Frigidaire FFU2065FW Manuale utente

P08F0071.eps P08D0439.eps P08C0913.eps P08S0411.eps

Product No. FFU2065FW0

Series 134A

Color white

Volts 115

Wiring Diagram 297082200

Owner's Guide 297079200

Market North America

Energy Guide 216795511

Electrolux Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995468278

06/06/14

(EN/SERVICE/MLR)

365

UPRIGHT FREEZER

Model No.

FFU2065FW

Publication No: 5995468278 FFU2065FW0

06/06 2

DOOR

FFU2065FW0 Publication No: 5995468278

# Functional Parts 3 06/06

* Non-Illustrated Parts

DOOR

POS. NO PART NO. DESCRIPTION

1 216522312 Gasket-door, white

2 5303925107 Lock Assy

5 # 216702900 Key, lock

9 216528113 Panel-inner door, frzr

11 216531215 Panel-outer door, white

12 216947300 Nameplate

13 08016354 Door Stop

18 216921200 Handle, white

* 216932500 Nut, flange locking, handle

* 297048000 Screw, anchor, #8, white

21A 08005520 Screw, door stop mtg, 4.0 x 0.7-19.7, flat hd, metric

22 216970800 Bearing, hinge w/o'ring, top

22A 297006800 Bearing-hinge, btm, w/o'ring

26 216524200 Gasket, secondary

27 5303212828 Clip, panel mtg

27* 5304406520 Clip, panel mtg kit, (40)

28 216951600 Rack-door, (5)

32 5309950074 Valve, breather

64 216403700 Plug-button, hole filler, door base

72 216514100 Shelf, tilt out, wire

73 216513900 End Cap, shelf, LH, tilt-out

74 216514000 End Cap, shelf, RH, tilt-out

93 5303161215 Screw, ph truss head, 8-18AB x 0.500

Publication No: 5995468278 FFU2065FW0

06/06 4

CABINET

FFU2065FW0 Publication No: 5995468278

# Functional Parts 5 06/06

* Non-Illustrated Parts

CABINET

POS. NO PART NO. DESCRIPTION

3 216503100 Screen-drain

5 # 216325600 Fan Blade

6 216604100 Breaker Kit w/corners

7 216603600 Breaker Kit w/corners, lock catch

9 216603300 Breaker Kit w/corners, 32", top or bottom

13 216934100 Motor, fan, 115 V

14 216998000 Switch, light/lamp, ramp

15 216846400 Light Bulb/Lamp

16 # 216817600 Socket, light/lamp, 25 W

19 216204901 Gasket-cover evap

23 297087400 Light, signal, amber

25 216820302 Cover-evaporator

26 216503300 Ramp, door closer

28 216247400 Hinge, bottom

29 216313501 Hose-drain

32 5308005500 Drain

34 216816221 Shield-light

35 216629700 Clip

38 216939100 Hinge-upper

40 216809000 Cover-hinge

41 216936800 Screw-hinge, 12-24x.700 HWH

42 216458500 Shelf, wire, 16.69x26.88, white, (3)

42A 216458400 Shelf, 14.50x27.88, (2)

* 216502400 Grommet-shelf mtg

44 216823300 Switch, rocker

47 216661600 Plate, baffle, snap fit

50 216394000 Bracket, fan motor mount

59 216826500 Basket

59A 216486500 Stop-basket, (2)

62 131420300 Screw, cr truss head, 8-18AB x 0.750

63 216396900 Screw, leveling foot, plastic, adjustable

66 # 216713700 Buzzer, alarm

68 08009560 Glide-basket, (4)

69 5305878546 Bumper-basket, (2)

71A 5304416289 Screw, ph truss head, 8-18AB x 0.47, EVAP PANEL

72 297036902 Grille/Kickplate, 32", white

77 # 5308037992 Sensor Assy

78 297013300 Housing-sensor

93A 216629600 Screw, hex washer head, 10-16 x 0.500, tapping

96 297087500 Light-signal, red

105 216926600 Bracket, alarm, 2 lights

105* 216926700 Shield

* 216790600 Harness, alarm

132 5303283898 Screw, 6-20AB x 3/8

166# 297079700 Electronic control, assy

169 216912400 Screw, hex washer head, #8-32 x .500, bracket fan mtr, (2)

* 216795511 Energy Guide

* 5303305324 Paint, touch-up, white

* 297001704 Insulation, 24", drain tube

Publication No: 5995468278 FFU2065FW0

06/06 6

SYSTEM

FFU2065FW0 Publication No: 5995468278

# Functional Parts 7 06/06

* Non-Illustrated Parts

SYSTEM

POS. NO PART NO. DESCRIPTION

1 # 5300083897 Condenser

2 5308000110 Strap-evap/heater, aluminum, (2)

4 # 216938600 Drier-filter

5 # 297093500 Harness, electrical

14 216730700 Heater-defrost

15 # 216997300 Evaporator

15A# 216783200 Heat Exchanger, suct/cap tube

18 216727600 Insulator-evap, styrofoam

19 216727700 Insulator-evap, styrofoam

20 216872200 Thermostat, defrost

27 5308002681 Grommet, compressor

29 # 297048100 Compressor, kit w/grommets, & welded clip

30 297051000 Controller, compressor

31A 216994100 Pan-drain

32 297051100 Clamp, elec cont mtg, compressor

34 5306594529 Sleeve-compressor

35 5303272328 Screw, Ind hex sems, 1/4-28 unfx, compressor

43A 216629700 Clip

86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming

130 216486800 Support, evaporator mtg

* 216502500 Sleeve, suction line

* 297014500 Plug-suction line

* 5303298960 Spacer-tube, 0.237" ID
