GE Rapid TripFix Manuale utente
Rapid TripFix
—
by ABB
Key benefits:
Less tools needed to install
Easier installation, quicker
mounting
RELIABLE AND EASY TO INSTALL.
Full-length neutral bars
User-friendly design with
elevated factory-installed neutral
and ground bars
Convenient,
secure connections
Plug-on neutral AFCI, GFCI, and
DFCI breakers
Troubleshooting guide for Ground Fault, Arc Fault
and Dual Function Circuit Breakers
If the steps above didn’t solve the issues, please submit the data
via this form:
Rapid TripFix
The easy and quick step-by-step guide to saving time
and troubleshooting breaker trips on the spot.
1. Turn the circuit breaker off
2. Turn back on the circuit breaker
What is the breaker’s LED indication?
• Solid red: parallel arcing
• Blinking red: series arcing
• Flashing red and yellow: failed internal test and needs
replacement
• Solid yellow: ground fault
3. Wherever you are, scan this QR code and follow the steps:
4. Press the «Push-to-test» button to confirm the functionality of
the breaker
