FujiFilm Instax SHARE SP-3 Manuale utente

BOC703-200

User’s Guide/Trouble shooting/Safety precautions

Bedienungsanleitung/Fehlerbehebung/Sicherheitsmaßnahmen

Guide d’utilisation/Guide de dépannage/Précautions de sécurité

Manual de instrucciones/Solución de problemas/Precauciones de seguridad

使用說明書/現象、可能的原因及解決措施/安全注意事項

사용설명서/문제 해결/안전을 위한 주의사항

instax_BO-C_6lang.indb 1instax_BO-C_6lang.indb 1 2017/9/14 15:21:092017/9/14 15:21:09

ENGLISH:

See pages 3 to 29.

DEUTSCH:

Siehe Seiten 31 bis 57.

FRANÇAIS:

Voir pages 59 à 85.

ESPAÑOL:

Consulte las páginas 87 a 113.

中國語:

請參閱第 115 到141 頁。

한국어:

143~169페이지를 참조하십시오.

Independent JPEG Group (IJG) Licenses

This software is based in part on the work of the Independent JPEG Group.

instax_BO-C_6lang.indb 2instax_BO-C_6lang.indb 2 2017/9/14 15:21:092017/9/14 15:21:09

Parts Name..............................................4

Before Use................................................5

Inserting/Charging the Battery........5

Inserting the Battery....................................... 5

Charging the Battery...................................... 6

Charging Indicator .......................................... 6

Loading the instax SQUARE Film Pack ...7

Turning on/off the Printer..................8

Checking Remaining Battery Life............... 8

Connecting and Printing....................9

When establishing connection for the

first time:............................................................. 9

When connection is already established:....11

Reprinting............................................. 12

Deleting an Image............................. 13

Unloading a Used instax SQUARE

Film Pack ............................................... 13

About the LED Indication................ 14

SPECIFICATIONS ................................. 15

TROUBLE SHOOTING ........................ 16

IMPORTANT SAFETY NOTICE ......... 20

Handling the Battery ........................ 27

Contents

ENGLISH

• Read “IMPORTANT SAFETY NOTICE” (Page 20)

and “Handling the Battery” (Page 27) for safety

use.

• After reading this User’s Guide, keep it in a

safe, easy to find place where you can refer to

it if needed.

instax_BO-C_6lang.indb 3instax_BO-C_6lang.indb 3 2017/9/14 15:21:102017/9/14 15:21:10

1Remaining battery LED 5USB connector cover 9Battery cover

2Remaining film LED 6USB connector 10 Back cover

3Print exit 7Back cover lock

4POWER button 8REPRINT button

Parts Name

instax_BO-C_6lang.indb 4instax_BO-C_6lang.indb 4 2017/9/14 15:21:102017/9/14 15:21:10

Before Use

• Before using the printer, install the instax SHARE application on your device.

• When you are using an Android OS device, search for“instax SHARE”in the Google Play, then install the application.

* System requirements of an Android OS device: Android Ver 4.0.3 or later and Google Play are installed.

• When you are using an iOS device, search for“instax SHARE” in the App Store, then install the application.

* System requirements of an iOS device: iOS Ver 8.0 or later is installed.

You may not be able to print from some devices even if you have installed the instax SHARE application and your

device meets the requirements listed here.

• The battery is not fully charged at shipment. Be sure to charge it before using the printer.

Access instax SHARE website for the latest information on system requirements.

Inserting/Charging the Battery

Inserting the Battery

Pull down the battery cover lock

to open the battery cover.

Insert the battery according to the arrow on

it. Make sure the yellow line on the battery

aligns with the mark on the printer.

Align the tabs on the battery cover

and push the battery cover lock

until it clicks into place.

~Ÿ !

instax_BO-C_6lang.indb 5instax_BO-C_6lang.indb 5 2017/9/14 15:21:102017/9/14 15:21:10

Inserting/Charging the Battery (Continued)

Charging the Battery Charging Indicator

Indication Battery status/Action

Lights red (ON)

Flashes red (OFF) Charging is in progress.

Lights orange (ON)

Flashes orange (OFF) Charging is half complete.

Lights green (ON)

Flashes green (OFF) Charging is almost complete.

Flashes green, then

goes off (OFF) Charging is complete.

Flashes green and

red alternately, or

flashes red, then

goes off

An error has occurred. Stop

charging.

Charging from a PC:

• Connect the printer and PC directly. Do not connect

them via a keyboard or USB hub.

• If the PC enters sleep mode while charging is in

progress, charging will stop. If you continue charging,

resume the PC and reconnect the USB cable.

• You may not charge the printer from a PC depending

on your PC specifications, settings, or status.

Connect the printer and an AC power adapter supplied

with your smartphone using the supplied USB cable, then

connect the AC power adapter to an indoor power outlet.

The remaining battery LED indicates the battery charge

status. For details, see the table on the right column.

• Use an AC adapter to meet the rated output below:

DC 5.0 V/1000 mA

• You can print an image while charging is in progress.

• Charging time is approximately three hours.

Be careful of the orientation. Connect the USB cable

with the mark ( ) on the terminal facing up.

instax_BO-C_6lang.indb 6instax_BO-C_6lang.indb 6 2017/9/14 15:21:102017/9/14 15:21:10

Loading the instax SQUARE Film Pack

~Ÿ

Caution

Do not open the back cover until you have used up all the film; otherwise, the rest of the film will

become exposed and turn white.The film can no longer be used.

• When you load the film pack, never press the two rectangular holes on the back of the film pack.

• Never use a film pack beyond its shelf life; otherwise, it may damage the printer.

Use FUJIFILM Instant Film “instax SQUARE”only. The instax mini film or instax WIDE film cannot be used.

Notes on the film pack

• Each FUJIFILM Instant Film“instax SQUARE” pack contains 1 black film protective cover and 10 film sheets.

• Do not remove the film pack from its inner bag before loading it into the printer.

• The film cover is ejected automatically when the back cover is closed.

For details, refer to the instructions and warnings on FUJIFILM Instant Film "instax SQUARE".

Continued on the next page

Pull the back cover lock down to open the back

cover.

Hold both sides of the film pack, align the bottom of the

film pack on the groove of the film chamber (1), then insert

it straight (2).

instax_BO-C_6lang.indb 7instax_BO-C_6lang.indb 7 2017/9/14 15:21:102017/9/14 15:21:10

Loading the instax SQUARE Film Pack

(Contunued)

⁄

Close the back cover.

Make sure the back

cover lock clicks into

place.

The film cover (black) is ejected

automatically when the back

cover is closed. Remove the film

cover from the print exit.

Turning on/off the Printer

Press and hold the POWER button for approx. 1 second

to turn the printer on or off.

Turning on the printer lights up the remaining battery

LED.

If no operation occurs for a certain period of time, the

printer turns off automatically.

Checking Remaining Battery Life

Use the remaining battery LED to check when turning

the printer on or while printing is in progress.

Indication Remaining battery life

Green Sufficient

Orange At half capacity

Red Low. Charging the battery is

recommended. (See page 6.)

Printer turns off

after flashing red.

No battery capacity remains.

Charge the battery. (See page 6.)

instax_BO-C_6lang.indb 8instax_BO-C_6lang.indb 8 2017/9/14 15:21:102017/9/14 15:21:10

Connecting and Printing

Continued on the next page

Wireless LAN Setup for iOS Devices

When you are using an iOS device, follow the procedure

below to perform wireless LAN setup.

1. Select “ON” for “Wi-Fi” in the “Settings” menu of your device.

2. Tap the network name (printer name) under “Choose a Network”

When establishing connection for

the first time:

Press and hold the POWER button for approx.

1 second to turn the printer on.

The remaining battery LED lights up.

Start the downloaded application “instax SHARE”.

Select the picture to print or take a picture.

Notes on Printing

1. Place the printer vertically.

2. When printing, put the printer on a steady surface

such as a desk.

instax_BO-C_6lang.indb 9instax_BO-C_6lang.indb 9 2017/9/14 15:21:112017/9/14 15:21:11

⁄

Connecting and Printing (Continued)

Tap“Connect and print”.

When a printer is detected,

tap“Connect”. If multiple

printers are detected, select

the printer to connect from

the list.

Printer's identifier (SSID) is

located on the bottom of the

printer.

Enter the factory default

password (1111) or the one you

specified, then tap“OK”.

The printer starts printing.

To reset the password to the factory default

(1111), turn the printer on while holding the

REPRINT button.

When the film has been ejected (the

printer stops making a sound), grasp

the edge of the film, then take it out.

1 remaining film LED turns off every

time you print an image.

Before tapping“Connect

and print”, tapping on

the lower right displays the

edit menu. You can add

a template or adjust an

image on this menu.

Tap“Done”to exit from the

menu.

When printing, put the

printer on a steady surface

such as a desk.

㻵㻺㻿㼀㻭㼄㻙㻝㻝㻝㻝

㻝㻝㻝㻝

instax_BO-C_6lang.indb 10instax_BO-C_6lang.indb 10 2017/9/14 15:21:112017/9/14 15:21:11
