indicative, according to the type of food to be cooked. It may vary

in relation to the quantity used, and the personal taste of the consumer.

Thermostat

position

Preparation

Cooking

Time

Observations

Rock (R)

Water(W)

Dish-warmer

Place the plate

onto the grill

R or W

Toasted bread

2 min.

1 min. on each

side

R or W

Caramelised pineapple

slices, brochettes of

fruit

12 min.

Turn every 3

min.

R or W

Half-tomatoes,

mushrooms, onion

slices

12 – 15

min.

Turn every 4

min.

R or W

Fresh salmon steaks,

trout, sole, scampi

10 – 12

min.

5 – 6 min. on

each side.

R or W

Sausages

10 min.

Turn every 2

min.

Brochettes of meat

Well-done beef

12 – 15

min.

Turn every 4

min.

R or W

Rare beef

4 – 6

min.

2 – 3 min. on

each side

R or W

It is necessary to brush fish which you intend to grill, lightly with oil or

melted butter. This will prevent the fish from sticking to the grill.

To stop cooking, switch to position 0.

- 20 -

MAINTENANCE

Before any maintenance, make sure that the apparatus is off, and allow it

to cool down.

All the pieces can be maintained quickly. A « drainer » position has been

devised, to permit the heating element to be secured during cleaning.





Hinge : the « drainer » position

The aluminium hinge which permits the turning of the element during

maintenance is fitted with a stainless steel securing bolt. This piece

runs to the right and secures the element, which is held in the

vertical position during the time necessary for cleaning.

- 21 -

The cast-iron grill: you can clean it easily when it has cooled down.

Proceed as for the rest of your kitchenware: a little detergent will be

sufficient. It is preferable not to place it in the dish-washer, so as to

maintain the brilliance of its enamel.

The heating element must be treated with a damp cloth.

The stainless steel tray may be treated with detergent, like all

kitchenware. Do not hesitate to put it in the dish-washer.

The fitting plate : clean it with products intended for the maintenance of

stainless steel. If you wish to keep its good appearance, avoid scourers

and abrasive detergents.

The volcanic lava does not deteriorate. Periodically remove accumulated

grease by placing the pieces of lava in a strong heat (the hearth) or in a

gas oven. In the event of excessive saturation of the rocks, refills are

available.
