Dimensions and Installation Information

For answers to your Monogram,® GE Profile™ or

GE® appliance questions, visit our website at

ge.com or call GE Answer Center® service,

800.626.2000.

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

JGB908WEK/CEK/BEK

GE Profile™ 30" Free-Standing Gas Range

Dimension and installation information are shown in inches.

Note: Dimension from the wall to the front

of the closed door handle is 29”. Depth to

front edge of cooktop 25-1/4”.

Installation Information: Before installing,

consult installation instructions packed

with product for current dimensional data.

24

30" FS Gas Ranges-CL

30

8

4

9

2

2-1/2

Recommended area for

thru the floor connection

of

p

i

p

e stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

30

47-3/4

26-1/4

46-3/8

36-1/4±1/4

Installation Information (Dimensions in inches)

Recommended common area

for gas outlet and electrical

outlet for GE free-standing

gas range models

Specification Created 12/04

230560

JGB908WK/CK/BK

HI

LITE

FRONT

9

8

7

654

3

2

1

LOHI

LITE

REAR

9

8

7

654

3

2

1

LO

HI

LITE

RECISE SIMMER

REAR

9

8

7

654

3

2

1

LO

LITE

POWER

BOIL

FRONT

HI

86

4

2

LO

POWER BOIL

SETTING INTENDED FOR

USE WITH LARGER POTS

HI

LITE

CENTER

9

8

7

654

3

2

1

LO

JGB908WEK/CEK/BEK

GE Profile™ 30" Free-Standing Gas Range

Specification Created 12/04

230560

Features and Benefits

• Self clean oven - Conveniently cleans the oven cavity without need of scrubbing

• Super-large oven capacity – Provides an impressively large oven interior for

cooking more dishes and large meals at once

• Deep recessed cooktop - Designed with a recessed surface to help contain

spills and make cleaning easy

• Center oval burner - Fifth burner in the center of the cooktop, ideal for griddle

or odd-size cookware

• Non-stick griddle - Placed over a fifth center burner the griddle provides a flat,

non-stick surface for cooking and warming all types of foods

• Power Boil™ 17,000 BTU burner – Delivers 17,000 BTUs of forceful heat for

rapid boiling

• Warming drawer - Convenient drawer keeps breads, desserts or just-cooked

foods warm and ready-to-serve

• QuickSet V oven controls - Feature an easy to use design that allows you to

set precise cooking temperatures

• Precise simmer burner - Offers the low setting of 600 BTUs, ensuring more

temperature control for simmering

• Sealed cooktop burners - Eliminates the space between the burners and the

cooktop to help contain spills and boil over liquids, ensuring easy cleanup

• Model JGB908WEKWW - White on white

• Model JGB908CEKCC - Bisque on bisque

• Model JGB908BEKBB - Black on black
