GCC Technologies LaserPro C180II Manuale utente
4F-1, 236, Fu-Te 2
nd
Rd., His Chih,
Taipei Hsien, 221, Taiwan
TEL:886-2-6616-6692 ٠2694-6687
FAX:886-2-2694-6875 ٠2694-5097
C180 II Control Panel Changing
Process
Version: 1.0
May 20, 2014
1
Revision History：
Version
Date Page CONTENTS
1.0 May, 20 2014
First release
2
1. Dismount two screws on the bottom of side panel (see red arrows below)
2. Dismount two screws of right-front cover (M3 *2)
1
2
3
3. Dismount 4 screws of back cover (M3 *4)
4. Dismount right window cylinder
3
4
4
5. Dismount 4 screws of right top cover (where the control panel locates)
5
5
5
6. Hanging the right top cover to the right side.
7. Dismount 5 screws for cover of control panel and ground cable screw
6
6
8. After control panel cover is removed, there are 4 screws needs to be removed and the four
cables (in the red circle). Then the control panel can be removed and changed new one.
