Specifications for the

Gateway 600YG2 Notebook

Specifications are subject to change without notice or obligation.

Processor and Core Logic

Processor options One Intel®Pentium 4™-M CPU

To determine your notebook’s processor:

■In Windows XP, click Start, My Computer, then click

View System Information. The processor is listed.

-OR-

■In Windows 2000, click Start, Programs,

Accessories, System Tools, then click System

Information. The processor is listed.

Processor packaging Intel socketable micro-FCPGA2

Level 2 cache 512 KB

Core logic ■Intel 845MP chipset

■PCI Bus

■ICH-3

Processor side bus 400 MHz front side bus

BIOS ■Phoenix BIOS

■512 KB Flash ROM

■SMBIOS 2.3 support

■Advanced Configuration and Power Interface 1.0b

(ACPI 1.0b) support

■Advanced Power Management 1.2 (APM 1.2)

■Wired for Management 2.0 (WfM 2.0)

2www.gateway.com

System memory

Memory type 266 MHz DDR-SDRAM system memory

Memory expansion options ■Two 200-pin industrial standard DDR-SODIMM

sockets

■Accepts two PC-2100 SDRAM memory modules

■1024 MB maximum system memory

■No on-board memory

To determine your notebook’s memory:

■In Windows XP, click Start, My Computer, then click

View System Information. The memory is listed.

-OR-

■In Windows 2000, click Start, Programs,

Accessories, System Tools, then click System

Information. The memory is listed.

Video

Graphics controller ■ATI Mobility Radeon 9500

■256-bit 3D and 2D graphics accelerator

Video memory 64 MB DDR-SDRAM

LCD display panel 15.0-inch or 15.7-inch active matrix (TFT) LCD color

display

Maximum panel resolution:

15.0-inch: 1024 ×768

15.7-inch: 1280 ×1024

Maximum color depth: 32-bit (16.7 million colors)

LCD supported video modes 15.0-inch: XGA

15.7-inch: SXGA

LCD maximum refresh rate 60 Hz

Controls ■Brightness level selectable through FNkey (up, down)

■Icon to display 8 levels of brightness

■Auto dim on battery

■Auto bright on AC power

External video ■Supports dual display and dual view

■Integrated TV encoder

External CRT resolutions Supports standard IBM VGA compatible modes

Maximum resolution: 2048 ×1536 ×32-bit colors

Specifications for the Gateway 600YG2 Notebook

www.gateway.com

External CRT maximum refresh rate 75 Hz

TV out (composite video) jack Supports NTSC/PAL connection to standard TV monitors

with RCA jack

TV out (S-Video) jack Supports NTSC/PAL connection to standard TV monitors

with S-Video jack on port replicator

IEEE 1394 ■One 4-pin connector

■100/200/400mbps

■Supports video and audio capture

■Software included for motion and still-frame capture

Audio

Audio chipset ESS ES1988

Sound support ■PCI interface audio

■Multi-stream Direct Sound and Direct Sound 3D

acceleration

■SoundBlaster Pro, MIDI, Windows Sound System

compatible, MP3, WMA

■APM1.2, ACPI1.0, and PPMI1.1 compliant

■S/PDIF output for PCM or AC-3 content via Toslink jack

on notebook and port replicator

■PCI Power Management Interface (PPMI) 1.1

compliant

Digital DVD audio Provides full 5.1 channel Dolby Digital output (AC-3)

from DVD decoder through Toslink optical S/PDIF jack

on notebook and port replicator.

Volume controls ■Volume control buttons for Audio DJ on front of system

■Volume control keys on keyboard

■Software control provided through Windows

Internal microphone Omni-directional, low impedance

Internal speakers ■Stereo speakers built into palm rest.

