Fujitsu C150-E140-03EN Manuale utente

M3091DC Image Scanner

OPERATION GUIDE

C150-E140-03EN

M3091DC Image Scanner Operation Guide

FOR SAFE OPERATION

Treatment of This Manual

Since this manual contains important information for using the M3091DC, read it

thoroughly before using the product. Use the M3091DC only after thoroughly reading and

understanding especially the section "Important Alert Messages" in this manual. Keep this

manual handy, and store it carefully.

Notice to

AmericanUsers Federal Communications Commission

Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Adjust or relocate the receiving antenna.

•Increase the distance between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from the

circuit the receiver is connected to.

•Consult your dealer or an experienced radio/TV technician for help.

FCC warning: Changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority to operate

the equipment.

M3091DC Image Scanner Operation Guide

Notice to

AmericanUsers Notes

•The use of a non-shielded interface cable with the referenced device is

prohibited. The length of the parallelinterface cable must be 3 meters

(10 feet) or less. The length of the serial interface cable must be 15

meters (50 feet) or less.

•The length of the power cord must be 3 meters (10 feet) or less.

Notice to

Canadian Users This digital apparatus does not exceed the class B limits for radio noise

emissions from digital apparatus set out in the Radio Interference

Regulations of the Canadian Department of Communications.

Le présent appareil numériqué n'émet pas de bruits radioélectnques

dépassant les limites applicables aux appareils numériques de la classe B

prescrites dans le Règlementsur le brouillage radioélectrique édicté par le

ministère des Comunications du Canada.

Notice to

German Users Bescheinigung des Herstellers/Importeurs

Hiermit wird bescheinigt, daß der/dieldas

•M3091DC in Übereinsstimmung mit den Bestimmungen der

•AmtsblVfg 243/1991 funkentstört ist. Der Deutschen Bundespost wurde

das Inverkehrbringen dieses Gerätes angezeigt und die Berechtigung

zur Überprüfung der Serie auf Einhaltung der Bestimmungen

eingeräumt.

•Maschinenlärminformationsverordnung 3. GS GV, 18.01.1991:

Der höchste Schalldruckpegel beträgt 70 dB (A) order weniger

gemäß ISO/7779.

M3091DC Image Scanner Operation Guide

Warning: This equipment may cause electromagnetic interference. It has not been tested

to show compliance with AS3548 Class A equipment, which is designed to provide

reasonable protection against such interference.

Operation of this equipment in a residential area is likely to cause interference in which case

the user at his own expense will be required to take whatever measures may be required to

correct the interference.

As an ENERGYSTAR ®Partner, Fujitsu Limited has determined that

this scanner meets ENERGYSTAR ®guidelines for energy efficiency.

ENERGYSTAR ®is a U. S. registered mark.

Trademark Acknowledgment

Fujitsu is a registered trademark of Fujitsu Limited.

ThirdEdition April 2000

The contents of this manual may be revised without prior notice.

The contents of this manual shall not be disclosed in any way or reproduced in any media

without the express written permission of Fujitsu Limited.

M3091DC Image Scanner Operation Guide i

Preface

Thank you very much for your purchase of the M3091DC Image Scanner.

The M3091DC Image Scanner can read very fine color images.

As this manual explains the basic handling of the scanner, read it carefully

to use the scanner properly.

In this manual, the MicrosoftWindows NTOperating System is

referred to as Windows NT, the MicrosoftWindows 95Operating

System is referred to as Windows 95, and the MicrosoftWindows 98

Operating System is referred to as Windows 98.

Microsoft, Windows, and Windows NT are registered trademarks of

Microsoft Corporation of the U.S. in the United States and other countries.

Other company names or product names appearing in this manual are

trademarks or registered trademarks of individual companies.

ii M3091DC Image Scanner Operation Guide

Important Notes to Users

Every user is requested to use this product including the manuals and

software supplied with the product at the user's own responsibility.

Fujitsu assumes no liability with respect to any damage or loss caused to

data as the result of using this product.

Please understand that the warranty range for failure of this product will

never exceed the amount of money paid by the user for the product.

Fujitsu prohibits any user from using software supplied with this product

or any other update software for this product for any purpose other than

incorporation into this product. Fujitsu also prohibits any user from

reworking or disassembling such software.

M3091DC Image Scanner Operation Guide iii

Conventions for Alert Messages

This manual uses alert messages to prevent users and bystanders from

being injured or from suffering damage to their property. An alert

message consists of an alert signal and alert statements. The alert signals

and their meanings are as follows.

This indicates a hazardous situation that could

result in serious personal injury if the user

does not perform the procedure correctly.

This indicates a hazardous situation that could

result in minor or moderate personal injury if

the user does not perform the procedure

correctly. This alert signal also indicates that

damage to the products or other property may

occur if the user does not perform the

procedure correctly.

In addition to the above-cited signals, the

following symbols are also used to provide

detailed information concerning injury or

damage:

Electric shock

High

temperature

The symbol marked with

indicates a warning or caution.

The concrete meaning of an alert

is illustrated in the symbol. (The

example at left indicates caution

against an electric shockand

caution against an high

temperature.)

iv M3091DC Image Scanner Operation Guide

Disassembly

The symbol marked with

indicates what must not be done

(prohibited action). The concrete

meaning of the action is

illustrated in the symbol. (The

example at left indicates the

prohibition of disassembly.)

Plug

The symbol marked with

indicates what must be observed.

The concrete meaning of the

action is illustrated in the symbol.

(The example at left directs the

operator to disconnect the power

plug from the outlet.)

M3091DC Image Scanner Operation Guide v

Important Alert Items

Important Alert Messages

Important alert messages applicable to the M3091DC Image Scanner are

listed below. Observe these directions for safe operation of the scanner.

Alert concerning power supply

Prohibited

−Do not insert the AC adapter to any outlet other than one dedicated to

15 A at 100 VAC. Do not make a starburst connection.

It could result in a fire or electric shock.

−Do not damage, break, or process the power cord. Do not put a heavy

item on, pull, or forcibly bend it.

It could result in a fire or electric shock.

−Use only the power cord (AC adapter) supplied with the scanner. Do

not use an extension cord.

It could result in abnormal heat or a fire.

−Do not use the power cord or AC adapter if it is damaged or loose in

connection with the outlet.

It could result in a fire or electric shock. Ask your sales agency or

Fujitsu Limited for repair.

vi M3091DC Image Scanner Operation Guide

Electric

shock

−Disconnect the AC adapter from the outlet before connecting an

interface cable or optional product.

Failure to do so could result in an electric shock.

−Do not handle the AC adapter with wet handswhen connecting or

disconnecting it.

It could result in an electric shock.

Direction

−If the AC adapter or outlet is covered with dust, clean it well with a

dry cloth.

Failure to do so could result in a fire.

Plug

−If one of the following occurs, promptly stop using the scanner and

disconnect the AC adapter from the outlet, then call your sales agency

or Fujitsu Limited:

−The scanner generates smoke or the outside of the scanner is

extraordinarily hot.

−The scanner generates an abnormal sound.

−Water enters the inside of the scanner.

Failure to do so could result in a fire.

−In case of thunder, disconnect the AC adapter from the outlet.

Failure to do so could result in damage to the scanner or other

property of the customer.
