GE GLD5600N Manuale
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Reivsed 6/07 350235
Panel
Thickness
Kit A B C
GPF525 25-1/4" 23-1/2" N/A 1/4"
GPF575 25-1/2" 23-5/8" 1/4" 3/4"
Listed by
Underwriters
Laboratories
4"
6"
5" 5"
4"
Figure A
Floor MUST be Even
With Room Floor
Cabinets
Square
and
Plumb
This Wall Area
must be Free
of Pipes or
wires
24"
Min.
24"
Min.
34-1/2"
Underside of
Countertop
to Floor
Plumbing and Electric Service
Must Enter Inside This Area
24
25
MAX.
20-1/2
4
4 (Adjustable)
33-3/4" MIN.
adj. to 35"
27-1/2
22
B
See Detail E for 3/4" Panel
Door insert A
Detail E for 3/4 panel only
Back ViewFront View
F
F
1-7/8 1-7/8
20
Section E-F
C
3/8
3/4
Electrical Rating
Voltage AC.......................................................... 120
Hertz..................................................................... 60
Total connected load amperage............. 10
Calrod® heater watts max........................ 875
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service
with a separate ground wire. This appliance
must be grounded for safe operation.
Note: The rough cabinet opening must be at
least 24" deep, 24" wide and approximately
34-1/2" high from floor to underside of
the countertop. Dishwasher must not be
installed more than 10 feet from sink for
proper drainage. All plumbing and
electrical work must be in accordance
with local codes. The power cord and
connections must comply with the National
Electrical Code Section 422 and/or local
codes and ordinances. The cord must be no
longer than 6 ft. from the junction box to
the receptacle.
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
GLD5600/60N
GE®Tall Tub Built-In Dishwasher
Specification Revised 6/07 350235
GLD5660NSS
Features and Benefits
• Giant Tub with Maximum Capacity Racking - Holds tall and oversized items; washes
16 place settings at once
• 2 Utility Shelves in Upper Rack - Creates space in the upper rack for cups and utensils
• 6-Level BrilliantClean™Towerless Wash System - Quietly and efficiently powers dishes
clean using remarkably less water and energy; 6 wash levels and three wash arms
direct water onto dishes just where it's needed
• SaniSensor™- Continually measures water temperature to sanitize dishes
•
Electronic Controls with 5 Cycles/4 Options - Make it simple to select from
a wide range of wash cycles
• QuietPower™3 Sound Package - Dramatically reduces the sound
of washing the dishes
• 2/4/8-Hour Delay Start - Makes it easier than ever to wash dishes at any hour taking
advantage of reduced energy rates or washing dishes even when the family is asleep
• 100% Triple Water Filtration - Water stays clean, so just-washed dishes do, too
• SaniWash Cycle - Sanitizes tableware by reducing 99.999% of bacteria
found on dishes
• HotStart™Option - Preheats water before the main wash cycle
for dependable performance every time
• Model GLD5600NWW - White on white
• Model GLD5600NCC - Bisque on bisque
• Model GLD5600NBB - Black on black
• Model GLD5660NSS - Stainless steel
GLD5600/60N
GE®Tall Tub Built-In Dishwasher