■1.0 W maximum output

Audio jacks ■S/PDIF digital audio output

■Stereo headphone output

■Stereo line input

■Monophonic microphone input

4www.gateway.com

Audio DJ ■O2 Oz263, Digital Audio & Audio Player

■Supports AC97 V2.2

■Supports playback function buttons (Play/Pause,

Forward/Scan Forward, Rewind/Scan Rewind, Stop)

■Independent power button

■Volume up/down

Communications

Modem features ■Integrated V.90/56K data/fax modem

■Uses the RJ-11 jack on the back of the notebook

■Supports Wake on Ring from S3 power mode

10/100 Mbps Ethernet interface

features

■Integrated IEEE 802.3 (10/100 BASE-TX) Ethernet

interface

■Uses the RJ-45 jack on the back of the notebook

■Supports Wake on LAN from S3 power mode

Wireless Ethernet interface features

(Factory installed option)

■Agere ORiNOCO IEEE 802.11b network card installed

in Mini PCI expansion slot

-OR-

■Broadcom BCM94306 IEEE802.11g network card

installed in Mini PCI expansion slot

-OR-

■Broadcom BCM94300 IEEE802.11a/g network card

installed in Mini PCI expansion slot

Antenna: Uses factory-installed internal antenna

assembly

Operating channels: 11 selectable channels

Security: 128 and 64 bit WEP encryption

Operating Frequency

■2.4 GHz Direct Sequence Spread Spectrum

(IEEE 802.11b and IEEE 802.11g)

■5.0 GHz (IEEE 802.11a)

Maximum Data Rate

■54 Mbps (IEEE802.11g and IEEE 802.11a)

■11 Mbps (IEEE802.11b)

Specifications for the Gateway 600YG2 Notebook

www.gateway.com

Input/Output (I/O)

Keyboard ■U.S. English keyboard

■Full-sized 86-keys

■19 mm × 19 mm key pitch

■3.0 mm keystroke

Pointing device ■Gateway EZ-Pad™touchpad

■4-button design

Multifunction buttons Four “hot keys” that launch e-mail, Web browser, help

application, and My Computer

Status indicators ■Bay swap status

■Hard drive access

■Left bay access

■Right bay access

■Caps lock

■Scroll lock

■PAD lock

■Audio DJ power

■Battery status

■Power/Suspend

Input/Output (I/O) ports ■Two USB (4-pin)

■High-speed serial

■Parallel (bi-directional, EPP, ECP)

■IEEE 1394 (4-pin)

■V.90, 56K Modem (RJ-11)

■10/100 Ethernet (RJ-45)

■External monitor (VGA)

■TV out (NTSC/PAL composite video)

■S/PDIF digital audio out

■Stereo headphone output

■Stereo line input

■Monophonic microphone input

■PS/2 keyboard or mouse

■PC Card sockets (two Type II or one Type III)

■Docking port

■DC input

PCMCIA ■Accepts two Type II or one Type III device

■TI PCI1520 controller

■Supports D3 cold wakeup

NOTE: This notebook does not support Zoom Video.

6www.gateway.com

Docking solution

Type Port replicator

Docking supported ■Hot dock

■Warm dock

■Cold dock

Input/Output (I/O ports) ■Two USB 2.0 (4-pin)

■High-speed serial

■Parallel

■Modem (RJ-11)

■Ethernet (RJ-45)

■External monitor (VGA)

■S-Video TV out

■S/PDIF digital audio out

■Stereo headphone output

■Analog audio line input (stereo)

■Two PS/2

■Docking port

■DC input

Storage

Hard drive controller ■Two independent bus-mastering Enhanced IDE

channels on PCI bus

■Supports up to Ultra DMA 100 and up to PIO mode 4

Hard drive ■User removable

■2.5-inch diameter

■9.5 mm height

To find the hard drive capacity:

■In Windows XP, click Start, then click My Computer.

Right-click the drive letter, then click Properties. The

drive’s capacity and available space appear. If the drive

has multiple partitions (for example, C: and D:), add the

capacities of each partition to determine the drive’s

total capacity.

