GE Profile PT970DR Manuale

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Listed by

Underwriters

Laboratories

Specification Created 5/10

220153

KW Rating

240V 6.8

208V 5.1

Breaker Size

240V 30 Amps

208V 30 Amps

PT970DR

GE Profile™30" Built-In Double Microwave/Convection Oven

L2 x 4 or

equivalent

runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

(must support 275 lbs.)

Cabinet 30"

A – Overlap of oven over side of edges of cutout 11/16"

B – Overlap of oven at top and bottom of cutout 1"

C – Overall of oven at top of cutout 1/2"

Oven

D – Overall depth* 23-1/2"

E – Overall height with trim 44"

Overall height without trim 43-1/2"

E –Overall width 29-3/4"

*Depth including door handle is approximately 26-6/10" min. to

26-9/10" max.

20''

28''

21''

CONDUIT

(72'' LONG)

CUTOUT

HEIGHT

42-3/16'' MIN.

42-1/4'' MAX.

CUTOUT

WIDTH

28-1/2'' MIN.

28-5/8'' MAX.

Minimum

cutout location

21-5/8''

from the floor

21" Minimum

Door Allowance

JUNCTION BOX

LOCATION

CABINET

WIDTH

30''

DOOR MUST BE

REMOVED BEFORE

INSTALLATION

MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.

THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.

CUTOUT DEPTH

23-1/2'' MIN.

Note: Cabinets installed adjacent to wall ovens

must have an adhesion spec of at least a 194°F

temperature rating. Electric wall ovens are

not approved for installation with a plug and

receptacle. They must be hard wired in accordance

with installation instructions.

Door handle protrudes 3" from door face. Cabinets

and drawers on adjacent 45° and 90° walls should be

placed to avoid interference with the handle.

Installation Information: Before installing, consult

installation instructions packed with product for

current dimensional data.

L2 x 4 or

equivalent

runners

Suitable

bracing

to support

runners

21-5/8"

over centerline

of cabinet

(must support 275 lbs.)

Cabinet 30"

A – Overlap of oven over side of edges of cutout 11/16"

B – Overlap of oven at top and bottom of cutout 1"

C – Overall of oven at top of cutout 1/2"

Oven

D – Overall depth* 23-1/2"

E – Overall height with trim 44"

Overall height without trim 43-1/2"

E –Overall width 29-3/4"

*Depth including door handle is approximately 26-6/10" min. to

26-9/10" max.

20''

28''

21''

CONDUIT

(72'' LONG)

CUTOUT

HEIGHT

42-3/16'' MIN.

42-1/4'' MAX.

CUTOUT

WIDTH

28-1/2'' MIN.

28-5/8'' MAX.

Minimum

cutout location

21-5/8''

from the floor

21" Minimum

Door Allowance

JUNCTION BOX

LOCATION

CABINET

WIDTH

30''

DOOR MUST BE

REMOVED BEFORE

INSTALLATION

MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.

THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.

CUTOUT DEPTH

23-1/2'' MIN.

Dimensions and Installation Information (in inches)

BROIL CLEAN

BAKE

PROBE COOK TIMER

STOP

CLOCK CLEAN

START

DELAY

CONV

Specification Created 5/10

220153

Features and Benefits

• Blackglossoveninterior–Blackoveninterioraddsastylishtouchtoanykitchen

• PreciseAir™convectionsystem–Areversingfancirculatesheatandairforevenly

browned and baked foods

• ConvectionBake–Thissettingisoptimalforbakingcasserolesorlasagnas,yeast

breads, pies and pizzas with no need to turn the pan

• Convectionroast–Optimalforlargercutsofmeat,thissettingrotatestheheataround

all sides, sealing in the juices, producing rotisserie results at up to 25% faster than a

conventional oven

• Super-largeovencapacity–Remarkablylargeoveninteriorisidealforholidays,dinner

parties and everyday family cooking

• Self-cleanoven–Self-cleanallowsyoutospareyourselffromthetroubleandeffortit

takes to scrub the oven interior

• Electronicovencontrols–Electronicpadsonthecontrolpanelareeasytooperatewith

just a touch

• 1.6Cu.Ft.Capacity(UpperOvenOnly)–Providesalargeinteriortoaccommodatea

variety of cookware, dinnerware and food containers

• Turntable(upperovenonly)–Rotatesfoodthroughoutthecookingcycleforeven

cooking results

• Hiddenbakeoveninterior–Concealsthelowerovenbakeelementtoeliminatehard-to-

reach areas that collect food and spills for easy cleaning

• ModelPT970DRBB–Blackonblack

• ModelPT970DRWW–Whiteonwhite

PT970DR

GE Profile™30" Built-In Double Microwave/Convection Oven
