Fun & Function SP8607 Manuale utente
Color Changing Light Panel with
SensaSoft™ Panel and Platform
SP8607, SP8608
Installation Manual 82710
August 2022
3
3
4
5-8
8
9
10
Contents
Warnings
Description
Includes
Installation
Cleaning, Maintenance, Technical
Guarantee
Contact
2
*This product is designed for users with special needs.
Adult supervision is required during use at all times.
*For indoor use only. The equipment uses a mains power supply.
*Do Not use the wall panel free standing. It should be installed securely to the wall.
*Never use abrasive cleaning pads to clean this item.
*The SensaSoft platform is designed to support no more than 275 lbs. It is designed for one
person at a time.
3
Description
Multi-colored and multi-sensory fun! With four different colors and sixteen different modes,
the Color Changing Light Panel creates an engaging sensory experience for kids of all ages.
Illuminate your sensory space with a variety of vibrant lights and settings. Choose the sound
responsive mode to enable kids to control the colors using their voice or by making any sound.
The remote control is another fun way to play with the wall panel. It encourages eye-tracking
and color recognition, and is fantastic for non-verbal users too.
Your SensaSoft wall panel and platform are part of a wide range of floor cushions and
interlocking products that provide multiple configurations (additional pieces can be
purchased at a later date). The wall panel attaches to the wall using the supplied brackets.
The platform sits on the floor and attaches to the wall panel with Velcro tabs. This keeps the
platform from slipping away from the wall panel.
Warnings
Sensasoft Wall Panel
Sensasoft Platform
Includes
Wall Panel
Platform
2 x Wall Brackets - 1000 mm
Power Cord
4
The wall panel and platform will be packaged separately.
Wall Bracket up
position
Holes
Top Bracket Hole hardware
33.5 inches above floor level
Bottom Bracket Hole hardware
14 inches above floor level
Baseboard
Mark Holes
5
Installation
The wall panel must be installed against a permanent wall of solid construction. An
electrical outlet is required to make your panel work. The panel should be located near
an electrical outlet. Brackets are supplied without screws or bolts. Proper screws or bolts
will depend on the type of wall the panel will be attached to. It is recommended
the wall panel is installed by a professional using the correct hardware to secure the
panel to the wall.
Note: The brackets do not support the weight. The wall brackets stop the panel from tipping.
The illustrations provided are showing a typical method using screws and hardware for a
solid brick wall.
Step 1
Using a level, place the wall bracket to the wall making sure the brackets are level. Use a
pencil to mark through the holes in the bracket to the wall. The top bracket hole centers
should be exactly 33.5 inches (85cm) above the floor and bottom bracket 14 inches
(35.6cm). We suggest a minimum of 3 holes in each bracket.
Step 2
Drill Holes and use at least 3 screws or bolts to attach the brackets to the wall
We recommend two people to lift the panel onto the wall brackets.
3 x Rear
brackets
Wall panel Wall Panel (Back)
Lift onto the
wall brackets
Step 4
6
•The platform arrives with the
legs unattached.
•Remove the screws placed in
the platform. Set them aside,
you will need them.
•Place the legs in the positions
shown.
•Using the same screws, secure
the legs.
Step 3
Identify the three brackets on the rear of the wall pad and lift on to the wall brackets. The panel
should stand on the floor if fitted correctly. The brackets stop the panel from tipping.
Platform
Velcro
Strips
Wall panel
Step 5
Push the platform to the wall panel and attach the two Velcro strips to the side
of the wall panel.
Connecting to the Main
Power Supply
Connect power cord
7
Your wall panel is fitted with a
Sensory panel. This requires
an electrical outlet. You are
supplied with a power cord.
This plugs into the socket to
the right side of your wall
panel. Connect the supplied
cord and plug into an
electrical outlet. You are now
ready to use your SensaSoft
product.
Auxiliary Cord Connect more panels with
the auxiliary cord
Cleaning
•We suggest a quick wipe every day after use . A more rigorous cleaning can be completed once a week.
