Apollo GX50 Quick Reference Guide

Press the indicated key and then

turn the LARGE knob to view the

pages shown. Turn the SMALL

knob for more info when available

(diamond shown).

Ident, Type,

& City/Facility Name

Bearing & Dist

Map

Runways

Approaches*

Lat/Lon

Sunrise/Sunset

WPT Comment

*when enabled

Frequencies

Type & Elevation

Fuel

Press INFO

Waypoint Information

(INFO)

Turn SMALL Knob

Press SEL to edit information or to select options.

Press ENTER to enter and save information. In the

Comm function, ENTER saves the Standby frequency.

Press DIRECT-TO to define a direct course from

your present position to a selected waypoint.

ENTER

SEL

Direct-To

1. Press DIRECT-TO. (Check the Direct-To options in System-Nav Info)

2. Turn the SMALL knob to select waypoint type. Then turn LARGE knob to

the waypoint ident or name.

3. Use LARGE & SMALL knobs to select ident or name.

4. Press ENTER. Now, fly direct to the selected waypoint.

waypoint

Press MAP

Moving Map (MAP)

Map plus Nav

Map Only

Map Setup

SAR Map*

Route Line, Map Orient,

& Map Reference

Symbol & ID Setup

Track History (On, Save, Int)

Track History (Strat, Clear, Used)

Airspace Setup

Airspace Buffers

ATC Ring

Airspace Types (B, C, MOA,

Training, Unknown, Alert,

Caution, Danger, Restricted,

Prohibited, & Warning)

SAR Setup*

SAR Position* * when enabled

Turn LARGE Knob

Turn SMALL Knob

Press NAV

Navigation (NAV)

Turn LARGE Knob

ETE, CDI, BRG, &

RGE

RAIM*

Altitude Assist

Parallel Track (PTK)

GPS Position

Countdown Timer

Arc Assist

From/To/Next (Dist)

From/To/Next (ETE)

From/To/Next (ETA)

From/To/Next (Wpt)

Tuned Station*

* when configured

Airport (ARPT)

VOR

NDB

INT

LocDME

User WPT

Search Around WPT

Runway Limits

SUA

Press NRST

Nearest Waypoint (NRST)

Turn LARGE Knob

Press MSG

New

Old

Turn LARGE Knob

Turn SMALL Knob

New Msg 1

New Msg n

Turn SMALL Knob

Old Msg 1

Old Msg n

Messages (MSG)

Active FPL

FPL #1

FPL #30

Create New FPL

Turn LARGE Knob

Press FPL

Flight Plan (FPL)

System (SYS)

Misc Sensors

Encoding Altimeter

Air Data Info

Fuel Info

Turn LARGE Knob

Healthy & Visible Satellites

Satellites Used for Fix

Satellite Search Status

GPS Date & Time

GPS Normal Reset

Turn LARGE Knob

Date/Time

Test Display

Display Brightness

Owner Name

Model, SW Ver, S/N

Fuel Units

Baro Units

Turn LARGE Knob

Press SYS. Turn LARGE Knob, then press ENTER.

System Info GPS Sensor

Autonav Time

Lat/Lon Units

Program Nav Pages

Mag Var

Flight Timer Trigger

Direct-To

CDI Scaling

Turn LARGE Knob

Nav Info

Database (DB)

Press DB

Create WPT by Lat/Lon

Create WPT by Radial/Dist

Update User Wpt w/PPos

Create Wpt by Grid (SAR Only)

Delete User WPT

Modify User WPT

Delete WPT Comment

Access Database

Turn LARGE Knob

1. Press FPL. Turn LARGE knob

to the “Create New Flight Plan”

page and then press ENTER.

2. To enter a new plan name, press

SEL.

3. Turn the SMALL knob to select

characters. Turn the LARGE knob

to move to the next character.

4. Press ENTER when the name is

complete.

5. Turn the SMALL knob to start

inserting waypoints into the flight

plan. At the INS? prompt, press

ENTER.

