MCM 153V

Farbbildschirm

Color monitor

Moniteur couleur

Monitor de color

Monitor a colori

Färgskärm

Kleurenbeeldscherm

Betriebsanleitung

Operating Manual

Deutsch

lish

Fran

ais

Español

Italiano

Svenska

Nederlands

Ausgabe Oktober 1999

October 1999 edition

VESA, DDC und DPMS sind eingetragene Warenzeichen der Video Electronics Standards

Association.

Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

Zuwiderhandlungen verpflichten zu Schadenersatz.

Liefermöglichkeiten und technische Änderungen vorbehalten.

VESA, DDC and DPMS are registered trademarks of Video Electronics Standards

Association.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved.

Delivery subject to availability. Right of technical modification reserved.

A26361-K563-Z100-2-5E19 English

Contents

Introduction....................................................................................................................................... 1

Notational conventions.............................................................................................................. 1

Important notes................................................................................................................................. 2

Safety ....................................................................................................................................... 2

Manufacturer’s notes................................................................................................................. 3

Note on X-ray radiation ............................................................................................................. 3

FCC Class B Compliance Statement................................................................................................ 4

Important note on power cable.................................................................................................. 4

Disposal and recycling.............................................................................................................. 6

Checking the contents of the consignment........................................................................................ 6

Installing an ergonomic video workstation......................................................................................... 7

Attaching the monitor base ............................................................................................................... 8

Connecting the monitor..................................................................................................................... 9

Operation of the monitor ................................................................................................................. 10

Switching the monitor on......................................................................................................... 10

Switching the monitor off......................................................................................................... 10

Notes on power management ................................................................................................. 11

Changing the monitor settings................................................................................................. 12

Notes on ergonomic color adjustment..................................................................................... 14

Technical data ................................................................................................................................14

VESA-DDC-compatible VGA interface.................................................................................... 15

Preset operating modes.......................................................................................................... 15

Pin assignment D-SUB ........................................................................................................... 16

Error handling ................................................................................................................................. 17

A26361-K563-Z100-2-5E19 English - 1

Introduction

Your new MCM 153V color monitor possesses a whole range of useful features and functions, e. g.:

• 15" (38 cm) high-resolution CRT (0,28 mm dot pitch)

• automatic scanning of all horizontal frequencies from 30 to 54 kHz and all refresh rates (vertical

frequencies) from 50 to 120 Hz

• digital screen controller with microprocessor for storing 26 different display modes

• VESA-DDC compatibility

• power management for reducing power consumption by up to 95% when the PC system is not

in use

• compliance with the latest ergonomic standards (ISO 9241-3)

• compliance with the recommendations in accordance with MPR II

This Operating Manual contains important information you require to start up and run your monitor.

The monitor interworks closely with the screen controller (graphics card) of your PC. It processes

the data supplied to it by the screen controller. The screen controller/the associated driver software

is responsible for setting the modes (resolution and refresh rate).

Target group

You don't need to be an "expert" to perform the operations described here. Do, however, read the

chapter with the important notes in the Operating Manual of your PC and in this Operating Manual.

In the event of any problems occurring, please contact your sales office or our service center.

Further information

Details of how you set the resolution and refresh rate are provided in the documentation on your

screen controller/the associated driver software.

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

!Pay particular attention to texts marked with this symbol. Failure to observe this warning

endangers your life, destroys the system, or may lead to loss of data.

iThis symbol is followed by supplementary information, remarks and tips.



Texts which follow this symbol describe activities that must be performed in the order shown.

"Quotation marks" indicate names of chapters and terms that are being emphasized.

Color monitor MCM 153V

2 - English A26361-K563-Z100-2-5E19

Important notes

!In this chapter you will find information regarding safety which is essential to take note of

with your monitor.

Safety

This device complies with the relevant safety regulations for data processing equipment, including

electronic office machines for use in an office environment. If you have any questions, contact your

sales office or our customer service.

• If the device is brought into the installation site from a cold environment, condensation can

form. Before operating the device, wait until it is absolutely dry and has reached approximately

the same temperature as the installation site.

• During installation and before operating the device, observe the instructions on environmental

conditions in the chapter entitled "Technical data" as well as the instructions in the chapter

"Installing an ergonomic video workstation".

• To ensure adequate ventilation the monitor may only be operated with the monitor foot

installed.

• The color monitor must not be exposed to strong magnetic fields (e. g. caused by magnetic

paper clip holders or loudspeakers). Strong magnetic fields could result in a permanent blotchy

image.

• The monitor is automatically degaussed when switched on. This results in a magnetic field

around the metal edge of the picture tube, which may damage the data on data carriers nearby.

Therefore, never keep magnetic data carriers near the monitor.

• The device automatically sets itself to the correct voltage within the range from 100 V to 120 V

and 200 V to 240 V. Ensure that the local mains voltage lies within these limits.

• The device must be installed in such a way that the user has good access to the appliance

socket.

• The ON/OFF switch does not disconnect the device from the line voltage. To disconnect the

line voltage completely, remove the power plug from the grounded power outlet.

• Lay all cables so that nobody can stand on them or trip over them. When attaching the device,

observe the relevant notes in the chapter "Connecting the monitor".

• No data transmission cable should be connected or disconnected during a thunderstorm.

• Please ensure that no objects (e. g. necklaces, paperclips etc.) or liquids can get into the

interior of the device (this may cause an electrical shock or short circuit).

• In emergencies (e. g. damaged casing, elements or cables, penetration of liquids or foreign

matter), switch off the unit, disconnect the power plug and contact your sales office or our

customer service center.

• Only qualified technicians may repair the device. Unauthorized opening and incorrect repair

may greatly endanger the user (electric shock, fire risk).

• Tampering with the device, in particular adjusting the high voltage or installing a different type

of CRT tube, may result in a large amount of X-ray radiation being emitted. Devices modified in

this way no longer comply with their license and may not be used.

• You may set only those resolutions and refresh rates specified in the "Technical data" chapter.

Otherwise you may damage your monitor. If you are in any doubt, contact your sales office or

customer service center.