•Before you start to clean unplug the equipment from the electrical outlet.
•To clean your Color Changing Light Up Panel, use a soft, lint free white cloth and mild detergent such
as dish washing liquid.
•Never use an abrasive cloth or any solvent liquid such as mineral spirits or bleach.
The light panel can become damaged if appropriate cleaners or cloths are not used.
•If the material is ripped, stop using immediately.
8
Connecting other SensaSoft Products
Every SensaSoft panel has an auxiliary cord to connect power to other SensaSoft
panels. The entire range can run from one power outlet. To connect more panels, use
the cord to the left of the wall panel. If this cord is not being used, tuck it behind
the panel so it cannot be tampered with.
Maintenance
Your Color Changing Light Panel requires no maintenance other than a visual inspection for a damaged
front panel. Check all wall hardware and ensure the panel is still secure. Make sure electrical cords are
not damaged.
Technical
The Color Changing Light Panel is a low voltage device using a power supply that is double insulated. A
class 2 device does not require portable appliance testing. We do however suggest an annual visual
inspection looking for any damaged parts.
Guarantee
CONDITIONS OF GUARANTEE
This guarantee is in addition to and does not in any way affect any statutory or other rights of consumer
purchasers. If within the applicable guarantee period (as shown in 8 below) the appliance proves to be
defective by reason of faulty design, workmanship or materials, we undertake subject to the following
conditions to have the defective appliance (or any part or parts thereof) repaired, or at our discretion, replaced
free of charge.
1. The appliance shall have been purchased and used solely in accordance with standard operating
instructions and the technical and/or Safety Standards required in the country where this appliance is to be
used
2. All inquiries must be through such dealers. For appliances used in the UK., U.S.A., Channel Islands,
Isle
of Man, and Republic of Ireland t
he appliance should be returned together with this guarantee and proof of
purchase promptly on being found defective, at the purchasers risk and expense, to the authorized dealer from
whom the appliance was purchased.
3. This guarantee shall not apply to damage caused through fire, accident, misuse, wear and tear, neglect,
incorrect adjustment or repair, to damage caused through where this appliance is used, or to damage occurring
during installation, adaptation, modifications, or use in an improper manner or inconsistent with the technical
and/or safety standards required in the country transit to or from the purchaser.
4. If at any time during the guarantee period any part or parts of the appliance are replaced with a part or
parts not supplied or approved by us or of an objective quality safe and suitable for the appliance, or the
appliance has been dismantled or repaired by a person not authorized by us, the purchaser shall not be
entitled to any rights and/or remedies under this guarantee.
5. The purchaser sole and exclusive remedy under this guarantee against us is for the repair (or at our
discretion the replacement) of the appliance or any part or parts and no other remedy, including, but not
limited to, incidental or consequential damage or loss of whatsoever nature shall be available to the purchaser.
6. This guarantee shall not apply to lamps, batteries, color filters, cabinet parts or any other parts of a
limited natural life.
7. Our decision on all matters relating to complaints shall be final. Any appliance or defective part which
has been replaced shall become our property until paid for in full.
8. The guarantee period applicable to all new appliances shall be 24 months.
9
SpaceKraft copyright July 2022
Wall Panel (SP7270) - 49.5"H x 48"W x 3.5"D
(1257mm x 1219mm x 89mm)
Weighs 46 lbs. (21 KG)
Floor Platform (SP7168) - 48"L x 47.25"W x 11.4"H
(1219mm x 1200mm x 289.5mm)
Weight 33lbs. ( 15 KG)
Disclaimer
No part of this manual may be reproduced in any form or by any means
(graphic, electronic or mechanical, including recording, taping,
photography or information retrieval system) without express written
permission of the publisher of this material.
All information correct at date of publication.
PO Box 11, Merion Station, PA 19066
QUESTIONS? call us at 800-231-6329 or email us at [email protected].
We are committed to going above and beyond to address your questions, ideas and feedback.
10
