Frigidaire FEF351C Manuale utente

Product No. FEF351CSA FEF351CUA FEF351CWA

Series 30" f/s elec 30" f/s elec 30" f/s elec

Color white black/bisque black/white

Market North America North America North America

Wiring Diagram 316255340 316255340 316255340

Owner's Guide 316257126 316257126 316257126

Installation Instructions 316259200 316259200 316259200

Service Data Sheet 316218513 316218513 316218513

FEF351C.eps L20G0072.eps L20V0098.eps L20T0003.eps L20D0012.eps

316255340d.eps 316255340s.eps

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

Publication No.

5995401584

04/01/15

(EN/SERVICE/ECL)

369

30-INCH FREE-

STANDING ELECTRIC

RANGE

Model No.

FEF351C

Publication No: 5995401584 FEF351C

01/04 2

BACKGUARD

20A

8.8.

FEF351C Publication No: 5995401584

# Functional Parts 3 01/04

* Non-Ilustrated Parts

BACKGUARD

Model Index: AFEF351C (FEF351CSA)

BFEF351C (FEF351CWA)

CFEF351C (FEF351CUA)

POS. NO PART NO. DESCRIPTION

1 5303289640 A B C Shield, backguard, rear wall

14 316022500 A B C Light/Lamp, indicator, 125 V

18 316263404 A - - End Cap, white, RH

18 316263402 - B C End Cap, black, RH

18A 316263405 A - - End Cap, white, LH

18A 316263403 - B C End Cap, black, LH

19 316263332 A - - Panel, backguard, white

19 316263333 - B C Panel, backguard, black

20 # 316207511 A B C Clock/Timer, electronic, ES300

20A 316220804 A - - Overlay, clock, white, ES300

20A 316220805 - B C Overlay, clock, black, ES300

23 316217500 A B C Bracket, clock mtg, (2)

24 316246000 A - - Switch, rocker, white, oven light

24 # 316246001 - B C Switch, rocker, black, oven light

31 316223000 A - - Knob, control, white

31 316223002 - B C Knob, black

46 316040201 A B C Lens, indicator light, red

54 # 316021500 A B C Switch, infinite, small element

54A# 316021501 A B C Switch, infinite, large element

69 5303288565 A B C Screw, truss sqdr, 8-32 x 3/16, switch mtg

* 316021108 A B C Screw, cup pt, 8-18 x 0.375, chrome

* 316021109 A B C Screw, 8-18 x 0.5, chrome

* 316021110 A B C Screw, 8-18 x 0.5, black

Publication No: 5995401584 FEF351C

01/04 4

BODY

FEF351C Publication No: 5995401584

# Functional Parts 5 01/04

* Non-Ilustrated Parts

BODY

Model Index: AFEF351C (FEF351CSA)

BFEF351C (FEF351CWA)

CFEF351C (FEF351CUA)

POS. NO PART NO. DESCRIPTION

1 316201300 A B C Back, main

3 316216402 A B - Panel, bodyside, white, RH

3 316216403 A B - Panel, bodyside, white, LH

3 316216406 - - C Panel, bodyside, bisque, RH

3 316216407 - - C Panel, bodyside, bisque, LH

3* 316021131 A B - Screw, bodyside, 8-18 X 11/16, white

3* 316021133 - - C Screw, bodyside, 8-18 X 11/16, bisque

4 316201401 A B C Burner Box

5 316129200 A B C Screw, leveling, plastic, with stop

6 316067902 A B C Rack, oven

7 316216510 A B C Hinge, oven door, RH

7A 316216511 A B C Hinge, oven door, LH

8 3203540 A B C Panel, oven bottom

9 316081900 A B C Pan, broiler

10 316082000 A B C Insert, broiler pan

12 # 316209901 A B C Switch, oven light/door

14 316116400 A B C Receptacle, oven light

15 5303013071 A B C Bulb/Lamp, oven light

16 08011086 A B C Lens, oven light, glass

17 316087500 A B C Retainer, lens

18 # 316213900 A B C Latch, oven door

21 3014099 A B C Spacer, bodyside

25 3200848 A B C Shield, heat,lower

26 316206300 A B C Support, chassis, (2)

