GE H1055 Manuale utente

USER MANUAL

Digital Camera

H1055

ENGLISH P.01

FRENCH P.17

PORTUGUESE P.49

SPANISH P.33

Thank you for purchasing GE digital cameras. Please read this manual

carefully and keep it in a safe place for future reference.

No part of this publication may be reproduced, transmitted, transcribed,

stored in a retrieval system, or translated into any language or

computer language, in any form, by any means, without the prior written

permission of General Imaging Company.

Trademarks

All trademarks mentioned in this manual are used for identification

purposes only and may be properties of their respective owners.

Unpacking

Your package should contain the camera model you purchased along

with the following items. If anything is missing or appears to be

damaged, please contact your vendor. (The accessories will vary based

on model purchased and are noted below.)

Preface

USB cable

AV cable

CD-ROM

User Manual

Warranty card

Wrist strap

Rechargeable

Lithium-ion battery

Battery charger

Quick start guide

Camera Views : H1055

megapix

10.1 H1055

1 2 3

16 17 18

19 20 21 22

Camera Views

1 Flash 13 Self-timer/ Down button

2 AF assist beam/

Timer indicator 14 Func/ok button

3 Lens 15 Flash mode/ Left button

4 Mic 16 Power button

5 LCD screen 17 Shutter button

6 Face detection AF button 18 Zoom scroll wheel

7 Status LED 19 Speaker

8 Mode dial 20 Tripod mount point

9 Menu button 21 USB/ AV port

10 Erase button 22 Memory card/

Battery compartment

11 Exposure compensation/

Up button 23 Wrist strap mount

12 Macro mode/ Right button

2. Insert the battery while observing the correct polarity. Use the side of

battery to press down the stopper as shown, allowing the battery to

be inserted properly.

Inserting the battery and SD/SDHC card

1. Slide the battery compartment out and lift it open.

Getting Started

3. Insert an optional SD/SDHC card into the memory card slot as shown.

To remove the SD/SDHC card, open the battery compartment and

gently push the card to release it. Pull the card carefully.

4. Close the battery compartment.

Optional SD/SDHC cards are not included. The use of 64MB to 4GB

memory card is recommended for reliable data storage.

Getting Started

Press the Power button to turn the camera on.

To turn o the camera, press the Power button again.

When turned on, the camera will

enter the mode according to the

mode dial setting. You can also

turn the mode dial to change the

modes after the camera is turned

on.

Turning on and off

The GE camera provides a convenient mode

dial that allows you to switch between dierent

modes with ease. All the available modes are

listed as follows.

Using the mode dial

Icon Mode Name Icon Mode Name

Auto Scene

Playback Portrait

Movie Panorama

Image Stabilization Manual

Mode dial

In Scene mode, you can select from a total of 12 scene types to match

your needs. You just need to select the right scene for the occasion and

the camera will automatically adjust to the optimal settings for you.

Scene mode

Icon Mode Name Icon Mode Name Icon Mode Name

Sport Snow Museum

Children Sunset Landscape

Indoor Fireworks Night landscape

Leaf Glass Night portrait

Power button

Setting display language, date, and time

When using the camera for the rst time, you need to set the language,

date, and time for your camera in the Setup menu.

Getting Started

To access the Setup menu, do the

following:

1. Press the Power button to turn the

camera on.

2. Press the button and use the

navigation buttons to select the

Setup menu.

3. Use the Up/Down navigation buttons

to select Date/Time or Language.

Then press the Right navigation

button to enter the setting.

4. (For Date/Time setting) Press the

Left/Right navigation buttons to

highlight each eld and use the Up/

Down navigation buttons to adjust

the value.

5. (For Language setting) Use the

navigation buttons to select the

desired language.

6. Press the button to conrm the

setting.

The Set date/time and language screen will automatically appear

when the camera is turned on the rst time.

Format Memory

We recommend that you format a memory card before using it for

the rst time after purchasing it, or whenever the card you are

using seems to be the cause of abnormal images.

Please note: formatting enables you to delete all content in the memory

card and built-in memory, including protected photo and movie les.

1. Select the Format Memory setting from the Setup menu as described

previously.

2. Use the Left/Right navigation buttons to select Yes or No, and press

the button to conrm.

3. The current media is formatted.

LCD Screen Display

Shooting mode display Playback mode display

Shooting mode icon

Scene mode icon (only available for

Scene mode)

Light metering method

EV value

Self-timer indicator

Macro mode indicator

Flash mode indicator

Battery status

Face detection “on” indicator

Remaining capacity

Focus frame

Zoom indicator

White balance

ISO speed

Image quality

Image size

Image color

Slow shutter warning indicator

Memory card/internal memory

indicator

EV adjustment slider

Playback mode icon

DPOF le icon

File protection icon

Audio le icon

Video le icon

Memory card/internal memory

indicator

Picture ID

Battery status

Photo audio status

(Press the shutter button to record sound)

(Press the shutter button to play sound)

Recording date and time

Histogram

Aperture value

Shutter speed

Exposure value

Memory capacity

(current picture/ total picture number)

ISO value

Image size

Mode:

13 14 15 16 17

11 12

2 3 4 5 6 7 8

Mode:

1 2 3 4 5 6 7 8

18 17 16

Auto mode is the easiest mode to take photos. While operating in this

mode, the camera automatically optimizes your photos for best results.

To start shooting, do the following:

1. Set the mode dial to Auto mode ( ).

2. Press the Power button to turn the camera on.

3. Compose your picture on the LCD screen and press the shutter button

halfway to focus on the subject.

4. When the subject is in focus, the Focus Frame that appears on the

center of the LCD screen will turn green.

5. Press the Shutter button fully to capture the image.

Using the zoom function

Basic Operation

Zoom indicator

Shooting in Auto mode

T&W button

Your camera is equipped with two types of zoom: optical zoom and

digital zoom. Use the Zoom scroll wheel on the top of the camera to

zoom in or out on your subject while taking pictures.

When the optical zoom factor reaches its maximum value, it stops

momentarily. Keep the (Tele) zoom button depressed and zoom will

switch over to digital zoom automatically.
