ROTARY MOWER
FB42
Published 08/01 Serial No. FB42-10017 Through Current P/N 00768114C
© 2004 Alamo Group Inc.
FUERST
1020 S. Sangamon Ave.
Gibson City, IL 60936
217-784-4261
OPERATOR'S MANUAL
This Operator's Manual is an integral part of the safe operation
of this machine and must be maintained with the unit at all
times. READ, UNDERSTAND, and FOLLOW the Safety and
Operation Instructions contained in this manual before
operating the equipment.
$0.00
TO THE OWNER/OPERATOR/DEALER
All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator
who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this
implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
BEFORE YOU START!! Read the safety messages on the implement and shown in your manual. Observe
the rules of safety and common sense!
WARRANTY INFORMATION:
Read and understand the complete Warranty Statement found in this Manual. Fill out the Warranty Registration Form
in full and return it to within 30 Days. Make certain the Serial Number of the Machine is recorded on the Warranty Card
and on the Warranty Form that you retain.
TABLE OF CONTENTS
SAFETY SECTION ....................................................................................................................................... 1-1
Safety Information .................................................................................................................................. 1-2
Safety Decal Location ............................................................................................................................ 1-11
INTRODUCTION SECTION ......................................................................................................................... 2-1
ASSEMBLY SECTION ................................................................................................................................. 3-1
Dealer Set-up Instructions ...................................................................................................................... 3-2
Shear Pin Driveline Installation ............................................................................................................... 3-2
Shield Assembly ..................................................................................................................................... 3-2
A-Frame Installation ................................................................................................................................ 3-3
TailwheelInstallation ............................................................................................................................... 3-3
Hydraulic Relief Assembly ...................................................................................................................... 3-4
OPERATION SECTION................................................................................................................................ 4-1
MAINTENANCE SECTION ........................................................................................................................... 5-1
Lubrication ............................................................................................................................................. 5-2
Gearbox .................................................................................................................................................. 5-3
Driveline ................................................................................................................................................. 5-4
Blades Sharpening ................................................................................................................................. 5-5
Blade & Carrier Removal ........................................................................................................................ 5-6
Blade Carrier Installation ........................................................................................................................ 5-6
Storage .................................................................................................................................................. 5-7
Torque Chart .......................................................................................................................................... 5-7
Gearbox Service Instructions .................................................................................................................. 5-8
SAFETY
SECTION
Safety Section 1-1
Safety Section 1-2FB42 08/01
© 2004 Alamo Group Inc.
SAFETY
SAFETY
A safe and careful operator is the best operator. Safety is of primary importance to the
manufacturer and should be to the owner/operator. Most accidents can be avoided by being
aware of your equipment, your surroundings, and observing certain precautions. The first
section of this manual includes a list of Safety Messages that, if followed, will help protect the
operator and bystanders from injury or death. Read and understand these Safety Messages
before assembling, operating or servicing this mower. This equipment should only be operated
by those persons who have read the Manual, who are responsible and trained, and who know
how to do so safely and responsibly.
The Safety Alert Symbol combined with a Signal Word, as seen below, is used throughout this
manual and on decals which are attached to the equipment. The Safety Alert Symbol means:
“ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!” The Symbol and Signal
Word are intended to warn the owner/operator of impending hazards and the degree of
possible injury faced when operating this equipment.
CAUTION! The lowest level of Safety Message; warns of possible injury. Decals
located on the Equipment with this Signal Word are Black and Yellow.
WARNING! Serious injury or possible death! Decals are Black and Orange.
DANGER! Imminent death/critical injury. Decals are Red and White. (SG-1)
Practice all usual and customary safe working precautions and
above all---remember safety is up to YOU. Only YOU can prevent
serious injury or death from unsafe practices.
Safety Section 1-3
FB42 08/01
© 2004 Alamo Group Inc.
SAFETY
SAFETY
SAFETY
READ, UNDERSTAND, and FOLLOW the following Safety
Messages. Serious injury or death may occur unless care is
taken to follow the warnings and instructions stated in the Safety
Messages. Always use good common sense to avoid hazards.
(SG-2)
Si no lee Ingles, pida ayuda a alguien que si lo lea
para que le traduzca las medidas de seguridad. (SG-3)
PELIGRO! ¡LEA EL
INSTRUCTIVO!
DANGER! Never operate the Tractor or Implement until you have read and
completely understand this Manual, the Tractor Operator’s Manual,
and each of the Safety Messages found in the Manual or on the Tractor
and Implement. Learn how to stop the tractor engine suddenly in an
emergency. Never allow inexperienced or untrained personnel too
operate the Tractor and Implement without supervision. Make sure
the operator has fully read and understood the manuals prior to
operation. (SG-4)
WARNING! Always maintain the safety decals in good readable condition. If the decals are missing, damaged,
or unreadable, obtain and install replacement decals immediately. (SG-5)
WARNING! Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in such
a way as to be clearly visible and legible. When transporting the
Equipment use the Tractor flashing warning lights and follow all local traffic
regulations. (SG-6)
WARNING! Do not modify or alter this Implement. Do not permit anyone to modify or alter this Implement,
any of its components or any Implement function. (SG-8)
DANGER! BEFORE leaving the tractor seat, always engage the brake and/or set the
tractor transmission in parking gear, disengage the PTO, stop the engine,
remove the key, and wait for all moving parts to stop. Place the tractor
shift lever into a low range or parking gear to prevent the tractor from rolling.
Never dismount a Tractor that is moving or while the engine is running.
Operate the Tractor controls from the tractor seat only. (SG-9)
WARNING! Operate this Equipment only with a Tractor equipped with an approved
roll-over-protective system (ROPS). Always wear seat belts. Serious
injury or even death could result from falling off the tractor--particularly
during a turnover when the operator could be pinned under the ROPS.
