FUJITSU Storage
ETERNUS DX
Configuration Guide -Server Connection-
(FCoE) ETERNUS DX100 S3/DX200 S3, ETERNUS DX500 S3/DX600 S3 Disk Storage
System Settings
P3AM-7982-05ENZ0
This page is intentionally left blank.
Preface
This manual briefly explains the operations that need to be performed by the user in order to connect an
ETERNUS DX to a server running Solaris OS, Windows®, Linux, or VMware ESX via an FCoE interface.
This manual should be used in conjunction with any other applicable user manuals, such as those for the
ETERNUS DX, server, OS, Converged Network Adapter cards, and drivers.
Refer to "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Notations" for the notations
used in this manual such as product trademarks and product names.
This manual references the following documents:
•Fabric OS Administrator’s Guide Supporting Fabric OS
•ETERNUS Web GUI User's Guide
This manual is designed for use with the following ETERNUS DX storage systems:
•ETERNUS DX100 S3/DX200 S3 Disk storage system
•ETERNUS DX500 S3/DX600 S3 Disk storage system
5th Edition
December 2014
The Contents and Structure of this Manual
This manual is composed of the following two chapters.
•"Chapter 1 Workflow" (page 6)
This chapter describes the workflow when setting up an ETERNUS DX.
•"Chapter 2 Setting Up the ETERNUS DX" (page 8)
This chapter describes how to set up an ETERNUS DX.
3
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-7982-05ENZ0
Table of Contents
Chapter 1 Workflow 6
Chapter 2 Setting Up the ETERNUS DX 8
2.1 Common Settings ........................................................................................................................... 8
2.1.1 Setting the To-server Connection Type (Setting the FCoE Port Parameters) ..........................................................8
2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)...................................................................8
2.1.3 Setting the Host Responses ..................................................................................................................................9
2.1.4 Setting the CA Port Groups....................................................................................................................................9
2.1.5 Registering the WWNs of the Accessing Converged Network Adapter Cards (Setting FCoE Host) ..........................9
2.1.6 Allocating LUN Groups (Setting the Host Affinity)...............................................................................................10
2.2 Specific Settings ........................................................................................................................... 10
2.2.1 Setting the CA Reset Groups................................................................................................................................10
2.3 Checking the WWNs ..................................................................................................................... 10
4
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-7982-05ENZ0
List of Tables
Table 2.1 FCoE port parameter settings .....................................................................................................................8
Table 2.2 Host response settings ...............................................................................................................................9
5
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-7982-05ENZ0
Chapter 1
Workflow
This manual is used when performing the setup procedures described in the "Setting Up the ETERNUS DX"
section of the "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE)" for each OS.
Required Documents
•Fabric OS Administrator’s Guide Supporting Fabric OS
•ETERNUS Web GUI User's Guide
Workflow
Setting the FCoE Port Parameters
Set the to-server connection type.
•"2.1.1 Setting the To-server Connection Type (Setting the FCoE Port Parameters)" (page 8)
Setting the LUN Groups
Set the server accessible LUN groups.
•"2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)" (page 8)
Setting the Host Responses
Set the host responses to match the connection configuration.
•"2.1.3 Setting the Host Responses" (page 9)
6
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-7982-05ENZ0
Setting the CA Port Groups
Create a group of ports for each CA type.
•"2.1.4 Setting the CA Port Groups" (page 9)
Setting the FCoE Host
Register the WWNs of the accessing Converged Network Adapter cards.
•"2.1.5 Registering the WWNs of the Accessing Converged Network Adapter Cards (Setting FCoE
Host)" (page 9)
Setting the Host Affinity
Define the relationship between the FCoE host, the CA port group, and the LUN group.
•"2.1.6 Allocating LUN Groups (Setting the Host Affinity)" (page 10)
Checking the WWNs
Check information that is necessary for connecting to the server.
•"2.3 Checking the WWNs" (page 10)
After completing all the required procedures in this manual, follow the procedures in "FUJITSU Storage
ETERNUS DX Configuration Guide -Server Connection- (FCoE)" for each OS.
