Children aged from 3 to 8 years are allowed to load and

unload refrigerating appliances.

Contents

Safety and warning information…........2

Installing your new appliance………....8

Description of the appliance.................9

Reversing the door............…..........10

Operation.............……….…...............13

Using your appliance.…….…..........14

Helpful hints and tips……….…........16

Cleaning and care.....……………….17

Troubleshooting......…………………19

Disposal of the appliance. ......…..…20

For your safety and correct usage, before installing and first

using the appliance, read this user manual carefully, including

its hints and warnings. To avoid unnecessary mistakes and

accidents, it is important to make sure that all people using the

appliance are thoroughly familiar with its

operation and safety features. Save these instructions and be

sure that they remain with the appliance if it is moved or sold,

so that anyone using it throughout its life, will be properly

informed on its usage and safety notices.

For the safety of life and property, keep the precautions of

these user's instructions as the manufacturer is not

responsible for damages caused by omission.

Safety for children and others who are vulnerable people

According to EN standard

This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

According to IEC standard

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

Children should be supervised to ensure that they do not

play with the appliance.

Keep all packaging away from children as there is risk of

suffocation.

If you are discarding the appliance, pull the plug out of the

socket, cut the connection cable (as close to the appliance

as you can) and remove the door to prevent children playing

from suffering an electric shock or from closing themselves

inside it.

If this appliance, featuring a magnetic door seals, is to

replace an older appliance having a spring lock (latch) on the

door or lid, be sure to make the spring lock unusable before

you discard the old appliance. This will prevent it from

becoming a death trap for a child.

General safety

WARNING —This appliance is intended to be used in

household and similar applications such as

-staff kitchen areas in shops, offices and other working

environments;

-farm houses and by clients in hotels, motels and other

residential type environments;

-bed and breakfast type environments;

-catering and similar non-retail applications.

WARNING — Do not store explosive substances such as

aerosol cans with a flammable propellant in this appliance.

WARNING — If the supply cord is damaged, it must be

replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

WARNING — Keep ventilation opening, in the appliance

enclosure or in the built-in structure, clear of obstruction.

WARNING — Do not use mechanical devices or other

means to accelerate the defrosting process, other than those

recommended by the manufacturer.

WARNING — Do not damage the refrigerant circuit.

WARNING — Do not use electrical appliances inside the

food storage compartments of the appliance, unless they are

of the type recommended by the manufacturer.

use of the appliance by a person responsible for their safety.

WARNING ―Food needs to be packed in bags before

putting into the refrigerator, and liquids need to be packed

in bottles or capped containers to avoid the problem that

the product design structure is not easy to clean.

The symbol is a warning and indicates the

refrigerant and insulation blowing gas are flammable.

Warning: Risk of fire / flammable materials

WARNING — The refrigerant and insulation blowing gas are

flammable. When disposing of the appliance, do so only at

an authorized waste disposal centre. Do not expose to

flame.

WARNING —When positioning the appliance, ensure the

supply cord is not trapped or damaged.

WARNING —Do not locate multiple portable socket-outlets

or portable power supplies at the rear of the appliance.

Refrigerant

The refrigerant isobutene (R600a) is contained within the

refrigerant circuit of the appliance, a natural gas with a high

level of environmental compatibility, which is nevertheless

flammable. During transportation and installation of the

appliance, ensure that none of the components of the

refrigerant circuit becomes damaged.

The refrigerant (R600a) is flammable.

If the refrigerant circuit should be damaged:

WARNING — Refrigerators contain refrigerant and gases in

the insulation. Refrigerant and gases must be disposed of

professionally as they may cause eye injuries or ignition.

Ensure that tubing of the refrigerant circuit is not damage

prior to proper disposal.

Replacing the illuminating lamps

WARNING—The illuminating lamps must not be replaced by

the user! If the illuminating lamps is damaged, contact the

customer helpline for assistance.

This warning is only for refrigerators that contain illuminating

lamps.

