Frigidaire FGUN2642LE Istruzioni per l'installazione

frigidaire.com

Signature Features

26 Cu. Ft. Standard-Depth

Product Dimensions

Height 69-3/8"

(Including Hinges & Rollers)

Width (Doors) 36"

Depth (Including Door) 33-1/8"

More Easy-To-Use Features

Store-More™ Full-Width

Cool Zone™ Drawer

A large capacity full-width drawer provides

enough space to easily store anything

from sheet cakes and large platters to

snacks and juice boxes.

Eortless™ Glide Crisper Drawers

Keep your fruits and vegetables fresh in

our crisper drawers which easily glide out,

and are designed to effortlessly close.

Eortless™ Glide Freezer Drawers

Drawers glide out smoothly and fully

extend, giving you easy access to what’s

inside.

Store-More™ Bins

Our gallon-size bins are designed to store

more, so you can fit a gallon of milk.

SpillSafe® Glass Shelves

SpillSafe® glass shelves slide out for easy

access and are designed to keep spills

contained, making cleanup a breeze.

Energy Saver Plus Technology

Express-Select® Controls

Easily select options with the touch of

a button.

Designer Lighting

Beautiful, ramp-up lighting keeps contents

clearly visible.

Quiet Design

Sound reduction package.

ENERGY STAR®

Sabbath Mode (Star-K® Certiﬁed)

Available in:

1As compared to other consumer refrigeration water

ﬁltration systems.

2In a 24 hour period.

Quick Ice2

Quick Ice delivers up to 37 percent

more ice.

SpaceWise®

Organization System

Makes it easy to keep food organized

and easy to find when you need it

with a Store-More™ full-width drawer,

gallon-size door bins, and Effortless™

Glide freezer drawers.

Best-in-Class Ice &

Water Filtration1

PureSource Ultra® Water Filtration

offers best-in-class water filtration

so you get cleaner, fresher ice and

water for your family.

Real Stainless Steel

Real stainless steel with a protective

coating that reduces fingerprints and

smudges so it’s easy to clean.

French Door Refrigerators

FGUN2642L F / P / E

Stainless

(F)

Pearl

(P)

Ebony

(E)

Specifications

subject to change.

Product Dimensions

A - Height (Incl. hinges and rollers)

B - Cabinet Width / Door Width

C - Depth (Incl. Door)

Depth with Door Open 90˚

69-3/8"

35-5/8" / 36"

33-1/8"

47-1/2"

NOTE: For planning purposes only. Always consult local and national

electric and plumbing codes. Refer to Product Installation Guide for

detailed installation instructions on the web at frigidaire.com.

Standard-Depth French Door Refrigerators

Frigidaire Gallery

Accessories information available

on the web at frigidaire.com

1For use on adequately wired 120V, dedicated circuit having 2-wire

service with a separate ground wire. Appliance must be grounded for

safe operation.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

French Door Refrigerators

FGUN2642L F / P / E 26 Cu. Ft. Standard-Depth

Features

Door Design

Door Handle Design

Cabinet Finish

Door Stops / Door Closers

Door Hinge Covers

Rollers – Front / Rear

Energy Saver Plus Technology

Water Filter Location

Sound Package

Control Features

Controls

Control Panel Location

Number of Control Buttons

Ice Option / Freeze Option

Display On / O Option

Lock

Temp / Door Ajar / Power Failure Alerts

Water Filter Change Indicator Light

Air Filter Change Indicator Light

Refrigerator Features

Lighting

Water Filter Type

Air Filter Type

Fixed Shelves

Quarter-Width Sliding Shelves

Half-Width Sliding Shelves

Cantilever Shelves

Store-More™ Full-Width Deli Drawer

Hanging Wine Rack

Hanging Can Dispenser

Crisper Drawer

Humidity Controls

Dairy Compartment

Store-More™ Fixed Door Bins

Fixed Door Bins

Adjustable Door Bins / Dispenser Bin

Non-Slip Bin Liner / Bottle Retainers

Freezer Features

Self-Closing Pull Out Drawer

Sliding Full-Width Freezer Baskets

Basket Dividers

Lighting

Ice Maker

Certiﬁcations

Sabbath Mode (Star-K® Certiﬁed)

ENERGY STAR®

Speciﬁcations

Total Capacity (Cu. Ft.)

Refrigerator Capacity (Cu. Ft.)

Freezer Capacity (Cu. Ft.)

Power Supply Connection Location

Water Inlet Connection Location

Voltage Rating

Connected Load (kW rating)

@ 120 Volts1

Amps @ 120 Volts

Minimum Circuit Required (Amps)

Shipping Weight (Approx.)

Soft-Arc Doors

Stainless Steel (F),

Color-Coordinated (P / E)

Grey (F),

Color-Coordinated (P / E)

Yes / Yes

Hidden

Adjustable / Yes

Yes

Top-Right Fresh

Food Section

Quiet Pack

Express-Select®

Left Door, Inside Edge

Quick Ice / No

Yes

Yes / Yes / Yes

Yes

Designer

PureSource Ultra®

4 SpillSafe®

Yes

1 Cool Zone™

2 Clear

1 Clear

2 White (1 per door)

4 Two-Gallon Clear / No

Yes

2 Eortless™ Glide

1 (Bottom Basket)

Yes

26.6

18.87

7.66

Right Bottom Rear

Left Bottom Rear

120V / 60Hz / 15 or 20A

1.02

8.5

365 Lbs.