Chapter 1 Workflow
7
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-7982-05ENZ0
Chapter 2
Setting Up the ETERNUS DX
2.1 Common Settings
This section explains the settings required for all server OSes, regardless of the connection configuration.
See the "ETERNUS Web GUI User's Guide" for details of how to set up and operate ETERNUS Web GUI.
2.1.1 Setting the To-server Connection Type (Setting the FCoE Port Parameters)
For each connection configuration, set the indicated items only. All other parameters should be left on their
default values.
Table 2.1 FCoE port parameter settings
Parameter Solaris OS, Windows®, Linux, VMware ESX
Transfer Rate 10 Gbit/s
Frame Size 2048 bytes (Default value)
Reset Scope I_T_L
Release Reservation if Chip is Reset Disable
Make sure to prepare and set up FCoE switches. For further details, refer to "Fabric OS Administrator’s
Guide Supporting Fabric OS".
2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)
Create LUN groups (Affinity Group) for the server to access. Refer to "Connectivity Management" in "ETERNUS
Web GUI User's Guide" for details, and set the LUN groups.
When the server OS is Windows®, Linux, or VMware ESX, assign LUN Group values starting from LUN0 in
ascending order. The server cannot recognize the ETERNUS DX LUNs unless they are assigned in this order.
This restriction does not apply when the server is running a Solaris OS.
8
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-7982-05ENZ0
2.1.3 Setting the Host Responses
The host response parameters for the ETERNUS DX must be set to match the way the server processes the
responses to requests from the ETERNUS DX. Setting of the host response must be done before connecting
the ETERNUS DX to the server.
Set the parameters that are described below for each OS.
Retain the default values for all of the parameters that are not described below.
Table 2.2 Host response settings
OS Conditions Host response selection
Solaris When using the OS standard Multipath Driver
(MPxIO)
Solaris MPxIO
Other cases Default
Windows®
Linux
VMware ESX
– Default
2.1.4 Setting the CA Port Groups
Create new FCoE port groups and register the ports as members of the groups. A port group is a group of
ports that access the same LUN group (ports that are used for multipath connection to the server or for con-
necting to the cluster configuring server). Configure the host affinity setting for each FCoE port group.
2.1.5 Registering the WWNs of the Accessing Converged Network Adapter Cards
(Setting FCoE Host)
Register the WWN of each Converged Network Adapter card installed in the server that will access the ETER-
NUS DX. At the same time, set the host response registered in "2.1.3 Setting the Host Responses" (page 9) to
accept these FCoE hosts (WWNs).
Registering the FCoE host WWNs and setting up Host Affinities as described elsewhere, allows limits to be set
on which servers are allowed to access which ETERNUS DX LUNs.
When a server-side Converged Network Adapter card is replaced, the WWN of the replacement Converged
Network Adapter card must be re-registered to the ETERNUS DX.
Chapter 2 Setting Up the ETERNUS DX
2.1 Common Settings
9
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-7982-05ENZ0
2.1.6 Allocating LUN Groups (Setting the Host Affinity)
Allocate the relationship between registered FCoE hosts (WWN), CA port groups, and LUN groups using the
Host Affinity setting function to specify which LUNs to be accessed. This sets access restrictions to the ETER-
NUS DX from each server.
Refer to "Connectivity Management" in "ETERNUS Web GUI User's Guide" for details, and set the LUN groups.
If the one-to-one relationship between the WWNs and Converged Network Adapter cards cannot be deter-
mined, the Host Affinity may not be set correctly.
In this case, trying various settings may be necessary until the server is able to recognize the ETERNUS DX
logical disks.
2.2 Specific Settings
Specific settings for the OS and connection configuration are not required.
2.2.1 Setting the CA Reset Groups
Because all of the ports are configured to be members of one CA reset group in the initial setting, the reset
group settings do not need to be changed.
2.3 Checking the WWNs
Use ETERNUS Web GUI to check the WWN of each ETERNUS DX. They are required for connecting the ETERNUS
DX to the server.
Chapter 2 Setting Up the ETERNUS DX
2.2 Specific Settings
10
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-7982-05ENZ0