Daily use

Do not store flammable gases or liquids in the appliance,

There is a risk of an explosion.

Do not operate any electrical appliances in the appliance

(e.g.electric ice cream makers,mixers etc.).

When unplugging always pull the plug from the mains

socket,do not pull on the cable.

Do not place hot items near the plastic components of this

appliance.

Electrical safety

1.The power cord must not be lengthened.

2. Make sure that the power plug is not crushed or damaged.

A crushed or damaged power plug may overheat and cause a

fire.

3. Make sure that you can access the main plug of the

appliance.

4. Do not pull the main cable.

5. If the power plug socket is loose, do not insert the power

plug. There is a risk of electric shock or fire.

6.You must not operate the appliance without the interior

lighting lamp cover.

7.The fridge is only applied with power supply of single phase

alternating current of 220~240V/50Hz. If fluctuation of voltage

in the district of user is so large that the voltage exceeds the

above scope, for safety sake, be sure to apply A.C. automatic

voltage regulator of more than 350W to the fridge. The fridge

must employ a special power socket instead of common one

with other electric appliances. Its plug must match the socket

with ground wire.

It is dangerous to alter the specifications or modify this

product in any way.

Any damage to the cord may cause a short circuit, fire, and/or

electric shock.

-Avoid opening flames and sources of ignition.

-Thoroughly ventilate the room in which the appliance is

situated.

Do not place food products directly against the air outlet on

the rear wall.

Store pre-packed frozen food in accordance with the frozen

food manufacture’s instructions.

The appliances manufactures storage recommendations

should be strictly adhered to relevant instructions for

storage.

Do not place carbonated or fizzy drinks in the freeze

compartment as it creates pressure on the container,which

may cause it to explode,resulting in damage to the

appliance.

Frozen food can cause frost burns if consumed straight from

the freezer compartment.

Do not place the appliance in direct sunlight.

Keep buring candles,lamps and other items with naked

flames away from the appliance so that do not set the

appliance on fire.

The appliance is intended for keeping food stuff and/or

beverages in normal household as explained in this

instruction booklet. The appliance is heavy.Care should be

taken when moving it.

Do not remove nor touch items from the freezer

compartment if your hands are damp/wet,as this could cause

skin abrasions or frost/freezer burns.

Never use the base,drawers, doors etc. to stand on or as

supports.

Frozen food must not be refrozen once it has been thawed

out.

Do not consume ice popsicles or ice cubes straight from

the freezer as this can cause freezer burn to the mouth

and lips.

To avoid items falling and causing injury or damage to

the appliance, do not overload the door racks or put too

much food in the crisper drawers.

This refrigerating appliance is not intended to be used as

●

a built-in appliance.

Adequate air circulation should be around the appliance,

lacking this leads to overheating. To achieve sufficient

ventilation, follow the instructions relevant to installation.

Wherever possible, the back of the product should not be too

close to a wall to avoid touching or catching warm parts

(compressor, condenser) to prevent the risk of a fire, follow

the instructions relevant to installation.

The appliance must not be located close to radiators or

cookers.

Make sure that the mains plug is accessible after the

installation of the appliance.

Service

Any electrical work required to do the servicing of the

appliance should be carried out by qualified electrician or

competent person.

This product must be serviced by an authorized Service

Center, and only genuine spare parts must be used.

1)If the appliance is Frost Free.

2)If the appliance contains freezer compartment.

Installation Important!

For electrical connection carefully, follow the instructions

given in this manual.

Unpack the appliance and check if there are damages on it.

Do not connect the appliance if it is damaged. Report

possible damages immediately to the place you bought it. In

this case retain packing.

It is advisable to wait at least four hours before connecting

the appliance to allow the oil to flow back in the compressor.

Before maintenance, switch off the appliance and disconnect

the mains plug from the mains socket.

Do not clean the appliance with metal objects, steam

cleaner, ethereal oils, organic solvents or abrasive cleansers.

