Frigidaire FEF304PHDA Manuale utente

FACTORY PARTS CATALOG

ELECTRIC RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF304PHDA FEF304PH ALMOND USA

FEF304PHWA FEF304PH WHITE USA

Publication No.

5995337010

000427

-EN/SERVICE /CML

369

WIRING DIAGRAM # - 316002674

OWNER’S GUIDE # - 316000629

INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE

FEF304PHDA

FEF304PHWA

04/00 2

Publication number

5995337010 FEF304PHDA,FEF304PHWA

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 6/98

Publication number

FEF304PHDA,FEF304PHWA 5995337010

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

A = FEF304PH (FEF304PHDA)

B = FEF304PH (FEF304PHWA)

POS. NO PART NO DESCRIPTION

* 316001554 A B Harness-main

* 316021105 A B Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 A B Screw,semi gim ,8-18 X 1/2 ,black

* 316112500 A B Template, Anti-tip bracket

12 # 316114600 A B Thermostat

14 316022504 A B Light-indicator,250v

18 3202802 A B End Cap,black ,RH

18A 3202801 A B End Cap,black ,LH

32 316102302 A B Knob-thermostat,black

36 316102307 A B Knob-control,black

40 316086827 A B Panel-manifold,black

46 316040201 A B Lens-light/lamp,indicator ,red

49 316073501 - B Panel-backguard,white

49 316073502 A - Panel-backguard,almond

50 316096900 A B Bezel-nameplate,black

51 316095420 A B Nameplate,black

53 3204623 A B Shield-heat,extrusion

54 # 5303051540 A B Switch-6" element

54A# 5301313767 A B Switch-8" element

04/00 4

Publication number

5995337010 FEF304PHDA,FEF304PHWA

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 5 04/00

Publication number

FEF304PHDA,FEF304PHWA 5995337010

CAUTION: Use the part number on all orders, not the position number.

BODY

A = FEF304PH (FEF304PHDA)

B = FEF304PH (FEF304PHWA)

POS. NO PART NO DESCRIPTION

* 316021105 A B Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B Screw,cup pt ,8-18 x 0.375,hinge,ind lght brkt,manifold pnl

* 316073400 A B Plate-weight,(3)

1 316080804 A B Back-main

3 316081034 - B Panel-bodyside,white ,RH

3 316081036 A - Panel bodysidel,almond ,RH

3 316081035 - B Panel-bodyside,white ,LH

3 316081037 A - Panel-body side,almond ,LH

4 5303271756 A B Burner Box

5 316107300 A B Screw-leveling

6 316067902 A B Rack-oven

7 316007007 A B Hinge-oven door,(2)

8 3203540 A B Panel-oven bottom

9 316081900 A B Pan-broiler

10 316082000 A B Insert-broiler pan

12 316027702 A B Switch-oven light

13 316026800 A B Rod-light switch /door

14 316116400 A B Socket-light

15 5303013071 A B Light Bulb/Lamp

21 3014099 A B Spacer-bodyside, (8)

27 5303284616 A B Clip-thermo bulb

28 3051367 A B Clip-wire

29 3051162 A B Glide-drawer,front

41 3131570 A B Cover-hinge cutout

57 316081101 A B Cover-access

58 3200847 A B Insulation,oven bottom

58A 316047707 A B Insulation, 1" ,oven wrapper

58B 316054202 A B Insulation, 1" ,oven back

59 316073601 A B Tube-oven vent

62 # 5303935061 A B Terminal Block

63 5301145190 A B Plate-ground strap

66 # 5303051140 A B Element-broil

67 # 316075102 A B Element-bake,lower oven

68 316075300 A B Support-element, broil

71 316015805 A B Shield-rear wall

72 5303285692 A B Cover-light/switch rod

82 5303289913 A B Shield-insulation

87 316081200 A B Bracket-cable mtg

170 316107200 A B Anti-tip bracket

170* 316116000 A B Screw-Anti tip, 1.75" concrete

170* 5303935180 A B Kit-Anti-tip bracket (complete w/template & screws)

04/00 6

Publication number

5995337010 FEF304PHDA,FEF304PHWA

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 7 04/00

Publication number

FEF304PHDA,FEF304PHWA 5995337010

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

A = FEF304PH (FEF304PHDA)

B = FEF304PH (FEF304PHWA)

POS. NO PART NO DESCRIPTION

* 316021110 A B Screw,semi gim ,8-18 X 1/2 ,black

* 316089600 A B Spacer-drawer,(2)

* 5303280311 A B Screw, waf hd sdr , 10-32 x 5/16 , (2)

* 5308014215 A B Screw

1 316011501 A B Drawer-utility

2 3131975 A B Shield-panel

4 316084405 - B Panel-drawer,white

4 316084406 A - Panel-drawer,almond

7 3051163 A B Glide-drawer,rear

9 316073800 A B Pan-broiler

10 3205234 A B Insert-broiler pan

15 # 3051450 A B Element-surface, 8" , large

15A# 3051449 A B Element-surface, small

16 3051379 - B Main Top,white

16 3051380 A - Main Top,almond

17 316066900 A B Rod-maintop support

18 08067747 A B Bracket-hinge,main top RH

18A 08067746 A B Bracket-hinge,main top LH

19 # 316048413 A B Pan-surface element,chrome ,large/8 inch,(2)

19A# 316048414 A B Pan-surface element,chrome ,small/6 inch,(2)

27 # 5303912666 A B Terminal Block Kit,surface element

28 5303017715 A B Medallion,1 1/2"dia ,black ,surface element

04/00 8

Publication number

5995337010 FEF304PHDA,FEF304PHWA

CAUTION: Use the part number on all orders, not the position number.

DOOR

# - Fast Moving Parts

* - Non Illustrated Parts 9 04/00

Publication number

FEF304PHDA,FEF304PHWA 5995337010

CAUTION: Use the part number on all orders, not the position number.

DOOR

A = FEF304PH (FEF304PHDA)

B = FEF304PH (FEF304PHWA)

POS. NO PART NO DESCRIPTION

* 316021110 A B Screw,semi gim ,8-18 X 1/2 ,black

* 316102200 A B Foil-aluminum

* 5303271648 A B Screw- wafer hd sq dr, 8-18AB x 1/2

* 5303280311 A B Screw, waf hd sdr , 10-32 x 5/16 , (2)

9 316066611 A B Liner-oven door

10 5303281378 A B Screw-handle mtg,wafer head ,10-24F x 3

12 5303202011 A B Seal-oven door,non self-clean

13 3202315 - B Panel-oven door,white

13 3202316 A - Panel-oven door,almond

39 316020204 A B Handle-door,black ,oven

39* 316008401 A B Washer,3/4 x 1/4 ,steel

49 3016755 A B End Cap,black ,(2)

04/00 10

Publication number

5995337010 FEF304PHDA,FEF304PHWA

CAUTION: Use the part number on all orders, not the position number.

WIRING DIAGRAM