-OR-

■In Windows 2000, double-click the My Computer icon

on your Windows desktop. Right-click the drive letter,

then click Properties. The drive’s capacity and

available space appear. If the drive has multiple

partitions (for example, C: and D:), add the capacities

of each partition to determine the drive’s total capacity.

Specifications for the Gateway 600YG2 Notebook

www.gateway.com

Super I/O controller ■NS PC87391 LPC super I/O controller

■Diskette drive controller

■IEEE 1284 compliant parallel port

■Serial port

Modular bays Two modular bays are available on the notebook.

Supports hot swapping of both bay devices:

■From taskbar

■Through an electrical switch

Optical Drive

To determine the type of optical drive in a bay, examine

the drive tray’s plastic cover. A CD Compact Disc logo

indicates a CD drive, a DVD logo indicates a DVD drive,

a CD-R/RW logo indicates a recordable/rewritable CD

drive, a DVD logo in combination with a CD-R/RW logo

indicates a DVD drive that also is a recordable/rewritable

CD drive, and a DVD-ROM/R/RW logo in combination

with a CD-R/RW logo indicates a recordable/rewritable

DVD drive that also is a recordable/rewritable CD drive.

Available drives include:

■CD

■DVD

■CD-RW

■Combination DVD/CD-RW

■DVD-RW/CD-RW

Second Hard Drive

■2.5-inch diameter

■12.7 mm or 9.5 mm high

Diskette Drive (right modular bay only)

■12.7 mm high

■3.5-inch diskettes

■720k/1.2MB/1.44MB support

Second Battery (right modular bay only)

■Removable six-cell prismatic Lithium Ion battery pack

■3.4 Ah

■11.1 V nominal

■37.74 Wh

8www.gateway.com

Power

Intelligent charger Supports dynamic charge current to achieve the best

charge performance

AC adapter ■19 VDC, 4.72A, 90 W output

■Automatically adjusts for 100 to 240 VAC, 50 to 60 Hz

power source

■Three-wire design

■Includes power LED

Battery type Main

■Removable nine-cell Lithium Ion battery pack

■Embedded controller inside to support smart battery

Secondary

■Removable six-cell prismatic Lithium Ion battery pack

Battery capacity Main

■5.7 Ah

■11.1 V nominal

■63.3 Wh

Secondary

■3.4 Ah

■11.1 V nominal

■37.7 Wh

Battery life varies depending on configuration, programs,

power management settings, and features used.

Recharge time varies, depending on usage.

Power management ■Advanced Configuration and Power Interface 1.0b

(ACPI 1.0b) support

■SMBIOS 2.3

■PC 2001 compliant

■Pentium 4-M CPU supports Intel®Speedstep™

technology

Controls ■Keyboard-activated pop-up display gives battery

charge as a percentage remaining

■Icon on taskbar shows battery charge as a percentage

remaining

■Battery meter on battery

Power switch Supports Power On/Off, Standby/Resume, Hibernate,

Shutdown

Reset hole Resets whole system if notebook cannot be recovered

by power switch

Specifications for the Gateway 600YG2 Notebook

www.gateway.com

Lid switch LCD On/Off, Standby, Hibernate

Security

Passwords ■Power-on password (2-level password support)

■Hard drive password

Physical ■Main system memory compartment screw

■Hard drive bay screw

■Mini PCI bay security screw

■Kensington®security slot on notebook right side

■Kensington®security ring on port replicator

System software

Operating system ■Microsoft®Windows®XP Professional

■Microsoft®Windows®XP Home Edition

■Microsoft®Windows®2000

System management ■SMBIOS 2.3 BIOS support

■Wired for Management 2.0 (WfM 2.0) enabled

■Advanced Configuration and Power Interface 1.0b

(ACPI 1.0b) support

■Support for Wake on LAN from S3 power mode

■Support for Intel®LANDesk®Client manager 6.0

System compatibility ■PC99 specification

■PC2001 specification

■Advanced Power Management 1.2 (APM 1.2)

