Francis Searchlights FB280 Manuale utente

User Instruction & Installation Manual

FB280

Tungsten Halogen Searchlight

Product Reference Number:

B7163 –FB280 LV Chrome B7169 –FB280 LV Semi-Gloss Black

B7186 –FB280 HV Chrome B7179 –FB280 HV Semi-Gloss Black

Manufacturer’s details: Distributor details:

Manual Part Number: C22274 Issue: 3 16.8.18

Francis Searchlights Ltd

Union Road, Bolton

Lancashire, BL2 2HJ, UK

Tel: +44 (0) 1204 558960

Fax: +44 (0) 1204 558979

http://www.francis.co.uk

E-mail: sales@francis.co.uk

CONTENTS

- Introduction

- Safety Precautions

- Technical Information

- Unpacking and Installation Instructions

- Electrical Installation

- Operating Instructions

- Fault Finding

- Maintenance and Servicing

- General Assembly

- Spare Parts List

1 - Introduction

It is imperative that this manual is read carefully and understood before

installing your equipment. For your future reference please keep this

manual in a safe place.

Thank you for specifying a product from the Francis Searchlights range. All Francis products

are designed to give complete customer satisfaction and are manufactured to the highest

engineering standards in order to ensure optimum performance and service life.

The Francis FB range combines features proven over many years service in the most

hazardous conditions in both marine and land installations.

In order to prolong the life and performance of your product, we recommend that you only

specify Francis Searchlights spare parts. This will also ensure that any warranties on your

equipment will not be invalidated. Information on spares ordering and parts is provided in this

manual.

Should you ever need to contact Francis Searchlights Ltd. regarding your equipment, please

quote the Product Serial Number at all times.

2 - Safety Precautions

The following instructions must be adhered to, in order to ensure a safe working environment

and the safety of the user.

Note: When unpacking or manoeuvring the searchlight into its fixing position, suitable

lifting points must be used in order to prevent damage to the equipment or personal

injury.

Prevent rain, snow, condensation and water droplets from contacting the lamp as this may

cause bulb failure and possible shattering;

Quartz halogen bulbs run with a high internal pressure in excess of atmospheric. Whilst the

construction is inherently strong, there is a slight risk of the bulb shattering;

Never look directly into an illuminated searchlight as this may cause severe damage to

eyesight. If it is necessary to inspect a lamp whilst in operation, always wear suitable

protective goggles;

Should it be necessary to examine the lamp with the front bezel removed, always use a

protective shield and wear goggles to ensure a safe working environment;

Never attempt to clean a lamp whilst in use;

Searchlights get hot. Never touch the unit when lit and always allow 15 to 20 minutes for

cooling down after turning the searchlight off;

Never place anything on or cover the searchlight when in use;

Ensure the lamp has cooled sufficiently before removal;

If undue force appears necessary to remove the lamp, the equipment should be inspected

by a competent person or contact the manufacturer;

When breaking a lamp for disposal, care must be taken to ensure the glass fragments are

safely contained. This operation must be performed out of doors in free air. In all

circumstances refer to the lamp manufacturers instructions packed with the lamp;

Due to the vast range of lamps available it may appear possible that more powerful lamps

can be used in the equipment than for which it was designed. Even when the unit will

physically accept a higher wattage or voltage lamp, this substitution is not recommended

and is dangerous. This action will also void any warranties on the equipment.

Always refer to the lamp manufacturer’s technical data when dealing with lamps.

3 - Technical Information

This product has been designed to operate in accordance with the product specification. The

FB280 searchlight has the following features:

All marine grade materials and fixings;

Parabolic glass reflector;

Stove enamel paint or chrome finish;

360° horizontal rotation;

Vertical movement +90° to -30°;

Toughened front glass;

Tungsten halogen light source 12/24v or 110/230v;

External lamp focus adjustment between;

Integral on/off switch;

Enclosure protection to IP56;

The searchlight also performs to the following optical data:

Volts Watts Range P.B.C.P. Div* Lamp Life Lamp Despatch

@ 1 Lux x 1000 (Hours) Cap Number

12v 100w 933M 871 3° 2000 GX6.35 D9848

24v 150w 960M 921 3° 300 GX6.35 D14795

24v 250w 1114M 1242 3° 2000 GX6.35 D4695

24v 250w 1360M 1800 3° 300 GX6.35 D9851

120v 300w 1150M 1323 4.7˚75 GX6.35 D16883

230v 300w 1200M 1250 4.7˚ 75 GX6.35 D16841

In order that the searchlight operates correctly it is imperative that competent personnel are

responsible for the installation, operation and servicing of this equipment. Failure to adhere to

this advice may cause premature failure or incorrect operation of the searchlight, which may

damage the equipment or cause personal injury.

4 - Unpacking and Installation Instructions

The following instructions should be read and fully understood prior to installing the equipment

to ensure that the correct procedures are followed, and all safety precautions are observed.

