Frigidaire PLEFMZ99E Manuale utente

Product No. PLEFMZ99ECA

Series 30" f/s elec

Color stainless

Market North America

Wiring Diagram 316417766

Owner's Guide 316417017

Installation Instructions 316259206

Service Data Sheet 316417615

PLEFM399DC.eps T20G0038.eps T20V0085.eps T20T1836.eps T20D0018.eps

316417766D.eps 316417766S.eps

Electrolux Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995440764

05/07/01

(EN/SERVICE/BJH)

369

30-INCH FREE-

STANDING ELECTRIC

RANGE

Model No.

PLEFMZ99E

Publication No: 5995440764 PLEFMZ99ECA

07/05 2

BACKGUARD

8.8.

15A

77A

96A

77 77A

T20G0038

55A

31 19

14A

54A

46A

20A

100

13A

101

PLEFMZ99ECA Publication No: 5995440764

# Functional Parts 3 07/05

* Non-Illustrated Parts

BACKGUARD

POS. NO PART NO. DESCRIPTION

1 316416100 Shield, backguard, rear wall

13 316414400 Control, bake, mini oven

13A 316095500 Switch, infinite, warmer

14A 316022500 Light/Lamp, indicator, 125 V

15 316411405 Support, backguard, black, RH

15A 316411404 Support, backguard, black, LH

19 316424153 Panel, control, stainless

20 # 316418704 Clock/Timer, electronic, w/mini oven, ES510

20A 316419700 Overlay, clock, black, w/mini oven, ES510

31 316223002 Knob, control, black

36 316223019 Knob, control, black

46 316040201 Lens, indicator light, red

46A 316239000 Lens, LED display

54 316239604 Control, surface element, single, potentiometer

54A 316239605 Control, surface element, dual, potentiometer

55 316247700 Nut, hex control mtg, (4)

55A 316247800 Washer, lock, control mtg

56 316234013 Shield, backguard, black, inner

69 5303288565 Screw, truss sqdr, 8-32 x 3/16, switch mtg

77 316247900 Spacer, power board, (4)

77A 316114100 Spacer, (2)

96 316426300 Board, display, LH

96A 316426301 Board, display, RH

97 316426500 Board, power

98 316426400 Board, user interface

100 5303289910 Screw, 8A, 1", power board mtg

101 316247400 Insulator, switch

* 316416910 Harness, main control

* 316416909 Harness, mini oven cntl

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

* 316021108 Screw, cup pt, 8-18 x 0.375, chrome

* 316021109 Screw, 8-18 x 0.5, chrome

* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995440764 PLEFMZ99ECA

07/05 4

BODY

5A 5

ANTI-TIP

BRACKET

ANTI-TIP

BRACKET

NOTE: Oven Liner N/A

Ass. du four N/A

170

151

58A

58B

17 16

107

161

164

113

112

170

151

T20V0085

59B

59A

110

109

111

106

108

33A

PLEFMZ99ECA Publication No: 5995440764

# Functional Parts 5 07/05

* Non-Illustrated Parts

BODY

POS. NO PART NO. DESCRIPTION

1 316401800 Panel, main back

3 316400104 Panel, bodyside, black, RH

3 316400105 Panel, bodyside, black, LH

5 316272900 Screw, leveling, plastic, rear, (2)

5A 316407200 Leveling Leg Assy, metal, front, (2), bracket & leg

6 316404501 Rack, oven

6A 318219500 Rack, broiler pan

6B 316425400 Rack, oven

8A 316411102 Base, bake element

9 316081900 Pan, broiler

10 316082000 Insert, broiler pan

12 # 316407100 Switch, oven light/door

14 316116400 Receptacle, oven light

15 5303013071 Bulb/Lamp, oven light

16 08011086 Lens, oven light, glass

17 316087500 Retainer, lens

18 # 316405800 Latch Assembly, oven door

21 316408000 Clip, bodyside

33A 316402100 Shield, rear wall, lower

37 # 316217001 Probe, oven temp

42 316407700 Shield, wool, lower

44 316246501 Spacer, oven door

45 316234100 Shield, wire, vent tube

57 316422400 Cover, access

58 316403801 Insulation, oven sump

58A 316406600 Insulation, oven wrapper

58B 316406500 Insulation, oven back

59 316208201 Tube, oven vent, lower

59A 316208304 Tube, oven vent, upper

59B 316247300 Catalyst, oven vent, ceramic

62 5303935238 Terminal Block Kit, w/ground plate

62* 316085600 Insulator

62* 316205500 Nut, hex flange, 3/8 10-32

63 316278800 Plate, grounding strap

66 # 316430900 Element, broil, 4000W

67 316415900 Element, bake, 3500W, 6 pass

68 316429100 Support, element, broil

71 316422300 Shield, rear wall

86 316441300 Receptacle, hinge

86* 316418901 Screw, trilobe, 10-32 x 5/16"

87 316081202 Bracket, cable mtg

88 316203500 Rod, auto latch

89 # 316415400 Motor, latch/lock

106 316404100 Bracket, motor mtg.