■Advanced Configuration and Power Interface 1.0b

(ACPI 1.0b) support

■SMBIOS 2.3

■Windows Hardware Quality Labs (WHQL) certified

Quick/Quiet boot Supported

10 www.gateway.com

Physical specifications

Dimensions 15.7-inch display

~13.86 ×11.44 ×1.77 in. (W ×D×H)

~352 ×290 ×45.5 mm (W ×D×H)

15.0-inch display

~13.86 ×11.44 ×1.69 in. (W ×D×H)

~352 ×290 ×43.5 mm (W ×D×H)

System weight 15.7-inch display

includes DVD drive, diskette drive, and battery

~8.65 lbs.

~3.9 kg

15.0-inch display

includes DVD drive, diskette drive, and battery

~8.0 lbs.

~3.6 kg

AC adapter weight 13 ounces (370 g)

Environment

Operating temperature 41°F to 95°F (5°C to 35°C)

Storage temperature -4°F to 140°F (-20°C to 60°C)

Operating humidity 20% to 80% relative humidity; no condensation

Storage humidity 10% to 90% relative humidity; no condensation

Operating altitude, maximum 8,000 feet at 59°F (2,438 meters at 15°C)

Storage altitude, maximum 12,000 feet (3,658 m)

MAN SYS 600 YG2 SPEC R3 8/03

Altri manuali per 600YG2

Altri manuali Gateway Computer portatile

Gateway

Gateway M280 Come usare

Gateway

Gateway EC18 Manuale utente

Gateway

Gateway Solo 3150 Manuale utente

Gateway

Gateway Solo 5100 Manuale operativo

Gateway

Gateway LT 1000 Manuale utente

Gateway

Gateway LT 1000 Manuale utente

Gateway

Gateway M275 Manuale utente

Gateway

Gateway NE46R Manuale utente

Gateway

Gateway Notebook Manuale utente

Gateway

Gateway 6010GZ - Celeron M 1.4 GHz Manuale utente

Gateway

Gateway M-6801mT Manuale elenco delle parti

Gateway

Gateway M505 Manuale utente

Gateway

Gateway MX6960 Guida di sicurezza

Gateway

Gateway M685 Manuale utente

Gateway

Gateway MX6960 Manuale utente

Gateway

Gateway MX8711 - Pentium Dual Core 1.6 GHz Manuale utente

Gateway

Gateway MX6110m Guida rapida

Gateway

Gateway LT 1000 Manuale utente

Gateway

Gateway MX6450 Manuale utente

Gateway

Gateway 200ARC Manuale utente

Gateway

Gateway MT6704 Manuale utente

Gateway

Gateway M250 Manuale utente

Gateway

Gateway 600 Manuale utente

Gateway

Gateway 200ARC Manuale utente

Manuali Computer portatile popolari di altre marche

HP ze2401xt - Pavilion Notebook PC Manuale utente

Velocity

Velocity NoteMagix M10 Manuale utente

Dell

Dell Alienware 17 R2 Manuale utente

Toshiba

Toshiba A105-S2236 Manuale utente

HP ENVY 17 Manuale

Winbook

Winbook LM Manuale utente

Dell

Dell Inspiron 1464 Manuale utente

Dell

Dell Inspiron 15R 5537 Manuale utente

HP PROBOOK 4520S Manuale

Dell

Dell Latitude ATG D620 Manuale utente

Sony

Sony VAIO PCG-FX270 Manuale utente

Dell

Dell Latitude 7310 Manuale utente

Dell

Dell Precision GU806 Manuale utente

Sony

Sony VAIO PCG-R505JLK Manuale utente

Lenovo

Lenovo THINKPAD X32 Manuale utente

HP Compaq tc4200 Guida rapida

Toshiba

Toshiba mini NB300 Manuale utente

Lenovo

Lenovo ThinkPad X201 Tablet Manuale
