Frigidaire FEB386WE Manuale utente

PRODUCT NO. FACTORY NO. COLOR MARKET

FEB386WECG 38257391H6067 BLACK U.S.A.

ELECTRIC WALL OVEN

Model No.

FEB386WE

Inc.

FACTORY PARTS CATALOG

ELECTRIC WALL OVEN

WIRING DIAGRAM # - 318046208

OWNER’S GUIDE # - 318200914

INSTALLATION INSTR. # - 318064310

FRIGIDAIRE HOME PRODUCTS

7075 ORDAN DRIVE

MISSISSAUGA, ONTARIO

CANADA, L5T 1K6

TEL: (905) 565-9200 Publication No.

5995318275

990217

-EN/SERVICE

377

Publication No. FEB386WE

5995318275

02/99 2

CONTROL PANEL

19 19A

LA9923G08

20 23

FEB386WE Publication No.

5995318275

# = Functional Part 302/99

* = Non-Illustrated Part

CONTROL PANEL

A=FEB386WE (FEB386WECG)

POS. NO PART NO DESCRIPTION

19 318030205 APanel-control black

19A 318041702 APanel-decorative with name plate

20 # 318010700 AClock/Timer

21 318029700 ATrim-top stainless steel

23 318111602 ABracket-timer

42 318027409 ATrim-vent black

51 316082300 ANameplate black

80 318111500 ARelay

99 5303300265 AScrew, 8-18 X ½

*3201861 AScrew, 6 X 3/8

*5303300414 ASpacer, cork & rubber

FEB386WE Publication No.

5995318275

02/99 4

CAVITY / ELEMENTS

124

103

103A

LA9923V13

66 68

58B

58A

108

119

127

37 12

129

128

185

56A

185

15 16

150A

150

107

222

131

132

132A

102

177

188

FEB386WE Publication No.

5995318275

# = Functional Part 502/99

* = Non-Illustrated Part

CAVITY / ELEMENTS

A=FEB386WE (FEB386WECG)

POS. NO PART NO DESCRIPTION

1 5303310527 ABack-main

2 318102100 A Shield-oven top

2A 318071700 AShield-oven top

6 318025301 ARack-oven

6A 5303311206 ARack broiler pan

6B 318025401 AShelf-oven

9 5303317977 APan-broiler

10 5303317976 AInsert-broiler pan

12# 318089910 ASwitch-light

14 5308011085 ASocket-light/lamp

15 3201908 ALamp-oven light

16 3201911 AGlass-oven light lens

17 5304400195 ARetainer-lens

37 # 316111203 AProbe-oven temp

41 5303310526 ACover-hinge cutout

54 5303310514 AHousing-oven light

56 318029101 ATrim-bodyside stainless

56A 318029100 ATrim-bodyside stainless

58A 5303310539 AInsulation

58B 5303310538 AInsulation oven back

59 318072504 ATube-oven vent

62 # 5303310518 ATerminal Block

66 # 5303310513 AElement-broil

67 # 5303310512 AElement-bake

68 5304403015 ASupport element

70 5303300142 AShield-insulation

71 318071200 AShield-wire

76 318056202 AFront-oven

80 5303301261 ASpring-oven

81 5303320846 APlate-oven mtg

82 318072300 AShield

83 318089609 ALiner-oven assy

86 5303310524 AChannel-hinge

88 5303311222 ARod-latch

89 # 5304404899 AMotor-latch

89* 318120702 ASwitch-latch

99 318055420 ASupport-adjustable

102 318090900 ASupport oven front

103 318028500 ATrim-base black

103A 318027700 ATrim-base stainless

107 318119600 ACover-fan

108# 318073001 AMotor-fan

109 5303311203 AFan blade

111 5303311205 ANut-fan retainr

119# 318004900 ASwitch-thermal

124 318076903 ABox-vent

125# 5303311202 AMotor-convection

127 5303310542 AAdapter assy

128 5303311163 ABushing

129 5303311164 ASpring

131 318102301 ACover-control housing

132 318101800 AEnd-cover RH

132A 318101801 AEnd-cover LH

150 318072205 ABracket-support RH

150A 318072204 ABracket-support LH

177 318053800 AGasket-vent

185 318014700 ASpacer-oven shield

188 08007817 ASpacer

222 318080000 APlate, Hole convection element

263 5303322885 ASpacer

* 5303211311 AScrew #8 X ½

Publication No. FEB386WE

5995318275 CAVITY/ELEMENTS

02/99 6

POS.NO PART NO DESCRIPTION

*3051070 AScrew, 10-24 X 7/16

*5303302745 AScrew, 10-16 X 1 1/8

*5303323139 AScrew, 10-24 X 29/32

*5303311528 AScrew, trim splasher

*5303323134 AScrew, 8-32 X 3/16

* 5303300265 AScrew 8-18 X ½

*5303323136 AScrew ground

*5303323277 AScrew, 8-18 X 13/32

*5303324184 AScrew, 8 X 5/16

*3131048 AScrew, 8 X 5/8

*5303302745 AScrew, 10-16 x 1 1/8, Black

*# 318078511 ABox & wires assy

*3201885 ANut

A = FEB386WE (FEB386WECG)

FEB386WE Publication No.

5995318275

0299 7

DOOR

15A

LA9923D09

32A

FEB386WE Publication No.

5995318275

# = Functional Part 802/99

* = Non-Illustrated Part

DOOR

A=FEB386WE (FEB386WECG)

POS. NO PART NO DESCRIPTION

4 318041210 AGlass-oven door black

6 318056811 ABaffle-door

7 318106001 AInsulation

9 318048607 ALiner-oven door

10 5303316953 AScrew-handle

12 318053103 ASeal-oven door

13 318009210 APanel, oven door stainless

15 318091101 ABracket glass

15A 318091102 ABracket-glass

16 318041603 AGlass-oven door

17 318042102 ASpacer-glass

18 318053001 ASeal-window

20 318086020 ASpacer-handle

23 5303320452 AHinge-oven door

29 318014400 ASpacer-handle mtg

31 318065100 ALatch-door

32 318056700 ADeflector

32A 318056701 ADeflector

39 318039801 AHandle-door stainless

54 5303300265 AScrew 8-18 X ½

*5303323277 AScrew, 8-18 X 13/32

*5303316982 ATape seal

*5303211311 AScrew, 8 X ½

*5303300414 ASpacer, cork & rubber

*5303325166 AScrew, 8-18 X ½

*5303323175 AAdhesive tape

FEB386WE Publication No.

5995318275

# = Functional Part 902/99

* = Non-Illustrated Part

WIRING DIAGRAM