(SG-7)
Safety Section 1-4FB42 08/01
© 2004 Alamo Group Inc.
SAFETY
SAFETY
DANGER! Never allow children or other persons to ride on the Tractor or Implement.
Falling off can result in serious injury or death. (SG-10)
DANGER! Never allow children to operate or ride on the Tractor or Implement.
(SGM-11)
WARNING! Do not mount the Tractor while the tractor is moving. Mount the Tractor
only when the Tractor and all moving parts are completely stopped.
(SG-12)
DANGER! Start tractor only when properly seated in the Tractor seat. Starting a
tractor in gear can result in injury or death. Read the Tractor operators
manual for proper starting instructions. (SG-13)
DANGER! Never work under the Implement, the framework, or any lifted
component unless the Implement is securely supported or blocked up
to prevent sudden or inadvertent falling which could cause serious
injury or even death. (SG-14)
WARNING! The operator and all support personnel should wear hard hats, safety
shoes, safety glasses, and proper hearing protection at all times for
protection from injury including injury from items thrown by the
equipment. (SG-16)
Safety Section 1-5
FB42 08/01
© 2004 Alamo Group Inc.
SAFETY
SAFETY
SAFETY
WARNING! Transport only at safe speeds. Serious accidents and injuries can
result from operating this equipment at unsafe speeds. Understand the
Tractor and Implement and how it handles before transporting on streets
and highways. Make sure the Tractor steering and brakes are in good
condition and operate properly.
Before transporting the Tractor and Implement, determine the safe
transport speeds for you and the equipment. Make sure you abide
by the following rules:
Be aware of the operating conditions. Do not operate the Tractor with
weak or faulty brakes. When operating down a hill or on wet or rain
slick roads, the braking distance increases: use extreme care and
reduce your speed. When operating in traffic always use the Tractor’s
flashing warning lights and reduce your speed. Be aware of traffic
around you and watch out for the other guy. (SG-19)
2. Test the equipment at a slow speed in turns. Increase the speed
through the turn only after you determine that it is safe to operate at
a higher speed. Use extreme care and reduce your speed when
turning sharply to prevent the tractor and implement from turning
over. Determine the maximum safe turning speed for you and this
equipment before operating on roads or uneven ground.
3. Only transport the Tractor and Implement at the speeds that you
have determined are safe and which allow you to properly control
the equipment.
1. Test the tractor at a slow speed and increase the speed slowly.
Apply the Brakes smoothly to determine the stopping characteristics
of the Tractor and Implement. As you increase the speed of the
Tractor the stopping distance increases. Determine the maximum
safe transport speed for you and this Equipment.
CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE
PERMANENT HEARING LOSS! Tractors with or without an
Implement attached can often be noisy enough to cause permanent
hearing loss. We recommend that you always wear hearing
protection if the noise in the Operator’s position exceeds 80db.
Noise over 85db over an extended period of time will cause severe
hearing loss. Noise over 90db adjacent to the Operator over an
extended period of time will cause permanent or total hearing loss.
Note: Hearing loss from loud noise [from tractors, chain saws,
radios, and other such sources close to the ear] is cumulative over
a lifetime without hope of natural recovery. (SG-I7)
WARNING! Never attempt to lubricate, adjust, or remove material from the Implement while it is in motion
or while tractor engine is running. Make sure the tractor engine is off before working on the
Implement. (SG-20)
Safety Section 1-6FB42 08/01
© 2004 Alamo Group Inc.
SAFETY
SAFETY
WARNING! Periodically inspect all moving parts for wear and replace when
necessary with authorized service parts. Look for loose fasteners,
worn or broken parts, and leaky or loose fittings. Make sure all pins
have cotter pins and washers. Serious injury may occur from not
maintaining this machine in good working order. (SG-21)
WARNING! Always read carefully and comply fully with the manufacturers instructions
when handling oil, solvents, cleansers, and any other chemical agent.
(SG-22)
DANGER! Never run the tractor engine or mower engine in a closed building or without adequate
ventilation. The exhaust fumes can be hazardous to your health. (SG-23)
DANGER! Never allow children to play on or around Tractor or Implement. Children can slip or fall off the
Equipment and be injured or killed. Children can cause the Implement to shift or fall crushing
themselves or others. (SG-25)
DANGER! KEEP AWAY FROM ROTATING ELEMENTS to prevent entanglement
and possible serious injury or death. (SG-24)
WARNING! Do not exceed the rated PTO speed for the Implement. Excessive PTO speeds can cause
Implement driveline or blade failures resulting in serious injury or death. (SG-26)
DANGER! NEVER use drugs or alcohol immediately before or while operating the
Tractor and Implement. Drugs and alcohol will affect an operator’s
alertness and coordination and therefore affect the operator’s ability to
operate the equipment safely. Before operating the Tractor or
Implement, an operator on prescription or over-the-counter medica-
tion must consult a medical professional regarding any side effects
of the medication that would hinder their ability to operate the
Equipment safely. NEVER knowingly allow anyone to operate this
equipment when their alertness or coordination is impaired. Serious
injury or death to the operator or others could result if the operator is
under the influnce of drugs or alcohol. (SG-27)
Indice
Manuali Taglia erba popolari di altre marche
TALEN TOOLS
TALEN TOOLS AVR HGM30 Manuale utente
DEWEZE
DEWEZE ATM-725 Manuale operativo
Weed Eater
Weed Eater 180083 Manuale utente
Husqvarna
Husqvarna Poulan Pro PP185A42 Manuale utente
Better Outdoor Products
Better Outdoor Products Quick Series Manuale utente
Cub Cadet
Cub Cadet 23HP Z-Force 60 Manuale operativo
