FRAMOS FSM-IMX636 Devkit Manuale utente
1 2 3
45 6
Quick Start Guide
Unpack the IMX636 Devkit contents. The
front-end should ship pre-assembled.
Connect the PixelMate™ to the FRAMOS
Sensor Adapter (FSA). Connect by
mating Pin 1 to Pin 1.
Connect the FRAMOS Processor Adapter
(FPA) to the processor board.
Connect the PixelMate™ to the FPA.
Connect by mating Pin 1 to Pin 1.
Prepare the processor board and power
on according to the manufacturers
instructions.
With assembly complete, download and
install the required drivers and software.
FSM-IMX636 Devkit
Quick Start Guide
(Contents on Page 2)
2023-07-10
Version 1.0a
Contact Information
FRAMOS GmbH
Website: https://www.framos.com
www.framos.com
NOTE Always read the user manual before operating.
To access the user manual, refer to step 6.
www.framos.com/fsm-startup
WARNING Connect by mating pin 1 to pin 1 as illustrated.
Do not invert the pinout orientation during installation.
Failure to orient the connection as illustrated will lead to
permanent equipment damage.
WARNING Connect by mating pin 1 to pin 1 as illustrated.
Do not invert the pinout orientation during installation.
Failure to orient the connection as illustrated will lead to
permanent equipment damage.
NOTE See NVIDIA® documentation for instructions.
© 2023 FRAMOS GmbH.
All rights reserved. No parts of this work may be reproduced in
any form or by any means - graphic, electronic, or mechanical,
including photocopying, recording, taping, or information
storage and retrieval systems - without the written permission
of the publisher.
Products that are referred to in this document may be either
trademarks and/or registered trademarks of the respective
owners. The publisher and the author make no claim to these
trademarks.
While every precaution has been taken in the preparation
of this document, the publisher and the author assume no
responsibility for errors or omissions, or for damages resulting
from the use of information contained in this document or from
the use of hardware, programs and source code that may
accompany it. In no event shall the publisher and the author
be liable for any loss of prot or any other commercial damage
caused or alleged to have been caused directly or indirectly
by this document.
WARNING This kit contains electrostatic-sensitive devices (ESD).
Observe handling precautions to avoid damaging the equipment.
What’s in the box?
FSM-IMX636 Devkit
Quick Start Guide
Contents
2023-07-10
Version 1.0a
Certication and Standards
The equipment described in this document is designed for
evaluation and laboratory use, as well as for the integration
into electronic devices. The customer is responsible to take all
necessary precautions to full regulations and laws of end-
customer and target market.
Technical Support
The technical equipment described in this document, be it
hardware or software, is delivered as it is and does not include
any obligations to FRAMOS to provide technical customer
support. Technical support is granted on a per-project basis
arbitrary by FRAMOS.
Handling ESD Sensitive Components
The electronic components like Printed Circuit Boards (PCB)
described in this document are sensitive to Electrostatic
Discharge (ESD) and need to be handled with high care in
static controlled environments. It is strongly recommended to
follow the general handling practices for ESD sensitive parts,
that include, but are not limited to, the following points:
• Treat all PCBs and components as ESD sensitive.
• Assume that you will damage the PCB or component if you
are not ESD conscious.
• Handling areas must be equipped with a grounded table,
oor mats and wrist strap.
• A relative humidity level must be maintained between 20%
and 80% non-condensing.
• PCBs should not be removed from their protective
package, except in a static controlled
location.
• PCBs must be handled only after personnel have
grounded themselves via wrist straps and
mats.
• PCBs or components should never come in contact with
clothing.
• Try to handle all PCBs only by their edges, preventing
contact with any components.
FRAMOS is not responsible for ESD damage caused
by misuse.
Life Support Applications
These products are not designed for use in life support
systems, appliances, or devices where malfunction of the
products can reasonably be expected to result in personal
injury. Customers, Integrators and End Users using or selling
these products for use in such applications do so at their own
risk and agree to fully indemnify FRAMOS for any damages
resulting from any improper use or sale.
CE-Declaration
This equipment is in compliance with the essential
requirements and other relevant provisions of the following
RoHS Directives: Directive 2011/65/EU and (EU) 2015/863.
RoHS
The RoHS Directive (Restriction of Hazardous Substances)
complements the WEEE Directive by severely restricting the
presence of specic toxic substances in electronic equipment
at the design phase, thereby reducing the environmental
impact of discarding such products at the end of their useful
life. FRAMOS Technologies d.o.o. is committed to complying
with this Directive and has worked in collaboration with its
suppliers to evaluate the new restrictions, to identify relevant
exemptions, and to substitute environmentally benign,
compliant alternative materials in its product components
and manufacturing processes. Subject to the available
exemptions, FRAMOS Technologies d.o.o. products were
compliant with the RoHS Directive for its products.
Materials declarations comply with EN 63000:2018
requirements for RoHS Technical Documentation.
EU Declaration of conformity according to RoHS are issued on
customer demand.
WEEE
The WEEE Directive obliges manufacturers, importers, and/
or distributors of electronic equipment to label the equipment
for recycling and to provide for recycling of the electronic
equipment at the end of its useful life. FRAMOS is committed
to complying with the WEEE Directive (as implemented in
each EU member state). In accordance with the requirements
of the Directive, FRAMOS Technologies d.o.o. has labelled
its electronic products that are shipped. The WEEE label and
instructions for disposal are as follows:
REACH
FRAMOS neither manufactures nor imports chemical
substances.
FRAMOS is well aware of:
The requirements of REACH regulation of the European
Council (EC) No. 1907/2006.
The SVHC Candidate List.
Our obligations concerning safety datasheets as well as
informing customers.
Instructions for Disposal of Waste Equipment by
Users in the European Union
This symbol on the product or its packaging indicates that this
product must not be disposed of with other waste. Instead,
it is your responsibility to dispose of your waste equipment
by handing it over to a designated collection point for the
recycling of electrical waste and electronic equipment. The
separate collection and recycling of your waste equipment at
the time of disposal will help conserve natural resources and
ensure that it is recycled in a manner that protects human
health and the environment. For more information about
where you can drop off your consumer waste equipment for
recycling, please contact your local city recycling ofce or the
dealer from whom you originally purchased the product.
Electro Magnetic Compliance (EMC)
The FRAMOS Sensor Module Ecosystem are OEM
components/devices and are provided at the open board
level. Electrical components with open design do not comply
with standards for electromagnetic compatibility as the
unshielded circuitry enables electromagnetic interference with
other electronic devices.
1
2
3
4
5
6
7
8
