Ganz VRDDN-2812IRY60 Manuale utente

www.cbceurope.com

6-8 Garrick Industrial Centre, Irving Way, London NW9 6AQ, England

tel: technical support +44 (0)20 8732 3350 +44 (0)20 8732 3332

fax: +44 (0)20 8202 3387 www.cbceurope.com

600 TVL Vandal Resistant Dome

VRDDN-2812IRY60 (LLTNB-IR212PA)

Key features

High Resolution - 600TVL

2.8-12mm varifocal auto iris lens

True day / night with IR cut ﬁlter

Vandal resistant

Quick and easy to install

IP66 Rated

Dual power 12vdc/24vac

The VRDDN-2812IRY60 (LLTNB-IR212PA) camera features the latest CCD image sensor technology,

delivering superb image quality with 600 TVL resolution.

True day / night capability ensures clean and crisp colour images during daylight, when light levels fall

low enough the camera changes over to mono and the integrated IR array is switched on. This then

provides the camera scene IR lighting up to a distance of 20 metres with sharp mono images.

An intuitive joystick driven OSD menu system makes the setup of the camera features simple.

The vandal resistant housing design makes the unit ideal for installations where there is risk of tamper

or attack at the camera location.

For visual deterrent purposes an external high brightness led can be made to activate whenever the

camera senses movement within the viewed scene.

A 1 metre cable allows the camera terminations to be made inside the building, negating the need for

an external junction box.

www.cbceurope.com

6-8 Garrick Industrial Centre, Irving Way, London NW9 6AQ, England

tel: technical support +44 (0)20 8732 3350 +44 (0)20 8732 3332

fax: +44 (0)20 8202 3387 www.cbceurope.com

Applications

Poorly lit areas

Colleges

Car Parks

Public Areas

External vandal / tamper risk

applications

Ofﬁce Complexes

Schools

Petrol stations

VRDDN-2812IRY60 (LLTNB-IR212PA) 600TVL Vandal Resistant Dome

Speciﬁcations

Description / Model VRDDN-2812IRY60 (LLTNB-IR212PA)

Sensor 1/3” CCD

Video Format PAL/NTSC

Resolution 600 TVL

Min Illumination 0 lux (IR array on)

S/N Ratio 50dB max (AGC off)

AGC On/off

Lens 2.8-12mm Varifocal auto iris

Iris Control Auto iris

Shutter 1/50th - 1/100000th second

White Balance ATW, range 3200 – 10000ºK

Day/Night True Day/Night (IR cut ﬁlter)

Privacy 8 Programmable zones

Sync Mode Internal

IR Array Integrated long life

IR Distance 20 metres

Voltage 12vdc/24vac

Current <350mA (IR on)

Video output CVBS 1v p-p/75 

Lens 2.8-12mm auto iris

IP Rating IP66

Operating Temp -10° ~ 50°C

Storage Temp -20° ~ 60°C

Dimension 147(W) x 112 (H)

Weight (approx) 850g

NB. Speciﬁcation subject to change without notiﬁcation

Accessories

VSVDOM-WB Wall bracket

VSVDOM-CORNADAP Corner adapter for wall bracket
