Franklin SDM-3009 Manuale utente



SDM-3009

Medical Book Card

User’s Guide



MBS

Medical Book System™

READ THIS LICENSE AGREEMENT BEFORE USING THE MEDICAL BOOK

SYSTEM.

YOUR USE OF THE MEDICAL BOOK SYSTEM DEEMS THATYOU ACCEPT

THE TERMS OF THIS LICENSE. IFYOU DO NOT AGREE WITH THESE

TERMS,YOU MAY RETURN THIS PACKAGE WITH PURCHASE RECEIPT TO

THE DEALER FROM WHICHYOU PURCHASED THE MEDICAL BOOK SYS-

TEM ANDYOUR PURCHASE PRICE WILL BE REFUNDED. The MEDICAL

BOOK SYSTEM means the software product, hardware, and documentation found in

this package and FRANKLIN means Franklin Electronic Publishers, Inc.

LIMITED USE LICENSE

All rights in the MEDICAL BOOK SYSTEM remain the property of FRANKLIN.

Through your purchase, FRANKLIN grants you a personal and nonexclusive license to

use the MEDICAL BOOK SYSTEM. You may not make any copies of the MEDICAL

BOOK SYSTEM or of the preprogrammed data stored therein, whether in electronic or

print format. Such copying would be in violation of applicable copyright laws. Further,

you may not modify, adapt, disassemble, decompile, translate, create derivative works

of, or in any way reverse engineer the MEDICAL BOOK SYSTEM.You may not ex-

port or re-export, directly or indirectly, the MEDICAL BOOK SYSTEM without com-

pliance with appropriate governmental regulations. The MEDICAL BOOK SYSTEM

contains Franklin’s confidential and proprietary information which you agree to take

adequate steps to protect from unauthorized disclosure or use. This license is effective

until terminated. This license terminates immediately without notice from FRANKLIN

if you fail to comply with any provision of this license.

License Agreement

Contents

➤

About Book Card Compatibility

IMPORTANT This book card can be

used only with the Medical Book Sys-

tem

™

platform and will not function in any

other Franklin BOOKMAN

platform.

The Medical Book System platform

can use Franklin BOOKMAN book

cards as well as Medical Book System

book cards. However, Franklin BOOK-

MAN platforms cannot use Medical

Book System book cards.

➤

For More Information

To learn more about the Medical Book

System or other products from Frank-

lin Electronic Publishers, call 800-665-

5450 or visit the Franklin Web site at

www.franklin.com.

Key Guide..................................... 3

Installing Book Cards .................. 4

Selecting a Book .......................... 4

Changing the Settings ................. 5

Viewing a Demonstration ............ 5

Using the Entries Menu ............... 6

Understanding Entries and

Subentries .................................... 7

Searching for Words.................... 8

Highlighting Search Words ......... 9

Expanding Your Searches ......... 10

Reading Special Markers........... 11

Using Notes................................ 12

Looking Up Words

in Other Books ........................... 13

Resetting the Medical Book

System........................................ 13

Book Card Care.......................... 14

Specifications and Patents ....... 14

FCC Notice ................................. 15

Limited Warranty (U.S. only) ..... 16

Index ........................................... 17

Color Keys

(red) Expands a word search.

SPEC

(green)Displays the Outline loca-

tion of the current text.

(

yellow

)Displaysthewordsearchscreen.

LIST

(blue) Lets you add, find, or remove

a note.

Function Keys

BACK

Erases typed letters, or backs up to

the previous screen.

CAP

Shiftskeystotypecapitalsorpunctuation.

CARD

Exits the currently selected book.

CLEAR

Clears an entry or search and goes

to the default state.

ENTER

Enters a word, selects a menu item,

or starts the highlight in text.

HELP

Displays help messages.

Displays the main menus.

ON/OFF

Turns the platform on or off.

SPACE

At entry screens, types a space. At

menus and text, pages down.

? ✻

At menus, displays the title of a high-

lighted item.With

CAP

,types an

asterisk (✽) to stand for letters in a

word.At text, displays the current Out-

line location of the text.

Key Guide

Key Combinations*

Goes to the top level of a

menu from a lower level.

Transfers a highlighted word

between installed book cards.

At a highlighted menu item, dis-

plays the related text.At text,

highlights special markers (e.g.,

footnotes, cross-references, etc.).

Types numbers.

At text, displays the next or

previous paragraph, table row,

or search match.

Goes to the top or bottom of

a menu or list.At text, goes to

the next or previous section.

✩

BACK

✩

CARD

✩

ENTER

✩

+Q-P

✩

CAP

* Hold the first key while pressing the second.

