Gama Sonic GS-114F Manuale utente





PRAIRIESOLARLAMP

w/changeablemounting

options

USPatent#7172307

InstructionManual

Model:GS‐114FPW

GS‐114F GS‐114PGS‐114W

Introduction

Thankyouforyourpurchase.GAMASONIC®solarchargedaccentlightingeliminatestheproblems

associatedwithmostsolarlightingavailabletoday.GAMASONIC®solarchargedlightsarebrighterand

lastallnightwithatypicalsolarcharge.Uniquedesign,superiorlightoutputandnumerousinstallation

optionsconfirmtheoutstandingvalueofourproduct.

GAMASONIC®hasbeenrecognizedasaworldwideleaderinthelightingindustryforover20years.The

companyalsooffersuniquemulti‐purposerechargeableproductsthatrangefrompartylightsto

emergencylightingproducts.

FortechnicalassistanceandmoreinformationcallourTollFreenumber:

800‐835‐4113(onlywithintheUS)orvisitourwebsiteat:www.gamasonic.com.

Pleasereadtheinstructionmanualcarefullytoobtainthebestresultsfromyourpurchase.

Toolsthatareneededbutnotsuppliedwiththesolarpostlampsare:ascrewdriver,powerdrill.

SolarLampLocation:

Foroptimumlightdurationthroughoutthenight,itisveryimportanttoplaceyoursolarlampinaspot

whereitwillreceivethemaximumamountofdirectsunlightthroughouttheday.

NOTE:

Forbestresults,thesolarlamppostmustbechargedfortwosunnydaysintheOFF(O)position.



OperationInstructions

1. Removepart(B)frompart(A)byunscrewingthe2screwcapsasshowninFig.1.Turnthe

operationswitch(Fig.2)toON(|)position,theSolarLampwillautomaticallyoperatedusk

todawn.

2. Reattachpart(B)topart(A)andsecurewiththe2screwcaps.





Fig.1

B

AB

Fig.2

InstallationInstructions



GS-114P (Fig. 3)

1. Useadrilltomaketwoholesinthedesiredsurface,

2. Placethewhitescrewanchorsintothedrillholes,placethelampinlinewiththe

holesandscrewdownwiththeprovidedscrews.

Note:Therearespecifictypesofscrewsforspecificsurfaces.Ifunsureofthe

appropriatetypeofscrewtouseonyourdesiredsurfacepleaseconsulta

professional.

GS-114W (Fig. 4)

NOTE:Forbestresultslocateyoursolarlampfacingthesouth.

1. Use electric drill to make two holes in the wall, place provided anchors into holes, place

the wall bracket in line with the holes and screw the provided screws.

2. Assemblypart(A)intothewallbracketbyturningitusingthescrewprovided.



GS-114F (Fig. 5)

NOTE:Ifyouarereplacinganexistinggas/electricpostlight,youmustconsulta

certifiedtechniciantocancelthembeforeinstallation.

1. PositionPart(C)ontopoftheexisting3”postandtightenitusingthescrews

provided.

2. Screwinpart(A)intopart(C)usingthescrewprovided.

ReplacingtheBatteries(Fig.6)

(Afterseveralyearsofuse,thebatterymayneedreplacing).

1. Unscrewthetwoscrewcapsanddetachpart(C)frompart(B).MakesuretheON/OFF

switchisintheOFF(O)position.

2. Unscrewthebatterycompartmentscrews.

Fig.3

Fig.4

Fig.5

3. Uncliptheconnectorandremovetheoldbattery.Makesurethenewbatteryishigh

quality3.6V/800mAhNi‐Cd Rechargeablebatterywithconnector.

4. Cliponnewbatteryandinstallintothebatterycompartment.Screwbackbattery

compartmentscrew.

5. Reattachpart(C)topart(B)andsecurewiththe2screwcaps.



WARNING:DonotdisposeofNi‐Cdbatteryintheregulartrash,municipalwastestreamorbyfireas

batteriesmayleakorexplode.Donotopen,shortcircuit,ormutilatebatteriesasinjurymayoccur.

PreserveourenvironmentbyrecyclingNi‐Cdbatteriesordisposingoftheminaccordancewithlocal,

Stateandfederalregulations.Donotmixoldandnewbatteries.



Maintenance

Cleanthesolarpanelsregularlywithadamptoweltoguaranteeoptimumperformance.Donotuseany

typeofsolventforcleaningandbecarefulnottoputtoomuchpressureonthesolarpanelswhile

cleaning.



TroubleShooting

Ifyoursolarchargedlightdoesnotcomeonatduskdespiteobservanceofalltheinstructions,pleasetry

thefollowingsteps:



1. Makesurethatthesolarlampisnotbeingaffectedbyanyotherlightsource.

2. Ensurethesolarlampisnotpositionedintheshadeduringtheday.

3. MakesuretheswitchinthelampheadistheOn()position.

4. Checkthatthebatteriesareinstalledcorrectly.



B

Fig.6

NOTE:Theperformanceofthesolarlampwillvarywiththetimeofyear.Itwilldelivermorelightwhen

ithashadafulldayinthesunratherthanadayinovercastweather.



WINTERTIMETIPS:Foroptimalperformance,besuretoremoveanysnowordebrisaccumulationfrom

solarpanel(s).Asolarpanelfreeofdebriswillchargethebatteriesmuchmoreefficiently.



WARNING:Pleasekeepoutofreachofchildren.