Note: If the equipment has been in storage for a considerable amount of time, it is

advisable to conduct a routine maintenance check on all parts before installation.

Safety Precautions

This equipment should not be connected to an electrical supply before being installed.

Installation procedures should be adhered to in order to ensure a safe working environment

and reduce the risk of damage or personal injury.

Preparing the Mounting Position

Bolt the searchlight firmly down, on and uneven surface it may be necessary to use a suitable

sealant such as silicone, in order to ensure a weatherproofed joint.

5 - Electrical Installation

For safety purposes, only competent personnel should perform the electrical installation. All

equipment should be installed to current Electrical Regulations and Standards.

In order to obtain the maximum light output from the searchlight, it is essential that the full

operating voltage of the lamp fitted be applied to the lampholder contacts.

Method of Electrical Connection

1) Disconnect the supply before working on the electrical system;

2) The searchlight must be connected to a fused electrical supply, using suitably sized cable;

3) If the searchlight is located a considerable distance from the supply, provision must be

made in the cable size in order to overcome the voltage drop. The following table should be

used for indication purposes only:

Searchlight

12v 100w

24v 150w

24v 250w

Cable Size (mm²)

Distance Max

1.5

2 MTRS

5 MTRS

3 MTRS

2.5

3 MTRS

8 MTRS

5 MTRS

4.0

5 MTRS

13 MTRS

8 MTRS

6.0

7 MTRS

20 MTRS

12 MTRS

10.0

15 MTRS

34 MTRS

20 MTRS

Searchlight

120v 300w

230v 300w

Cable Size (mm²)

Distance Max

1.5

13 MTRS

24 MTRS

2.5

21 MTRS

39 MTRS

4.0

32 MTRS

62 MTRS

6.0

50 MTRS

96 MTRS

10.0

84 MTRS

161 MTRS

4) Whenever possible cable terminations should be made below deck and with approved

terminal devices;

5) If a spare auxiliary fuse or circuit breaker is not available, one of the correct type and rating

should be fitted and connected to a positive supply. It is advisable to locate a bus bar or

main connection and avoid any direct connection to the supply:

6) For 110/220v AC products, the following colour coding system should be used for the

customer supply cable:

Brown - Live

Blue - Negative

Green/Yellow - Earth

Note: This equipment must be earthed.

6 - Operating Instructions

This equipment is designed for use out of doors, in free air. Never place anything on, or cover,

the searchlight when in use as this may present a hazard.

The beam of the searchlight can be adjusted to give a variety of beam types. Using the external

focus wheel, the desired beam can be achieved for any particular application.

This product should not be used for any purpose other than for which it was designed.

Any modifications to the product should not be undertaken without consulting the

manufacturer.

Setting to Work

Safe service in use necessitates the strict observance of the following precautions.

Any article fabricated from quartz or glass is inherently fragile and care should

therefore be taken, at all times, when handling lamps;

Eye protection must be worn when handling lamps that have been removed from

their packaging materials. The protective jacket should not be removed from the

lamp for safety reasons, as there is a remote possibility of the lamp shattering

violently, especially if it is subjected to mechanical shock or vibration;

Always isolate the equipment from the supply before inserting a lamp;

Before inserting the lamp ensure that all contacts are clean. Contacts must be

renewed at the slightest sign of corrosion. Sanding or filing down corroded areas is

not recommended as this will only make the conducting surface between the pin

and lampholder smaller, thus causing the lamp to overheat;

Do not twist or bend the fused quartz bulb when fitting the lamp as mechanical

stresses MUST be avoided;

The lamp must be capable of unimpeded expansion when it warms up to operating

temperature. Mechanical forces must not be applied to the fused quartz bulb;

Before the protective jacket is removed, suitable protection must be worn i.e face

mask and gloves with wrist protection;

Never touch the quartz bulb with bare hands, as fingerprints will make the glass

cloudy and cause a severe loss of light. This may also cause recrystallisation and

thus weaken the bulb material. Should the bulb be inadvertently touched, remove

fingerprints with methylated spirit and a clean, soft paper towel. The bulb should

then be wiped with distilled water. NOTE: ALWAYS WEAR MASK AND GLOVES

DURING CLEANING);

In all circumstances the lamp manufacturer’s data should be referred to when dealing

with lamps.

When fitting the lamp:

-Always isolate the equipment from the supply when inserting a lamp;

-Ensure the circuit is suitably fused;

-Ensure the lamp is of the correct power rating and type;

-Check lampholder is in good condition. If the contacts show any sign of corrosion, replace

the lampholder;

-Check the lampholder is in a good dry condition. Never allow water to collect in the lamp

fitting or come into contact with the lamp.

