GE GSL22JFTBS Manuale
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Dimensions and Installation Information (in inches)
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
GSL22JFT
GE® ENERGY STAR®22.0 Cu. Ft. CleanSteel™Side-By-Side Refrigerator with Dispenser
Overall
Dimensions
Height to top of hinge (in.) A 67-1/2
Height to top of case (in.) B 66-1/2
Case depth without door (in.) C†28
Case depth less door handle (in.) D†31-1/4
Case depth with door handle (in.) E†33-9/16
Depth with fresh food door open 90° (in.) F†49-3/8
Width (in.) G 33-1/2
Width with door open 90° inc. door handle (in.) H 35-15/16
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Revised 5/07 310210
GSL22/25JFTBS
Warmer
Colder
Warmer
Colder
Water Lock
Crushed Cubed Light
AdjustTemperature
9iscoldest / 0 is off
Freezer Refrigerator
SetTemp
9iscoldest / 0 is off
Features and Benefits
• CleanSteel™Exterior - Offers a premium stainless look that resists fingerprints,
smudges, and smears
• External Temperature Controls with Child Lock - Combines the ease of 0-9 temperature
settings, with the sophistication of electronic controls
• Adjustable Humidity Vegetable/Fruit Crisper - Provides easy storage environment for
fruits and vegetables
• Adjustable Temperature Deli Drawer - Keep meats and cheeses fresher, longer
• Snack Pan - Helps keep everyday foods like muffins and carrot sticks fresh
• Adjustable Gallon Door Bins - Make room for milk and other gallon-size containers
• AutoEnergy Saver - Senses freezer and fresh door openings and adjusts refrigeration
operation cycles accordingly
• GE SmartWater™Filtration System - Delivers clean great-tasting water and ice through the
LightTouch! Dispenser
• FrostGuard™Technology - Protects frozen items from freezer burn by monitoring freezer
door openings and defrosting only when needed
• Deluxe Quiet Design - Significantly reduces operating noise
• NeverClean™Condenser - Condenser coils are encased, so they don’t require cleaning
in normal operating environments
• Model GSL22JFTBS - CleanSteel™
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
GSL22JFT
GE® ENERGY STAR®22.0 Cu. Ft. CleanSteel™Side-By-Side Refrigerator with Dispenser
Specification Revised 5/07 310210