Do not use sharp objects to remove frost from the appliance.

Use a plastic scraper.

Caution!

Care and cleaning

869

In order to improve efficiency

of the cooling system and save

energy, it is necessary to maintain

good ventilation around the appliance

for the dissipation of heat. For this

reason, sufficient clear space should

be available around the refrigerator.

Suggest :It is advisable for there to be

50-70mm of space from the back to

the wall, at least 100mm from its top,at

last 100mm from its side to the wall

and a clear space in front to allow the

doors to open 12 °. As shown in 5

following diagrams.

≥100

1068

≥100

-70mm

566

125°

This appliance performs wellfrom N

to ST.

The appliance may not work properly

if it is left for a longer period at a

temperature above or below the

indicated range.

50~70

Freezer

Fridge

Description of the appliance

View of the appliance

1.Refrigerator lamp

2.Door switch

3.Shelf

4.Vegetable drawer cover

5.Vegetable drawer

6.Freezer upper drawer

7.Freezer lower drawer

8.Adjustable foot

9.Egg rack(inside)

10.Upper rack

11.Middle rack

12.Water storage box part

13.Refrigerator door

14.Lower rack

15.Freezer door

Note: To get the best energy efficiency of this product, please place all shelves,

drawers on their original position as the illustration above.

Reversing the door

Remove the door shelf

press

inwardly

2.Stand the refrigerator upright, first

unscrew the screw① by a cross-

shaped screwdriver, and remove the

upper hinge cover② which is at the

top right corner of the refrigerator,

and use a putty knife or thin-blade

screwdriver to prize the crew hole

cover③ which is at the top left corner

of the refrigerator.

3.Unscrew the flange screws①

which are used for fixing the right

upper hinge part② by a 8mm socket

wrench.

Note:

hand during step 3 to prevent door

dropping.

4. Remove the upper door and place

it on a smooth surface with its panel

upwards. Loose screws② , detach

part①, then install part① to the left

side with screws②.

5. Loose screws used to fix the

middle hinge and remove middle

hinge. Then remove the lower door.

Please hold the upper door by

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Fridgemaster Frigorifero

Fridgemaster

Fridgemaster MTL55250 Istruzioni operative

Fridgemaster

Fridgemaster MBUR60121MF Manuale utente

Fridgemaster

Fridgemaster MUR4892 Manuale utente

Fridgemaster

Fridgemaster MBUL60133 Manuale utente

Fridgemaster

Fridgemaster MS83430BFF Manuale utente

Fridgemaster

Fridgemaster MUR4996 Manuale utente

Fridgemaster

Fridgemaster MS91500IFB Manuale utente

Fridgemaster

Fridgemaster MC55210S Manuale utente

Fridgemaster

Fridgemaster MC50165F Istruzioni operative

Fridgemaster

Fridgemaster MS91515DFF Istruzioni operative

Fridgemaster

Fridgemaster MC55196 Manuale utente

Fridgemaster

Fridgemaster MTL55242 Istruzioni operative

Fridgemaster

Fridgemaster MC55264DS Manuale utente

Fridgemaster

Fridgemaster MTL55249 Manuale utente

Fridgemaster

Fridgemaster MTTR4442 Manuale utente

Fridgemaster

Fridgemaster MTRR102A Manuale utente

Fridgemaster

Fridgemaster MBC54260F Manuale tecnico

Fridgemaster

Fridgemaster MTM48120R Manuale utente

Fridgemaster

Fridgemaster MC60283DFFB Manuale utente

Fridgemaster

Fridgemaster MBC55249 Istruzioni operative

Fridgemaster

Fridgemaster MUR49100 Manuale utente

Fridgemaster

Fridgemaster MUR4894MF Manuale utente

Fridgemaster

Fridgemaster MS91518FBS Istruzioni operative

Fridgemaster

Fridgemaster MUL4892MF Istruzioni operative

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente
