Fujitsu Siemens Computers AMILO Xi 3650 Manuale utente

Issue January 2009

Version 5

AMILO Notebook Xi 3650

The art of entertainment

Pages 6

Experience impressive entertainment, exciting new technologies, inspiring innovations and features unified in the

AMILO Notebook X Series.

Key Features

Processor technology

Latest Intel® Centrino® 2 processor technology (optional)1for high-definition digital

entertainment experience, blistering performance, longer-lasting battery life and the

new wireless standard for connectivity

Operating System

Windows Vista® Home Premium

Innovation

NVIDIA® GeForce® 9600M GT graphic card with 512 MB GDDR3 dedicated high-

speed VRAM deliver the ultimate balance between mobility and performance for

astounding HD playback capabilities combined with 3D features to enable

visually-intense applications and games

NVIDIA HybridPower™ technology allows you to unleash graphics performance when

you need it, or instantly switch gears to a lower power mode from the motherboard

GPU for longer battery life and quieter operation. This reduces system power

consumption dramatically and extends battery life by up to 25%

Reliability

Spill-proof keyboard2to protect your notebook against accidentially spilt liquids

- Enough time to shut down the notebook

- Have the liquid removed from the notebook

- Protects your investment and your data

Engineered in Germany means the test center in Germany tests conformity to

international standards and customer-specific requirements

A+ grade LCD panels for better picture quality

Ease of use

Silent mode function that causes a noticeable reduction in fan noise

Multimedia LightTouch™ bar and integrated Vista remote control let you easily play,

stop or pause your DVDs or music CDs

Multimedia and Entertainment

18.4-inch HD+ or Full HD display with 16:9 aspect ratio and BrilliantView technology

that provides vivid colors, amazing sharpness and impressive contrast

The integrated AMILOcam (1.3 mega pixels) with low-light technology for great video

quality even in low-light conditions and the built-in digital array microphone are perfect

for Internet telephony (VoIP) and video chats

Connect the AMILO Notebook Xi 3650 to an external display via HDMI (with HDCP

support)

Options

Integrated Blu-ray Disc™ drive for the ultimate entertainment experience

Dual hard disk drive with Raid 0/1 function

- Raid 0 function: implements data striping to provide the best possible performance

- Raid 1 function: defines disk mirroring for simultaneous writing of data on two

disks, so if one drive becomes defect, all data can be accessed on

the second drive

Model: Reveal white

Model: Eclipse black

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 2 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

Operating systemand Recovery

Operating system Genuine Windows Vista® Home Premium (32-bit version)

Fujitsu Siemens Computers Recovery Program

Backup and restore the original status of the hard disk and create system

restore disks

or individual recovery media on CD or DVD are included

Product Design

Color Reveal white or eclipse black

Architecture

System architecture Intel® Centrino® 2 processor technology (optional)1

Chipset Intel® GM45 + ICH9M-Enhanced

Processors3

Intel® Core™2 Duo processor T5800 (2.0 GHz, 800 MHz FSB, 2 MB L2 cache)

T6400 (2.00 GHz, 800 MHz FSB, 2 MB L2 cache

P7350 (2.0 GHz, 1066 MHz FSB, 3 MB L2 cache)

P7450 (2.13 GHz, 1066 MHz FSB, 3 MB L2 cache)

P8400 (2.26 GHz, 1066 MHz FSB, 3 MB L2 cache)

P8600 (2.4 GHz, 1066 MHz FSB, 3 MB L2 cache)

T9400 (2.53 GHz, 1066 MHz FSB, 6 MB L2 cache)

T9550 (2. 66 GHz, 1066 MHz FSB, 6 MB L2 cache)

Memory 2 SO-DIMM memory slots (no memory on board)

Memory speed 1066 MHz

Memory type DDR 3 RAM

Memory modules 1024 or 2048 MB

Max. memory size3, 44096 MB

Drives

Hard disk drive

HDD type SATA

HDD size 2.5-inch

HDD speed 5400 rpm

HDD cache 8 MB

HDD capacity3250, 320 or 500 GB with single HDD;

500 (2x 250), 640 (2x 320) or 1000 (2x 500) GB with dual HDD

Option3:

HDD type SATA

HDD size 2.5-inch

HDD speed 4200 rpm

HDD cache 8 MB

HDD capacity3500 GB with single HDD;

1000 (2x 500) GB with dual HDD

Raid function (optional, if two HDDs are installed)

Raid 0: stripe set for performance

Raid 1: mirroring for security

Raid off: two physical HDDs

Optical disc drive3 (built-in)

ODD type SATA

ODD technology SuperMulti-format DVD burner with double layer (DL) support

ODD read speed CD-ROM 24x, DVD-ROM 8x

ODD write speed CD-R 24x, CD-RW 16x, DVD+R 8x, DVD-R 8x, DVD+RW 8x,

DVD-RW 6x, DVD+R DL (8.5 GB) 4x, DVD-R DL (8.5 GB) 4x,

DVD-RAM 5x

Blu-ray Disc™ (optional)3

ODD technology Built-in Blu-ray Disc™ drive incl. SuperMulti-format DVD burner with

double layer (DL) support

ODD read speed BD 1.6x, CD-ROM 24x, DVD-ROM 8x

ODD write speed CD-R 8x, CD-RW 8x, DVD+R 8x, DVD+RW 4x, DVD-R 8x, DVD-RW 4x,

DVD+R DL (8.5 GB) 2.4x, DVD-R DL (8.5 GB) 2x, DVD RAM 5x

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 3 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

Display

Display type BrilliantView LCD with dual lamp (90% NTSC)

Aspect ratio 16:9

Resolution type Full HD

Display size 18.4-inch

Display resolution (intern) 1920 x 1080 pixels

Display resolution (extern) 1920 x 1200 pixels

Reaction time (typ.) 8 ms

Brightness (typ.) 300 NIT

Contrast (typ.) 800 :1

Compliance with standards ISO 13406-2 class II

Option3

Display type BrilliantView LCD

Aspect ratio 16:9

Resolution type HD+

Display size 18.4-inch

Display resolution (intern) 1680 x 945 pixels

Display resolution (extern) 1920 x 1200 pixels

Reaction time (typ.) 16 ms

Brightness (typ.) 200 NIT

Contrast (typ.) 600 :1

Compliance with standards ISO 13406-2 class II

Graphics

Dedicated graphics (full name) NVIDIA® GeForce® 9600M GT

Dedicated video memory 512 MB GDDR3, 1066 MHz

Onboard graphics chip Mobile Intel® Graphics Media Accelerator 4500MHD

Shared video memory5Up to 1295 MB (depending on installed main memory)

3D Benchmark 2006 Up to 5044 points (depending on configuration)

Graphic features NVIDIA® HybridPower™ technology (hybrid graphic technology)

NVIDIA® PureVideo® HD technology

DirectX® 10 support

Interfaces

Video 1x HDMI (1.3) (incl. HDCP and S/PDIF out), 1x VGA

Audio Front: 1x line in, 1x microphone in, 1x line out /headphone out,

Side: 1x line out / S/PDIF out

Network 1x LAN (RJ-45)

Data 1x eSATA combined with USB 2.0, 3x USB 2.0,

1x IEEE1394 (FireWire™), 1x CIR,

1x ExpressCard slot (54 / 34 mm),

1x 15-in-1 card reader6

SD, miniSD, MicroSD, SDHC,

MS, MS-Duo,

MMC, RS-MMC, MMC-Micro,

MSPRO, MS-PRO Duo, MS-Pro HG, MS-Pro HG Duo, M2,

xD picture card

Power supply 1x DC-in

Communication

Integrated Bluetooth® 2.1

LAN (Local Area Network) Gigabit Ethernet LAN (10 / 100 / 1000 Mbps)

Built-in WLAN (Wireless Local Area Network) Yes

WLAN brand name Intel® WiFi Link 5100 AGN

WLAN type draft-n 802.11a/g/n

WLAN max. data rate up to 300 Mbps

WLAN encryption WEP, WPA and WPA2

For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO,

PL, AT, PT, SE, SK, ES, CZ, HU, UK, CY

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 4 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

Multimedia

Audio Support of high-definition audio for S/PDIF output with up to 7.1 channels;

7.1 audio support also via 4x audio jacks (analog)

Audio chip Realtek ALC888

Speakers 2x built-in speakers (2 W each)

Microphone Built-in digital array microphone

Subwoofer 1x built-in subwoofer (3 W)

Input device Sound volume control via function key or via LightTouch™ bar

AMILOcam

Image sensor 1.3 mega pixels webcam

Frames per second 307

Features Powered by Logitech®

Auto focus

Automatic brightness adjustment with status LED (blue: on, red:

streaming / application on)

Low-light technology for great video-quality even in dark

surrounding

Input devices / Control buttons

Power button Located left of the keyboard, back lighted

Keyboard Spill-proof keyboard2with 85 keys, 21 key number block

Touchpad Hidden touchpad, with left and right mouse button,

touchpad disable function via function key combination (Fn+F6)

Multimedia keys Multimedia LightTouch™ bar located on top of the keyboard to launch the

following applications:

Silent mode (reduce noise level / fan speed, by reducing the CPU

performance, office applications, Internet and DVD playback are not

affected)

Hybrid graphics to switch between onboard graphics for extended

battery runtime and external graphics for better performance

DVD playback

Skip rewind

Play / pause

Skip forward

Volume control

Remote Control 26-key Vista remote control, shipped in ExpressCard slot

Hot keys The following hot keys or key combinations are available

Fn+F1 WLAN / Bluetooth on / off

Fn+F3 Mute on / off

Fn+F4 Volume down

Fn+F5 Volume up

Fn+F6 Touchpad on / off

Fn+F7 AMILOcam on / off

Fn+F8 Brightness down

Fn+F9 Brightness up

Fn+F10 Display switch

Fn+F11 Silent mode

Fn+F12 Suspend

Number block

4 individually configurable quick-start application buttons (A1, A2, A3, A4)

Status indicators The notebook has 3 status LEDs:

Power status (& suspend)

Blue (always on): on; Blue blinking: stand by; None: off

Battery charge

Blue (always on): full; Blue blinking: charging;

Red blinking: < 10 % capacity

WLAN / Bluetooth®

Blue: on; None: off

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 5 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

Security

Supervisor and user password Yes

Kensington lock Yes

Lid switch (hidden) Yes

ACPI functions ACPI 3.0 compliant for Vista requirement

Power on stand by (S1 LCD off)

Stand by / energy saving mode (S3 save to RAM)

Hibernate mode (S4 save to disk)

Off mode (S5 soft off)

Power System

Battery8

Battery type Lithium-Ion battery

8 cells, 14.8 V / 2400 mAh (cell) / 4800 mAh (pack)

Battery life (idle mode)9Onboard graphics: up to 4.7 hours

Dedicated graphics: up to 3.6 hours

Battery life (DVD playback)10 Onboard graphics: up to 3.1 hours

Dedicated graphics: up to 2.7 hours

Battery charging time (idle mode)11 Onboard graphics / dedicated graphics (charging 90%): up to 2.1 hours

Battery charging time (maximum active mode)12 Onboard graphics (charging 90%): up to 2.2 hours

Dedicated graphics (charging 90%): up to 2.5 hours

Battery charging time (normal use)13 Onboard graphics (charging 90%): up to 2.1 hours

Dedicated graphics (charging 90%): up to 2.05 hours

Battery charging time (off mode) Onboard graphics (charging 90%): up to 2.15 hours

Dedicated graphics (charging 90%): up to 2.1 hours

AC Adapter Dynamic charge supported, ACPI 3.0 supported

Wide Range AC adapter 110 - 240 V AC, 50 - 60 Hz

Output 90 W with 20 V DC, 4.5 A

Energy consumption

S0 (idle mode) Onboard graphics: 11.15 W; Dedicated graphics: 17.30 W

S0 (max. active mode)14 Onboard graphics: 58.59 W; Dedicated graphics: 84.14 W

S3 (stand by / energy saving mode) Onboard graphics: 2.05 W; Dedicated graphics: 1.56 W

S4 (hibernate) Onboard graphics/Dedicated graphics: 0.51 W

S5 (off mode) Onboard graphics/Dedicated graphics: 0.36 W

Noise emission

Idle mode15 27.8 dB(A) (silent mode off)

Maximum active mode16 28.3 dB(A) (silent mode off)

Operating conditions

Operational 5 °C to 35 °C (ambient temperature)

10 % to 90 % relative humidity, non-condensing

Dimensions and weight

W x D x H 438 x 294 x 43.5 (front) / 50.5 (back) mm

Weight 3.9 kg17

Certifications GOST (WLAN)

CE Marking

R&TTE (WLAN, Bluetooth®)

Warranty Country specific terms

Application Software

Home office Microsoft® Works

Microsoft® Office Home and Student Trial

Adobe Reader

Windows Mail (within Vista operating system)

Windows Calendar (within Vista operating system)

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Xi 3650 Page 6 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

delivery subject to availability. Any liability that the data and illustrations are complete, actual or

correct is excluded.

Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which

by third parties for their own purposes may infringe the rights of such owner.

For further information see http://www.fujitsu-siemens.com/terms_of_use.html

Published by

FSC IP CLI PMKT

Christiane Geis

Fujitsu Siemens Computers

http://www.fujitsu-siemens.com/

Company stamp

Multimedia Nero Essentials S (CD / DVD write software)

Vista DVD Playback Pack (DVD playback software)

Windows Media Player (within Vista operating system)

Windows Media Center (within Windows Vista® Home Premium

operating system)

Logitech® QuickCam® application software

Optional3

CyberLink Power DVD (playback software for Blu-ray Disc™, only with

Blu-ray Disc™ drive)

Internet Microsoft® Internet Explorer

Country specific Internet provider

Security Norman security software solution

Accessories

Included AC adapter 90 W

First Battery 8 cells

Integrated remote control

Cleaning wipe

Optional Find out more: www.fujitsu-siemens.com/accessories

Manuals Manual (on hard disk), quick start guide, safety guide, warranty guide,

recovery guide

Drivers Updates downloadable at http://www.fujitsu-siemens.com

Awards

Notebookjournal.de

Germany – 01/2009

“Best 18.4 inch notebook”

1Processor technology depends on actually installed processor:

2DISCLAIMER: The keyboard is spill-proof up to 50ml. This is enough to protect your notebook from an accidental spill. However, we recommend a backup as well

as a system shut-down should liquids come into contact with the keyboard. The spill-proof protection does not prevent data loss caused by water damage. If this

should happen, please contact your local customer service desk.

3Depending on exact configuration. Please check at your local retailer

4DISCLAIMER: Up to 1 GB may not be available with 32-bit operating systems due to system resource requirements if system is preinstalled with 4096 MB RAM

5Shared video memory size may vary depending on configuration. Used video memory size depends on Microsoft® Windows Vista® memory management

- 1024 MB system memory enables up to 271 MB shared memory

- 2048 MB system memory enables up to 783 MB shared memory

- 3072 MB system memory enables up to 1295 MB shared memory

- 4096 MB system memory enables up to 1295 MB shared memory

6An adapter is needed for the following card formats: RS-MMC, MMC-Micro, miniSD, MicroSD, SDHC, MS-Duo, MS-PRO Duo, MS-Pro HG, MS-Pro HG Duo, M2

7AMILOcam frame rate can vary significantly depending on the used software application

8DISCLAIMER: Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time

varies depending on usage. The recharge capacity may decrease after some months so that the battery lifetime as well as operating time can not be assured for the

whole lifetime of the notebook

9Tested with Battery Mark 4.0.1 (“power saver mode”)

10 DVD playback tested with Vista DVD playback

11 Tested without test program

12 Tested with 3DMark 2006

13 DVD playback tested with Vista DVD playback

14 Tested with 3DMark 2006

15 Tested according to ISO 7779 and ISO 9296

16 Tested with QAFE 8.01 / 2. sieve.exe (CPU stress test) / Diskload.exe according to ISO 7779 and ISO 9296

17 Weight may vary depending on actual configuration

The configuration described in this document is generic only and non-binding. For the exact

configuration of your AMILO, please contact your licensed dealer.

Altri manuali per AMILO Xi 3650

Altri manuali Fujitsu Siemens Computers Computer portatile

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO A1650G Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO M1425 Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers Amilo L1310G Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO D 6800 Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers LIFEBOOK E8310 Scheda informativa del prodotto

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Pro V3505 Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Pro V Series Scheda informativa del prodotto

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Pro V7010 Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers lifebook S6010 Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Pi 3625 Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers LIFEBOOK B Series Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers LIFEBOOK E Series Scheda informativa del prodotto

Fujitsu Siemens Computers

Fujitsu Siemens Computers answers 2 LIFEBOOK C Series Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Xa 2528-12P Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Pa 3553 Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Li Series Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO A1650G Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Si 2636 Scheda informativa del prodotto

Fujitsu Siemens Computers

Fujitsu Siemens Computers Lifebook C Series Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers ESPRIMO Mobile D9500 Scheda informativa del prodotto

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO A7640 Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO A Series Manuale utente

Fujitsu Siemens Computers

Fujitsu Siemens Computers LIFEBOOK P Series Scheda informativa del prodotto

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Li Series Scheda informativa del prodotto

Manuali Computer portatile popolari di altre marche

HP ze2401xt - Pavilion Notebook PC Manuale utente

Velocity

Velocity NoteMagix M10 Manuale utente

Dell

Dell Alienware 17 R2 Manuale utente

Toshiba

Toshiba A105-S2236 Manuale utente

HP ENVY 17 Manuale

Winbook

Winbook LM Manuale utente

Dell

Dell Inspiron 1464 Manuale utente

Dell

Dell Inspiron 15R 5537 Manuale utente

HP PROBOOK 4520S Manuale

Dell

Dell Latitude ATG D620 Manuale utente

Sony

Sony VAIO PCG-FX270 Manuale utente

Dell

Dell Latitude 7310 Manuale utente

Dell

Dell Precision GU806 Manuale utente

Sony

Sony VAIO PCG-R505JLK Manuale utente

Lenovo

Lenovo THINKPAD X32 Manuale utente

HP Compaq tc4200 Guida rapida

Toshiba

Toshiba mini NB300 Manuale utente

Lenovo

Lenovo ThinkPad X201 Tablet Manuale
