GE Profile PDCF1NBW Manuale

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Dimensions and Installation Information (in inches)

Listed by

Underwriters

Laboratories

Front View Top View

B

A

E

F

G

TCX22 QSART

CD

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

Specification Revised 4/07 210843

Overall

Dimensions

Height to top of hinge (in.) A 69-5/8

Height to top of case (in.) B 69

Case depth without door (in.) C 24-1/8

Case depth less door handle (in.) D 28

Case depth with door handle (in.) E 31

Depth with fresh food door open 90° (in.) F 61-3/8

Width (in.) G 35-7/8

Width with door open 90° inc. door handle (in.) H 40-7/8

Air

Clearances

Each side (in.) 1/8

Top (in.) 1

Back (in.) 1/2

PDCF1NBW

GE Profile™ENERGY STAR® 21.1 Cu. Ft. Bottom-Freezer Drawer Refrigerator

Note:

Anti-tip bracket part number 200D8494P001 will be shipped with

every counter-depth model

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

Specification Revised 4/07 210843

PDSF5NFWWW

PDSF5NBWWW

PDCF1NFWWW

PDCF1NBWWW

Features and Benefits

• Counter-Depth Configuration - Offers a built-in look by fitting almost completely flush with

surrounding cabinetry and blending in with décor

• High-Gloss, Contoured Doors, Sculptured Handles and Top and Bottom Bevels - Offer a

dramatic look and touch of personal style to any kitchen

• Optional Automatic Icemaker - Equipped for a automatic icemaker

• Freshness Center™- Offers maximum convenience by utilizing two humidity-controlled

drawers and 1 full-length drawer for large storage

• BrightSpace™Interior with GE Reveal™Lighting - Cast a natural-looking glow throughout

the refrigerator

• Multi-Level Slide 'n Store™Basket System - Includes three full-extension baskets for

tremendous storage flexibility and keeps contents perfectly in place

• Condiment Bin and Beverage Rack - Provides convenient storage for canned drinks

and condiments

• QuickSpace™Shelf - Slides out of the way to make room for tall items

• Upfront Temperature Controls with Actual Temperature Display & TurboCool™Setting -

Features easy-to-reach, easy-to-read temperature controls and a setting to quickly restore

proper temperature after frequent door openings

• Self-Closing Drawer - Self-closing hinges automatically pull the drawer shut when it's within

one inch of the closed position

• Adjustable Gallon Door Bins - Make room for milk and other gallon-size containers

• NeverClean™Condenser - Condenser coils are encased, so they don't require cleaning in

normal operating environments

• Model PDCF1NBWWW - White on white

• Model PDCF1NBWBB - Black on black

PDCF1NBW

GE Profile™ENERGY STAR® 21.1 Cu. Ft. Bottom-Freezer Drawer Refrigerator
