Gama Sonic GS-99F Manuale utente

Introduction

Thank you for your purchase.

GAMA SONIC

® solar charged accent lighting eliminates

the problems associated with most solar lighting available today.

GAMA SONIC

® solar

charged lights are brighter and last all night with a typical solar charge. Unique

design, superior light output and numerous installation options confirm the

outstanding value of our product.

GAMA SONIC

® has been recognized as a worldwide leader in the lighting industry for

over 2 years. The company also offers unique multi-purpose rechargeable products

that range from party lights to emergency lighting products.

WINDSOR SOLAR LAMP

US Patent # 71723 7

Instruction Manual

Models: GS-99F

Please read the instruction manual carefully to obtain the best results from your

purchase.

Solar Lamp Location

For optimum light duration throughout the night, it is very important to mount your

solar lamp post in a spot where it will receive the maximum amount of direct sunlight

throughout the day.

NOTE: The following steps are for reference only. Consult your local hardware store

for the best installation method for your particular surface.

NOTE: The solar light must be charged in full sun for two days for best results.

Operatio I structio s

Turn the operation switch to High for maximum

brightness or Low for longer duration (Usually used in

winter time or in places where there is less sun

exposure) (Fig. 1). Solar Lamp will automatically

operate dusk to dawn.

I stallatio I structio s

1. Screw the Finial onto of the lamp top (Fig. 2)

2. Install the lamp onto your existing 3” post, and

tighten to the post using the 3 screws provided

(Fig. 3).

Fig. 1

Fig. 2

Fig. 3

Finial

Replaci g the Batteries

(After several years of use, the batteries may need replacing).

1. Make sure the ON/OFF switch is in the “OFF” position ( ).

2. Unscrew the two screws on the upper part to detach it from the lamp

(Fig. 4).

3. Unscrew the battery compartment’s screws located on the silver

reflector and remove the compartment doors (Fig. 5).

4. Unclip the battery connector and remove the old battery. Make sure the

new batteries are high quality – 2 x Li-Ion Battery packs (3.2 Volt / 11

mAh) with connector.

5. Install the new batteries into the battery compartment.

6. Reassemble the unit by reversing the above procedure.

WARNING: Do not dispose of Li-Ion battery in the regular trash, municipal waste

stream or by fire as batteries may leak or explode. Do not open, short circuit, or

mutilate batteries as injury may occur. Preserve our environment by recycling Li-Ion

batteries or disposing of them in accordance with local, State and federal regulations.

Do not mix old and new batteries.

Mai te a ce

Clean the solar panels regularly with a damp towel to guarantee optimum

performance. Do not use any type of solvent for cleaning and be careful not to put too

much pressure on the solar panels while cleaning.

Trouble Shooti g

If your solar charged light does not come on at dusk despite observance of all the

instructions, please try the following steps:

1. Make sure that the solar lamp post is not being affected by any other

light source.

2. Ensure the solar lamp post is not positioned in the shade during the

day.

Fig. 4

Fig. 5

3. Make sure the switch on the lamp head is in either the Low or High

position.

4. Check that the batteries are installed correctly.

NOTE: The performance of the solar lamp post will vary with the time of year. It will

deliver more light when it has had a full day in the sun rather than a day in overcast

weather.

WINTERTIME TIPS: For optimal performance, be sure to remove any snow or

debris accumulation from solar panel(s). A solar panel free of debris will charge the

batteries much more efficiently.

WARNING: Please keep out of reach of children.