107 316026701 Cover, fan

108# 316415800 Motor, fan

109 316136400 Blade, fan

110 316136500 Washer, fan motor

111 316136600 Nut, fan retainer

112 316435200 Standoff, strike plate

113 316431600 Plate, strike, mini oven

Publication No: 5995440764 PLEFMZ99ECA

07/05 6

BODY

5A 5

ANTI-TIP

BRACKET

ANTI-TIP

BRACKET

NOTE: Oven Liner N/A

Ass. du four N/A

170

151

58A

58B

17 16

107

161

164

113

112

170

151

T20V0085

59B

59A

110

109

111

106

108

33A

PLEFMZ99ECA Publication No: 5995440764

# Functional Parts 7 07/05

* Non-Illustrated Parts

BODY

POS. NO PART NO. DESCRIPTION

113* 316436700 Screw, countersunk HD, #10-16 x 1/4, (2)

151 316404600 Shield, bodyside

161# 316211603 Element, convection fan, 350 W

164 316410301 Trim, front, mini oven

170 5303935180 Anti-tip Kit, w/bracket, screw

170* 316107200 Bracket, anti-tip

170* 316112500 Template, anti-tip

170* 316116000 Screw, concrete, 1.75", anti-tip brkt

* # 316416417 Harness, wiring, main

* 3203550 Plug, button, oven bottom

* 5303305345 Paint, touch-up, black

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

* 316021108 Screw, cup pt, 8-18 x 0.375, chrome

* 316021110 Screw, 8-18 x 0.5, black

* 316021132 Screw, 8-18 X 11/16, black

* 316089500 Screw, 10-16 x .486

* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5

* 5303285179 Screw, wafer head, 8-32T x 0.500, black

* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995440764 PLEFMZ99ECA

07/05 8

TOP/DRAWER

26B

26A

100

14A

14B

110

109

T20T1836

108

105

107

106

104

103

102

101

15B

15C

15A

PLEFMZ99ECA Publication No: 5995440764

# Functional Parts 9 07/05

* Non-Illustrated Parts

TOP/DRAWER

POS. NO PART NO. DESCRIPTION

1 316414101 Drawer, mini oven

2 316409803 Liner, drawer, mini oven, w/window

4 316432105 Panel, drawer, stainless, front

7 316437200 Insolator, heat, drawer front

8 316431901 Glass, inner door, mini oven

12 316410700 Seal, door, mini oven

13 316414000 Glide, drawer, mini oven, (2)

14 316414202 Insulation, door top, mini oven

14A 316414201 Insulation, door sides, mini oven, (2)

14B 316414203 Insulation, door bottom, mini oven

15 # 316010205 Element, surface, 6", 1200 W, radiant

15A# 318198824 Element, surface, warmer, 100 W

15B# 316216600 Element, surface, dual, 1700W/2700W

15C# 316280700 Element, double 6", surface, 4400W, w/bridge

16 316421263 Maintop, frame/glass, black

17 316431801 Spacer, glass, mini oven, (2)

18 316436600 Hinge Bracket, maintop, (2)

26 316427600 Channel, element support, (2)

26A 316099202 Bracket, chassis support, rear

26B 316214200 Bracket, chassis support, front

29 316429000 Spacer, handle, (2)

30 316431700 Magnet Assembly, mini oven

33 316432000 Glass, drawer, front

37 # 316217003 Probe, oven temp, mini oven

39 316246100 Handle, door/drawer, stainless

52 316278300 Clip, element mtg

60 316001015 Screw, waf hd sq, 10-24 x 1.25, (2), handle mtg

81 # 316413900 Element, bake, mini oven

85 316411000 Rack, mini oven

100 316410900 Insulation, wrapper, mini oven

101 316410201 Panel, top, mini oven

102 316431201 Panel, oven side, RH, mini oven

103 316431203 Panel, oven side, LH, mini oven

104 316431500 Light Assembly, mini oven

105 316431303 Panel, main back, mini oven

106 316431400 Insualtion, oven back, mini oven

107 316431307 Shield, main back, mini oven

108 316410101 Panel, bottom, mini oven

109 316410800 Insulation, floor, mini oven

110 316410400 Shield, floor, mini oven

* 316416856 Harness, wiring, surface

* 316416901 Harness, mini oven, to probe

* 316416902 Harness, mini oven, to light

* 316264000 Cleaner, cooktop

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

* 316021108 Screw, cup pt, 8-18 x 0.375, chrome

* 316021109 Screw, 8-18 x 0.5, chrome

* 316021110 Screw, 8-18 x 0.5, black

* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995440764 PLEFMZ99ECA

07/05 10

DOOR

60B

10B

T20D0018

14A