6. Turn the SMALL knob to select

the first character. Turn the

LARGE knob cw to move to the

next character.

7. Use the SMALL and LARGE

knobs to select the waypoint

name and then press ENTER.

8. The INS? prompt will flash for

the next waypoint. Press ENTER

and repeat steps 5-7 until

finished.

9. Press SEL to stop editing

your flight plan.

Creating a Flight Plan

1. Press DB.

2. Turn the LARGE knob to the

Access Database page and

press ENTER.

3. Turn the SMALL knob to select

waypoint type.

4. Turn the LARGE knob to the

desired character and turn the

SMALL knob to select characters.

5. Press INFO.

6. Turn the SMALL knob to view

information.

7. Press INFO again or ENTER

to exit.

Finding Info On A Waypoint

1. Press DB.

2. Turn LARGE knob to the

Create User Wpt By Lat/Lon

page and then press ENTER.

3. Use the SMALL to select

characters and turn the LARGE

knob to move the cursor to set

the waypoint name.

4. Continue to select the

necessary characters for the

Lat/Lon and runway length.

5. Press ENTER when finished.

Creating A New Waypoint

1. Press FPL.

2. Turn the LARGE knob to the

desired active flight plan and

press SEL.

3. Turn the SMALL knob to

select the desired option and

press ENTER.

Activating a Flight Plan

2345 Turner Rd., S.E.

Salem, OR 97302

USA 800-525-6726

Canada 800-654-3415

International (503) 391-3411

FAX (503) 364-2138

http://www.upsat.com

P/N 561-0238-02

July 2001

2001 by UPS Aviation Technologies, Inc.

Printed in the U.S.A.

1. Press NRST.

2. Turn the LARGE knob to change

Wpt type.

3. Turn the SMALL knob to view

nearby waypoints.

4. Press DIRECT-TO and then

ENTER to fly direct to the wpt.

Emergency Search

1. Press FPL twice to reach the home page

Flight Plan Mode and press SEL, or

press SEL while in the Nav function.

2. Press ENTER to prepare to load

approach waypoints.

3. Turn the SMALL knob to display the

available approach choices.

4. Press ENTER to select the displayed

approach path.

5. Turn the SMALL knob to display the

approach legs.

6. Press NAV to return to Navigation Mode.

Approach Setup Summary

B. Load Approach Information

Load a destination airport. Load a stored

Flight Plan, or edit the active Flight Plan.

You may also use the DIRECT-TO button

to choose a destination. The destination

must be an airport that has an established

approach capability.

A. Load Destination Airport Enroute

Within 30 nm of

Destination

IAF Active Waypoint

FAF Active Waypoint

At FAF (MAP Becomes Active)

At MAP (TO/FROM Transition)

MAHP Active Waypoint

Load Approach

Enable Approach & enter altimeter setting

(Approach annunciator turns ON)

(CDI goes to 1 nm full-scale sensitivity)

Verify Approach annunciator is ON

Verify/Set OBS/HLD: ON for Procedure Turn or Hold

OFF to sequence

Verify green Approach-Active annunciator is ON

Verify altimeter setting is entered

Verify/Set OBS/HLD: OFF to sequence to MAP

Verify Approach-Active annunciator is ON

(CDI goes to 0.3 nm full-scale sensitivity)

If NOT landing: Press OBS/HLD to cancel

Approach-Active

(Green Approach-Active annunciator turns OFF)

(Approach Annunciator remains ON)

(CDI goes to 1.0 nm full-scale sensitivity)

Verify OBS/HLD is ON

Location Action

Approach Checklist

DME-Arc Checklist

At Arc

Intercept

On Arc

Inbound Leg

Intercept

1. Verify/Set OBS/HLD ON

2. USE DME-Arc Page in NAV mode

3. Verify or select DME-Arc Reference Waypoint and follow the

prompts

4. Use Nav or Map mode and follow information

1. Use DME-Arc page in NAV mode or Map mode to navigate

2. Follow prompts for inbound leg intercept

1. Follow prompts to turn to next leg

Location Action