28 316045000 A B C Clip, wiring harness, green, main top

29 3051162 A B C Glide, drawer, front

37 # 316233900 A B C Probe, oven temp

41 316233400 A B C Cover, hinge cutout, RH

41A 316233500 A B C Cover, hinge cutout, LH

42 316206200 A B C Shield, wool, lower

44 316246500 A B C Spacer, oven door

57 316081100 A B C Cover, access

58 3200847 A B C Insulation, oven bottom

58A 316047708 A B C Insulation, 2", oven wrapper

58B 316240100 A B C Insulation, oven back

59 316073604 A B C Tube, oven vent

62 5303935061 A B C Terminal Block Kit

62* 316085600 A B C Insulator

62* 316205500 A B C Nut, hex flange, 3/8 10-32

63 316208500 A B C Plate, grounding strap

66 # 316203200 A B C Element, broil

67 316075103 A B C Element, bake

68 316203400 A B C Support, broil element

71 316015810 A B C Shield, rear wall, galv steel

87 316081200 A B C Bracket, cable mtg

88 316203500 A B C Rod, auto latch

89 # 316135202 A B C Motor, latch/lock

89A 316245800 A B C Bracket, latch, rear

Publication No: 5995401584 FEF351C

01/04 6

BODY

FEF351C Publication No: 5995401584

# Functional Parts 7 01/04

* Non-Ilustrated Parts

BODY

Model Index: AFEF351C (FEF351CSA)

BFEF351C (FEF351CWA)

CFEF351C (FEF351CUA)

POS. NO PART NO. DESCRIPTION

170 5303935180 A B C Anti-tip Kit, w/bracket, screw

170* 316107200 A B C Bracket, anti-tip

170* 316112500 A B C Template, anti-tip

170* 316116000 A B C Screw, concrete, 1.75", anti-tip brkt

* 316269526 A B C Harness, wiring, main

* 318235300 A B C Connector assy., w/3 lugs, & instructions

* 3203550 A B C Plug, button, oven bottom

* 5303305324 A B - Paint, touch-up, white

* 5303305345 - B C Paint, touch-up, black

* 5304414035 - - C Paint, touch-up, bisque

* 316021108 A B C Screw, cup pt, 8-18 x 0.375, chrome

* 5303271648 A B C Screw, wafer hd sq dr, 8-18AB x 0.5

* 5303280311 A B C Screw, wafer hd sq dr, 10-32 x 0.312

* 5303285179 A B C Screw, wafer head, 8-32T x 0.500, black

* 5308014215 A B C Screw, 6-20 x 0.312

Publication No: 5995401584 FEF351C

01/04 8

TOP/DRAWER

FEF351C Publication No: 5995401584

# Functional Parts 9 01/04

* Non-Ilustrated Parts

TOP/DRAWER

Model Index: AFEF351C (FEF351CSA)

BFEF351C (FEF351CWA)

CFEF351C (FEF351CUA)

POS. NO PART NO. DESCRIPTION

1 316011503 A B C Drawer

2 316231500 A B C Liner, drawer

4 316231305 A B - Panel, drawer, white

4 316231309 - - C Panel, drawer, bisque

7 3051163 A B C Glide, drawer, rear

15 # 5303012223 A B C Element, surface, 8", large

15A# 08067762 A B C Element, surface, 6", small

16 316245402 A B - Main Top, white

16 316245405 - - C Main Top, bisque

17 316066900 A B C Rod, maintop support

18 08067747 A B C Bracket, hinge, main top RH

18A 08067746 A B C Bracket, hinge, main top LH

19 5303935054 A B C Pan, surface element, large/8 inch

19A 5303935057 A B C Pan, surface element, small/6 inch

27 # 5303912666 A B C Terminal Block Kit, surface element

28 3017801 A B C Medallion, stainless steel, surf elem

28 5303017715 A B C Medallion, 1 1/2"dia, black, surface element

* # 316253524 A B C Wiring Harness, surface element

* 316058600 A B C Clip, surface element, chrome, (4)

* 316021108 A B C Screw, cup pt, 8-18 x 0.375, chrome

* 316021109 A B C Screw, 8-18 x 0.5, chrome

* 316021110 A B C Screw, 8-18 x 0.5, black

* 5303280311 A B C Screw, wafer hd sq dr, 10-32 x 0.312

* 5308014215 A B C Screw, 6-20 x 0.312

Publication No: 5995401584 FEF351C

01/04 10

DOOR