To fit the lamp:

-Unclip the latches on the front of the searchlight, allowing the bezel and glass to hang clear

on the captive latch;

-For easier access the light shield may be removed by undoing the centre screw;

-Cut open one end of the protective sleeve surrounding the lamp;

-Using the sleeve to prevent the fingers coming into contact with the lamp, position the two

pins above the holes in the lampholder;

-Gently push the lamp into the lampholder and remove the protective sleeve;

-Replace the light shield, fixing the centre screw in position;

-Position the front bezel onto the searchlight and retain in position using the latches;

Testing

Upon correct installation and connection to an electrical supply, the equipment can be tested in

order to ensure its’ correct performance. A competent person with some knowledge of electrical

equipment must carry out this work.

Equipment required: Multimeter with leads

Ammeter

Using the equation P=VI, the approximate power output of the equipment can be calculated in

the following way:

-Using the multimeter, take a voltage reading;

-Using the ammeter, take an amp reading from the live cable to the lamp;

-Multiply these figures together to give an approximate wattage (Power output).

For example:

Using a 24v 150w Tungsten halogen lamp:

Voltage reading = 24v; Amps reading = 6 amps

Therefore, Wattage = 24 x 6 = 144 watts

7- Fault Finding

All fault finding must be conducted by a competent person or qualified Electrical Engineer.

Failure of Lamp to light

Causes:

1) Power not supplied;

2) Fuse blown;

3) Failed lamp

Remedy:

1) Check voltage at supply. If supply is not present the fault is at the customer supply. If

power is present, see remedy 2;

2) Check fuse for visual failure. If none noticeable check fuse for continuity using a

multimeter. If fuse found to be faulty, replace with new part and test equipment again for

correct working order. If found to be working correctly see remedy 3;

3) Firstly, check supply at lampholder connecting block (within searchlight barrel). If supply is

present, disconnect unit from power supply before removing the lamp. If noticeable

damage to filament is present, the lamp will have failed. The lamp can also be checked for

continuity using a multimeter. Replace lamp ensuring all precautions and instructions

previously outlined in this manual are adhered to.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Francis Searchlights Proiettore

Francis Searchlights

Francis Searchlights L560 Manuale utente

Francis Searchlights

Francis Searchlights A7199 Manuale utente

Francis Searchlights

Francis Searchlights A7195 VL500 150w 24v LED Manuale utente

Francis Searchlights

Francis Searchlights FH380RC Manuale utente

Francis Searchlights

Francis Searchlights A7123 Manuale utente

Francis Searchlights

Francis Searchlights FH380 Manuale utente

Francis Searchlights

Francis Searchlights FR480 Manuale utente

Francis Searchlights

Francis Searchlights FX380 Manuale utente

Francis Searchlights

Francis Searchlights A2963 Manuale utente

Francis Searchlights

Francis Searchlights A7120 Manuale utente

Francis Searchlights

Francis Searchlights A7104 Manuale utente

Francis Searchlights

Francis Searchlights Voyager 2 Manuale utente

Francis Searchlights

Francis Searchlights A7182 VM500 Manuale utente

Francis Searchlights

Francis Searchlights A7193 VL500 150w 115/230v LED Manuale utente

Francis Searchlights

Francis Searchlights A2277 Manuale utente

Francis Searchlights

Francis Searchlights L230RC Manuale utente

Francis Searchlights

Francis Searchlights A2213 Manuale utente

Francis Searchlights

Francis Searchlights A7186 VX500 100w 24v Xenon Manuale utente

Francis Searchlights

Francis Searchlights A6192 Manuale utente

Francis Searchlights

Francis Searchlights FR300 Manuale utente

Francis Searchlights

Francis Searchlights A7138 Manuale utente

Francis Searchlights

Francis Searchlights A7170 Manuale utente

Francis Searchlights

Francis Searchlights FB230 Manuale utente

Francis Searchlights

Francis Searchlights A2980 Manuale utente

Manuali Proiettore popolari di altre marche

VIZULO

VIZULO Micro Martin Guida utente

EuroLite

EuroLite LED IP FL-100 SMD Manuale utente

Cooper Wheelock

Cooper Wheelock XB12 Manuale utente

Allen + Roth

Allen + Roth 17624-000 Manuale utente

ADJ

ADJ 4 STAGE PAK Manuale utente

Cooper Lighting

Cooper Lighting EGL91SW233 Manuale utente

Max

Max 37496 Manuale utente

BEGA

BEGA 85 143 Manuale utente

Beamz

Beamz 151.226 Manuale utente

EuroLite

EuroLite LED IP FL-8 Manuale utente

Ledj

Ledj PERFORMER 36 RGB Manuale utente

Perel

Perel ELS3 Manuale utente

Perel

Perel ELS3WD Manuale utente

LumX

LumX LM 36130 Manuale utente

Xtricity

Xtricity 4-80053 Manuale utente

Stahl

Stahl 6521/4 Series Manuale utente

Ecosense

Ecosense EcoSpec Manuale utente

Ayrton

Ayrton minipanel FX Manuale utente
