Frigidaire FAC122P1 Manuale utente

M40L0001.eps M40C0001.eps M40M0002.eps 2202049172.eps

Product No. FAC122P1A1 FAC122P1A2 FAC122P1A3 FAC122P1A4

Series ROOM AIR ROOM AIR ROOM AIR ROOM AIR

Color white white white white

Volts 115 115 115 115

BTU-Cooling 12,000BTU 12,000BTU 12,000BTU 12,000BTU

Owner's Guide 220204d031 220204d031 220204d031 220204d031

Installation Instructions COMINSTALLEN COMINSTALLEN COMINSTALLEN COMINSTALLEN

Market North America North America North America North America

Electrolux Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995437042

05/05/18

(EN/SERVICE/WC)

099

ROOM AIR

CONDITIONER

Model No.

FAC122P1

Publication No: 5995437042 FAC122P1

05/05 2

CABINET, FRONT, CONTROLS

FAC122P1 Publication No: 5995437042

# Functional Parts 3 05/05

* Non-Illustrated Parts

CABINET, FRONT, CONTROLS

Model Index: AFAC122P1A (FAC122P1A1)

BFAC122P1A (FAC122P1A2)

CFAC122P1A (FAC122P1A3)

DFAC122P1A (FAC122P1A4)

POS. NO PART NO. DESCRIPTION

1 5304436522 A B C D Base, unit chassis

2 5304436523 A B C D Rail, shutter track, bottom

3 5304436544 A B C D Frame, shutter panel, LH

4 5304436545 A B C D Retainer, shutter lock

5 5304436546 A B C D Shutter, accordion panel

6 5304436547 A B C D Retainer, shutter mount, cabinet sides

7 5304446442 A B C D Cabinet, wrapper/sleeve

8 5304436549 A B C D Rail, shutter track, top

9 5304436550 A B C D Frame, shutter panel, RH

10 5304436599 A B C D Front Assembly, complete panel, includes

11 5304436551 A B C D Panel, front grille, tilt-out

12 5304436552 A B C D Filter, air, plastic frame

13 5304436553 A B C D Frame, front assembly

14 5304436554 A B C D Louver, horizontal

15 5304446443 A B C D Louver, vertical

16 5304437050 A B C D Knob, rotary control

17 5304437051 A B C D Enclosure, control, switch box

17 5304446347 A B C D Dial Plate, display panel

18 5304446345 A B C D Switch, selector, main

19 5304446441 A B C D Panel, control mounting board

20 # 5304437106 A B C D Control, temperature

23 5304436530 A B C D Strap, capacitor mtg.

24 # 5304436526 A - - D Capacitor

24 # 5304436525 - B C - Capacitor

25 5304436524 A B C D Control Box

Publication No: 5995437042 FAC122P1

05/05 4

COOLING & AIR FLOW SYSTEMS

M40M0002

FAC122P1 Publication No: 5995437042

# Functional Parts 5 05/05

* Non-Illustrated Parts

COOLING & AIR FLOW SYSTEMS

Model Index: AFAC122P1A (FAC122P1A1)

BFAC122P1A (FAC122P1A2)

CFAC122P1A (FAC122P1A3)

DFAC122P1A (FAC122P1A4)

POS. NO PART NO. DESCRIPTION

1 5304436556 A B C D Scroll, blower housing, bottom, w/drain tray

2 # 5304436557 A B C D Blower Wheel, centrifugal fan

3 5304436559 A B C D Scroll, blower housing, top

4 5304436558 A B C D Door, fresh air vent, with lever

5 5304436564 A B C D Guide, vent door/lever

6 5304436565 A B C D Cover, blower scroll, top

7 # 5304436563 A B C D Fan Blade, propeller, axial flow

8 # 5304436562 A B C D Shroud, fan housing

9 5304446444 A - C - Motor, fan

9 5304446450 - B - D Motor, fan

10 5304436560 A B C D Seal, fan motor, rubber ring, water proof

11 # 5304436566 A B C D Evaporator

12 5304446465 A B C D Capillary Tube

13 5304446464 A - - D Discharge Tube

13 5304446466 - B C - Discharge Tube

14 5304446463 A - - D Compressor Assy

14 # 5304437081 - B C - Compressor Assy

15 # 5304436572 A - - D Condenser

15 5304446452 - B C - Condenser

16 5304446462 A - - D Suction Tube

16 # 5304436569 - B C - Suction Tube

* # 5304446449 A B C D E F Power Cord, electric, 115 V

* 5304458023 A B C D E F Hardware Kit, installation

Publication No: 5995437042 FAC122P1

05/05 6

WIRING DIAGRAM

2202019172