Direction Keys

Pages up or down.

Moves the cursor, text, or

highlight.

Installing Book Cards

CAUTION Never install or remove a

book card when the platform is turned on.

If you do, information entered in any

installed book cards may be erased.

1. Turn the platform off.

2. Turn the platform over.

3. Align the book card tabs with the

notches in a card slot.

4. Press the book card until it snaps

into the slot.

Selecting a Book

If you have installed two book cards in

the platform, you can select which book

you want to read.

1. Turn the platform on.

2. Press

CARD

3. Use or to highlight the book

you want to use.

4. Press

ENTER

to select it.

➤

Removing Book Cards

CAUTION When you remove a book

card from a platform, information en-

tered in that book card may be erased.

➤

Understanding the Keys

The functions of the keys may vary ac-

cording to which book card is installed

and selected in the platform. To learn

how to use a particular book card, read

its User’s Guide.

➤

Help is Always at Hand

You can view a help message at virtu-

ally any screen by pressing

HELP

. To

exit help, press

BACK

To read a tutorial about this book, se-

lect Tutorial from the Setup menu.

➤

Follow theArrows

The flashing arrows at the right of the

screen show which arrow keys you can

press to move through menus or view

more text.

Using the Setup menu, you can adjust the

type size, default state, shutoff time, and

screen contrast of this book.

The type size sets how large the charac-

ters appear on screen. The shutoff time

sets how long your Medical Book System

stays on if you forget to turn it off.

The default state sets the screen that ap-

pears when you press

CLEAR

1. Press

2. Highlight

Set Type Size, Set De-

fault Topic, Set Default State, Set

Shutoff

, or

Set Contrast

on the

Setup menu.

3. Press

ENTER

4. Use or to change the setting.

Or press

BACK

to leave the setting

unchanged.

5. Press

ENTER

to select it.

Changing the Settings

Before you start using this book, you may

want to see a brief demonstration.

Press

and then use the arrow keys to

highlight View Demo on the Setup menu.

Press

ENTER

to select it. To stop the dem-

onstration, press

CLEAR

Viewing a Demonstration

➤

Misspelling

When you type letters that do not

match a term on the Entries menu, the

spelling correction entry screen ap-

pears.You can press

BACK

repeatedly

to exit it, or you can enter the mis-

spelled entry name to view correc-

tions.

You can select Words starting with... to

view completions, if any, or select a

correction to view its definition.

5. Press

ENTER

to view the definition.

The simplest way to find an entry is to

type the term at the Entries menu.

1. Press

CLEAR

2. If needed, press

and high-

light the Entries menu.

3. Type the name of the term you

want to look up. For example, type

bursitis

To delete a letter, press

BACK

You can also highlight a menu item by

using or .

A slanted arrow indicates that the

menu item has a submenu.

4. When the entry is highlighted, press

ENTER

to select it.

If you entered a main entry, select the

subentry you want and press

ENTER

Using the Entries Menu

➤

Symbol andAbbreviation key

Understanding Entries and Subentries

Sub-entry

Official alternate term

Nomina Anatomica

Official alternate Nomina

Anatomica term

Abbreviation

[NA]

abbrev.

panded. For example if you look up MI

you are cross-referenced to myocardial

infarction.

Eponyms are terms named after people.

A search on a person’s name will yield

a short biographical sketch followed by

cross-references to the eponyms. For

example, a search on Weill will take

you to the Weill, Georges entry with a

cross reference to Weill-Marchesani

syndrome.

Entries are arranged in the main entry/

subentry format. Most subentries are

found under main entries that are single

word nouns. For example, subdeltoid

bursitis can be found in a submenu un-

der bursitis, Babesia ovis under Babe-

sia and so on.

Note: In most subentry menus, the

main headword is abbreviated to its

first letter, for example B. ovis, so that

you can type ovis in the Babesia sub-

menu to quickly find Babesia ovis. Ar-

ticles and prepositions can also be

ignored in searches. For example to

find base of stapes in the Base sub-

menu, just type stapes.

Latin terms (Nomina Anatomica) are

cross referenced to the English terms.

Definitions of anatomical terms are

listed under their English equivalents;

for example, to find the definition

faster, look up encephalocele instead of

cranium bifidum.

Abbreviations are either cross-refer-

enced to the main entry or are ex-

Searching for Words

Word searches find all the occurrences, or

matches, of a word or word phrase in this book.

You can type up to 100 characters in a

single search, but you cannot search for

short, common words such as the and is.

1. Press

(yellow).

2. Type your search words. For ex-

ample, type

sucquet

To delete a letter, use

BACK

You do not need to type capitals or

punctuation to find matches.

3. Press

ENTER

to search.

This is the Outline location of the first

match of your search words.

4. Press

ENTER

to see the match.

Your search words are boxed.

5. To see the Outline location of the

next or previous matches, if any,

hold

✩

and press

6. Press

to see the matches

listed on the menus.

After a word search, only matching en-

tries are listed on the menus.

7. Use the arrow keys to highlight a

menu item and then press

ENTER

. If

needed, select a subitem.

8. Press

(yellow) or

CLEAR

clear your search.

➤

If You Misspell a Search Word

If you enter a misspelled search word,

a list of corrections appears.

Use to highlight a correction and

then press

ENTER

➤

Searching for Parts of Words

If you want to find prefixes, suffixes,

or other parts of words, type an aster-

isk (✽) in place of the missing letters.

For example, type bacter

✽

and then

press

ENTER

. To type an asterisk, hold

CAP

and press

✻

Use to highlight a match and then

press

ENTER

Searching for Words

You can also search for a word by high-

lighting it in text.

1. At the text, press

ENTER

To turn off the highlight, press

BACK

2. Use the arrow keys to highlight a word.

3. Press

ENTER

to search for it.

If needed, press

ENTER

again to see the

first match.

4. Hold

✩

and press

repeatedly

to see the Outline locations of the

next matches, if any.

To see the location of previous

matches, if any, hold

✩

and use

5. Press

to see the menu items

with matches.

6. Press

CLEAR

when finished.

Highlighting Search Words

Indice

Altri manuali Franklin Dizionario elettronico

Franklin

Franklin Dictionnaire Franais/Anglais DBF-116 Manuale utente

Franklin

Franklin LLS-7100 Language Master Colour Manuale utente

Franklin

Franklin Talking Children's Dictionary CDS-240 Manuale utente

Franklin

Franklin Language Master LM-2015 Manuale utente

Franklin

Franklin DEUTSCH-ENGLISCH LEXIKON BQD-210 Manuale utente

Franklin

Franklin Professor PRO DBD-3040 Manuale utente

Franklin

Franklin BOOKMAN MWD-440 Manuale utente

Franklin

Franklin Language Master LM-2000 Manuale utente

Franklin

Franklin IC-109 Manuale utente

Franklin

Franklin BES-1850 Manuale utente

Franklin

Franklin EST-5114 Manuale utente

Franklin

Franklin Language Master LM-5000 Manuale utente

Franklin

Franklin MWS-1840 Manuale utente

Franklin

Franklin BOOKMAN SCD-770 Manuale utente

Franklin

Franklin CST-180 Manuale utente

Franklin

Franklin IC-111 Manuale utente

Franklin

Franklin Dictionary & Thesaurus MWD-1470 Manuale utente

Franklin

Franklin Deutsch/English Professor PRO BDS-1860 Manuale utente

Franklin

Franklin EnglishFrench BFQ-470 Manuale utente

Franklin

Franklin RDC-525 Manuale utente

Franklin

Franklin DMQ-118N Manuale utente

Franklin

Franklin SPQ-200 Manuale utente

Franklin

Franklin German/English Dictionary DBD-4028DL Manuale utente

Franklin

Franklin Talking Children's Dictionary KID-1240 Manuale utente

Manuali Dizionario elettronico popolari di altre marche

Ectaco

Ectaco SAT-1600 Manuale utente

Sharp

Sharp PW-E310 Manuale utente

Eaton

Eaton DNP MINT Guida rapida

Ectaco

Ectaco Language Teacher ECz600T Manuale utente

Besta

Besta cd 739p Manuale di istruzioni

LEGRAND

LEGRAND tynetec ZXT360 Manuale utente

HORITA

HORITA RLT-50 Manuale utente

Language Teacher

Language Teacher ES400T Manuale utente

Accent

Accent 800 Manuale utente

SUPREME

SUPREME BTLT200 Manuale utente

KMC Controls

KMC Controls KMD-5551E Guida utente

Ectaco

Ectaco SpeechGuard TL-4 Manuale utente

Sharp

Sharp PW-AM700 Manuale utente

Ectaco

Ectaco Language Teacher ET200D Manuale utente

Bosch

Bosch LTC 8782 Series Manuale utente

Vasco

Vasco Mini Manuale utente

Ectaco

Ectaco Partner PW800 Manuale utente

Ectaco

Ectaco Language Teacher ERm600T Manuale utente
